Laser distance sensor OCP352H0180
analogM12 connectorIP67

Laser distance sensor - OCP352H0180 - wenglor sensoric GmbH - analog / M12 connector / IP67
Laser distance sensor - OCP352H0180 - wenglor sensoric GmbH - analog / M12 connector / IP67
Laser distance sensor - OCP352H0180 - wenglor sensoric GmbH - analog / M12 connector / IP67 - image - 2
Add to favorites
Compare this product

Characteristics

Technology
laser
Output
analog
Electrical connection
M12 connector
Protection level
IP67
Range

Min.: 50 mm
(2 in)

Max.: 350 mm
(14 in)

Description

These sensors work with a high-resolution CMOS line and DSP technology and determine distance using angular measurement. As a result, material, color and brightness related measurement differences are virtually eliminated. Integrated analogue output can be configured for voltage 0...10 V (10...0 V) or current 4...20 mA (20...4 mA). Features at a Glance High resolution: 50 µm (resolution-mode) Linearity: 0,15 % (resolution-mode) Zoom function Measured value independent of material, color and brightness
