Peak power sensor PCC421VP-20-R6

peak power sensor
peak power sensor
Add to favorites
Compare this product


Characteristics

Other characteristics
peak

Description

Vibration transmitter, 4-20 mA output proportional to peak velocity, 2.0 in/sec full-scale measurement range, operation to 105°C, low profile with side exit 2-pin MIL-C-5015-style connector, the upgraded PCC42X series is smaller, lighter and lower price Vibration transmitter sensors represent vibration levels by a loop current of 4-20 mA, which can be easily integrated into existing plant control systems, such as a PLC, DCS, or SCADA system. As part of a continuous monitoring setup, 4-20 mA trend data can be easily compared against standard vibration guides to indicate general machine health. Peak velocity output Corrosion resistant Hermetically sealed ESD, overload and reverse wiring protection Sensor output - 4-20 mA Measurement unit - Velocity Detector type - Peak Full-scale range - 2.0 IPS Connector style - MIL-C-5015, 2-pin Connector orientation - Side exit Temperature range - -40°C to +105°C Weight - 145 grams Hazardous area approvals - Non-approved

Catalogs

No catalogs are available for this product.

See all of Wilcoxon Sensing Technologies‘s catalogs
