Temperature indicator GDI-100-D

pressuredensityLCD display

Internal and external SF6 gas-insulated equipment High- and medium-voltage levels Maintenance and service facilities Temporary or continuous monitoring of the gas density, pressure and temperature of closed SF6 gas tanks Recalibration of gas density monitors and gas density indicators Special features High-precision on-site display Logger function with up to 3 measured values per second Communication and data exchange via WIKA-Wireless Description General information The model GDI-100-D precision digital gas density indicator adopts the concept of an analogue SF6 gas density indicator, but operates, however, at such a high level that only digital sensor technology can cope with. The accuracy of digital measurement technology and the simplicity of an analogue gauge are brought together in the GDI-100-D, which in terms of performance, ease-of-use, and instrument features, is unmatched in SF6 gas density measurement. Temporary monitoring SF6 gas-filled switchgear must be monitored, following maintenance and new installation, for a specified time, in order to eliminate any leakage or defective maintenance. The GDI-100-D enables this temporary monitoring and records the parameters gas density, pressure and temperature. Accuracy The GDI-100-D is fitted with the high-precision sensor technology from the model CPG-1500 precision digital pressure gauge and determines the SF6 gas density with an accuracy of 0.6 %. It is calculated from the parameters of pressure and temperature via a complex virial equation in the internal evaluation electronics.
