Touch screen panel PC W07IE3A-67O1-P

PCAP touchscreenmultitouch screen7"

Overview
The Winmate W07IE3A-67O1-P is a 7-inch IP67 panel PC designed for industrial and outdoor HMI applications. It pairs an Intel® Celeron® N6211 processor with a high-brightness P-cap multi-touch display and a waterproof front for reliable operation in harsh environments.

Key features

• Intel® Celeron® N6211 Processor (1.5M cache, up to 2.60 GHz)
• 7.0" display, 1024 x 600 resolution, 1000 nits brightness
• P-cap multi-touch with optical bonding to improve clarity
• Optional anti-reflective protection glass (optical bonding)
• Front IP67 protection; VESA mounting support
• Plastic front bezel with anti-corrosion aluminum die-cast back cover
• Wide operating temperature: -10°C to 55°C
• Wide DC input: 9–36V (optional ignition on/off delay)

Certifications

• IP67 (front)
• CE
• FCC

Display & touch

• Projected capacitive (P-cap) multi-touch bonded to the panel
• Optional True Flat protection glass bonded to panel
• Active area: 153.6 x 90 mm; contrast ratio 700:1; viewing angles 75/75/75/70

Mechanical & enclosure

• Dimensions: 189.4 x 145.4 x 49.8 mm; weight: 1.2 kg
• VESA mount for wall or panel installations
• Front plastic bezel; aluminum die-cast back cover with Surtec 650 / polyester powder coating
• Fanless design for maintenance-free operation

Environmental & ruggedness

• Operating temperature: -10°C to 55°C; storage: -30°C to 70°C
• Operating humidity: 10%–90% RH, non-condensing
• Shock/Vibration: MIL-STD-810G (516.6 Procedure I / 514.6 Procedure I)
• Front protection rating: IP67 for dust and water resistance

I/O & power

• 1 x M12 waterproof connector for 2 x USB2.0
• 1 x M12 waterproof connector for RS232
• 1 x waterproof Gigabit LAN RJ45 connector
• 1 x M12 waterproof power input 9~36V DC
• LED indicators for power and storage; power and brightness keys (Power, F1, F2, F3)

Accessories & options

• Included: external open-wire power cable, USB/COM/LAN waterproof cables, waterproof caps, RJ45 female-female converter, VESA screws
• Optional: 100~240V AC to DC 84W adapter with power cord
• Ordering option: W07IE3A-67O1-G (Anti-Reflective Protection Glass)

Technical specifications

• Model: W07IE3A-67O1-P
• Processor: Intel® Celeron® N6211 1.2 GHz (up to 2.6 GHz)
• Memory: 1 x SO-DIMM DDR4 3200 MHz — 4 GB standard; 8 GB and 16 GB optional
• Storage: 1 x M.2 2242 B-Key SSD 128 GB standard; 256 GB and 512 GB optional
• Ethernet controller: 1 x Intel® Ethernet Controller
• Security: TPM 2.0
• OS (optional): Windows 11 IoT Enterprise / Windows 11 Pro / Windows 10 IoT Enterprise / Linux Ubuntu 22.04
• WLAN / Bluetooth: optional
• Display: 7.0 inches, 1024 x 600, 1000 nits
• Touch / Glass: P-cap multi-touch bonding with panel; True Flat protection glass optional
• Contrast ratio: 700:1
• Active area: 153.6 x 90 mm
• Dimensions / Weight: 189.4 x 145.4 x 49.8 mm / 1.2 kg
• Mounting: VESA mount
• Cooling: fanless
• Operating humidity: 10%–90% RH non-condensing
• Operating temperature: -10°C to 55°C
• Storage temperature: -30°C to 70°C
• Shock / Vibration: MIL-STD-810G
• IP rating: IP67 (front)
• Certifications: CE, FCC
