Outside micrometer SHAHE/5205-50 25-50mm 0.001mm ±0.003mm/Digital Micrometerdigitalhigh-precisionhigh-speed

outside micrometer
outside micrometer
outside micrometer
outside micrometer
outside micrometer
outside micrometer
outside micrometer
outside micrometer
outside micrometer
Add to favorites
Compare this product
indicative price

Characteristics

Measurement
outside
Display
digital
Other characterisitcs
high-precision, high-speed
Measuring range

Min.: 25 mm (0.984 in)

Max.: 50 mm (1.969 in)

Resolution

0.001 mm (0.00004 in)

Description

Technical Data 1. Measuring range: 25-50mm 2. Resolution: 0.001mm 3. Accuracy: ±0.003mm 4. Measuring force: 5-10N 5. Power consumption: <=20uA 6. Storage temperature: -20℃-60℃ 7. Operating temperature: 0℃-40℃ 8. ON/OFF...SET key: Power switch, Datum set 9. ABS...in/mm key: Absolute and relative measuring 10. Quick display of the measured value on LCD screen, no over-speed error.
