5.5" tablet TG500G7

Android 13MediaTek Genio 5104 GB

Overview The TG500G7 is a 5.5-inch rugged Android tablet controller designed for mission-critical industrial applications. It is powered by a Genio 510 processor (2 x A78 + 4 x A55), runs Android 13, and combines IP65 ingress protection with MIL-STD-810H shock and vibration resistance for reliable operation in harsh environments.

• Key features1920 x 1080 TFT LCD with optical bonding and anti-glare touch
• Genio 510 CPU (2 x A78 + 4 x A55)
• IP65 all-weather, dust- and water-resistant enclosure
• MIL-STD-810H compliant for drop, shock and vibration
• Compact ergonomic design for secure handheld use
• Support for Wi‑Fi and BT
• High brightness 1000 nits for outdoor readability

• CertificationsCE
• FCC

Display Size: 5.5 inches
Resolution: 1920 x 1080
Type: Projected Capacitive Multi Touch
Panel Brightness: 1000 nits
Contrast Ratio: 1000:1
View Angles: 80,80,80,80
Bonding: Optical bonding for sunlight viewability
Viewability: Anti-Glare touch treatment
Touch Mode: Supports hand, gloves and rain modes System Specification Processor: Genio 510 (2 x A78 2.2GHz + 4 x A55 2.0GHz)
Memory: 4 GB
Storage: 64 GB eMMC
Operating System: Android 13.0
WLAN: Supported
BT: Supported Mechanical Dimensions: 204.2 x 135.1 x 46 mm
Cooling System: Fanless design IO Ports USB: 1 x USB 3.0 (Type-C)
LAN: 1 x M10 LAN connector (10/100 Mbps, max to 250 Mbps) optional
Video: 1 x micro HDMI output
Audio: 2 x speakers
SD Card Slot: 1 x micro SD card slot (up to 2 TB) Environment Operating Humidity: 10% to 90% RH, non-condensing
Operating Temperature: -20°C to 60°C (AC mode), -10°C to 50°C (Battery mode)
Storage Temperature: -30°C to 70°C
Shock: MIL-STD-810H Method 516.8 Procedure I
Vibration: MIL-STD-810H Method 514.8 Procedure I
IP rating: IP65 Control Buttons: 6 x programmable buttons, 1 x power button Power Battery: Standard — one 3.7V typ. 3200 mAh rechargeable Li-ion battery (2S1P); Optional — two 7.4V typ. 6400 mAh rechargeable Li-ion battery (2S2P)
Battery Operating Time: One pack ~8 hrs; Dual pack (optional) ~16 hrs
Power Rating: 19V DC
Adapter: 100-240V AC, 50-60Hz / 19V DC Accessory Included: 1 x 65W PD adapter, 1 x power cord
Optional: shoulder strap, Microhard 2450, M10 LAN external cable (2 m), external antennas (optional for RF module)

• Technical specificationsModel: TG500G7
• Platform / CPU: Genio 510 (2 x A78 + 4 x A55)
• Memory: 4 GB
• Storage: 64 GB eMMC
• OS: Android 13.0
• Display: 5.5 inches, 1920 x 1080, projected capacitive multi-touch, 1000 nits
• Ruggedness: IP65, MIL-STD-810H shock and vibration
• Dimensions: 204.2 x 135.1 x 46 mm
• I/O: USB 3.0 Type-C, micro HDMI, optional M10 LAN, micro SD slot (up to 2 TB)
• Battery options: single 3200 mAh or dual 6400 mAh
• Certifications: CE, FCC
