Turbine flow meter YYCL2

volumefor waterfor liquids

Working principle & construction
The flowmeter uses a tangential turbine measurement structure with a four‑blade impeller inside the flow chamber. Internally it integrates a magnetic induction flow detection unit, a temperature sensor and a pressure sensor in a coaxial three‑in‑one configuration.

• Flow measurement: Fluid flow drives the impeller; an electromagnetic conversion unit generates pulses. Instantaneous and cumulative flow are calculated from pulse counts per unit time.
• Temperature measurement: Built‑in high‑precision temperature element monitors the medium temperature in real time for temperature compensation and improved measurement stability.
• Pressure measurement: Integrated pressure‑sensitive element records pipeline operating pressure, enabling multi‑parameter monitoring at a single point.

Construction & installation
The instrument housing is stainless steel with a high protection rating. It supports multiple installation methods, including sanitary tri-clamp and threaded connections, for reliable long‑term operation in industrial field environments.

Product features

• Integrated multi‑parameter measurement: Simultaneous measurement of flow, temperature and pressure with a single instrument, reducing measurement points and lowering installation and maintenance costs.
• Application versatility: Configurable materials, seals and mounting options to suit various media and field conditions.
• Broad measuring range & full diameter coverage: Accurate at low flows while maintaining stable performance at high flows.
• High accuracy & repeatability: Delivers precise measurements and consistent long‑term performance.
• Tangential measurement structure: Low pressure drop, minimal flow disturbance and low operational noise.
• Fast response & high sensitivity: Maintains accuracy at low velocities across a wide range of conditions.
• Rugged construction: Withstands high pressure and extreme temperatures for harsh industrial environments.
• Real‑time synchronized signal acquisition: Simultaneous capture of temperature and pressure signals with stable, interference‑resistant performance.
• High‑reliability electronics: Uses precision sensing elements to ensure long service life and reliability.
• Standard outputs & communication: Supports standard signal outputs and communication interfaces; compatible with display terminals for simple configuration and remote monitoring.

Selection parameters & technical specifications
Typical performance parameters are listed below.

Measurement performance

• Measured parameters: Flow rate, temperature, pressure
• Applicable media: Clean water, low‑viscosity fluids
• Measurement principle: Velocity‑type (conservation of angular momentum)

Operating conditions

• Installation: Sanitary tri-clamp, threaded or custom connections

Construction & materials

• Housing material: Stainless steel
• Protection rating: High, industrial grade

Output & communication

• Standard output signals: Available
• Communication interfaces: Available for remote monitoring

Typical applications

• Water treatment and distribution
• HVAC systems
• Industrial cooling circuits
• Process control loops
• General industrial automation

Technical specifications

• Model / Series: YYCL2 Series (Smart turbine multi‑parameter flowmeter)
• Measured parameters: Flow, temperature, pressure
• Applicable media: Clean water, low‑viscosity fluids
• Measurement principle: Velocity‑type (conservation of angular momentum)
• Housing material: Stainless steel
• Installation types: Sanitary tri‑clamp, threaded, custom connections
• Protection rating: High, industrial grade
• Output signals: Standard outputs available
• Communication: Interfaces available for remote monitoring
