Electric servo-actuator

linearfor the oil and gas industryintegrated

Safety, reliability and competence Integrated systems under one roof: perfectly tailored components for the regulation and control of your movements. We are specialists in power and signaling electronics for high-voltage and low-voltage applications. The SSEAC (SubSea Electric ACtuator) is the first complete valve actuator by WITTENSTEIN for the oil and gas industry. It is designed for water depths of 3,000 m and can be used for throttle, gate and ball valves as well as High-Integrity Pressure Protection Systems (HIPPS) and Chemical Injection Metering Valves (CIMVs). It was unveiled at the Houston OTC in May of 2014. Since 2001, over 250 WITTENSTEIN drives have been reliably deployed on the ocean floor. Benefits: Replaces hydraulic systems Valve condition monitoring Early notification to the surface in cases of critical conditions Double-sealed, housing configurable to customer specifications Performance data: Redundancy (2 channels) Maximum torque of 2700 Nm Super duplex housing 25-year service life
