Peak power sensor PCC423VP-10-J9T2A

Vibration transmitter, 4-20 mA output proportional to peak velocity, 1.0 in/sec full-scale measurement range, operation to 105°C, low profile with side exit 16' integral cable with Teflon jacket, the upgraded PCC42X series is smaller, lighter and lower price Vibration transmitter sensors represent vibration levels by a loop current of 4-20 mA, which can be easily integrated into existing plant control systems, such as a PLC, DCS, or SCADA system. As part of a continuous monitoring setup, 4-20 mA trend data can be easily compared against standard vibration guides to indicate general machine health. Peak velocity output 16 ft. high temperature integral cable Hermetically sealed ESD, overload and reverse wiring protection Sensor output - 4-20 mA Measurement unit - Velocity Detector type - Peak Full-scale range - 1.0 IPS Connector style - Integral cable Connector orientation - Side exit Cable type - J9T2A (twisted pair, braided shield, yellow Teflon jacket) Cable length - 16 ft Temperature range - -40°C to +105°C Weight - 145 grams Hazardous area approvals - Non-approved
