Automatic fire detection and alarm unit HY-1025R
Add to favorites
Compare this product
Characteristics
- Other characteristics
- automatic
Description
Overview
Control Panel Specification
System Specification
Integration & Configuration
Additional Information
- Model: HY-1025R
- Product type: Addressable Control Panel
- Key points:
- Addressable Class A panel with 2 loops, supports up to 254 devices per loop; 4.3" LCD display; RS-485 cascading up to 128 panels; optional built-in micro thermal printer
Control Panel Specification
- Working Voltage: 16V DC–28V DC
- Main Power: AC90–240V, 50/60Hz
- Backup Power: 2×12V/5Ah lead-acid battery
- Log Record Capacity: Max. 2048 records
- Fire Alarm / Fault Terminals: NO/NC
- Communication Distance: Standard 1500 m (extendable to 3000 m)
- Cable Specs: 2×1.5 mm² (2×16 AWG)
- Display: 480×272 4.3" LCD screen
- Printer (optional): Micro thermal printer
- Dimensions: 333.0 × 115.0 × 480.0 mm
- Operating Temperature: –10°C to +40°C
- Operating Humidity: ≤ 95% RH (no condensation)
- Protection Grade: IP30
- Weight: 7 kg (10 kg with 2 batteries)
- Compliance Standard: EN54-2, EN54-4
System Specification
- Loops: 2 loops for HY-1025R (1 loop for HY-1022R)
- Loop Capacity: Up to 254 sensors/modules per loop
- Topology: Class A (HY-1022R / HY-1025R) or Class B variants
- Panel Cascading: Up to 128 panels via RS-485
- Simulated Zones: Every 32 addresses can form a zone (when printer option enabled)
- Communication Limits: Performance depends on communication distance and battery specifications
- Optional Peripherals: Telephone & broadcast systems, micro thermal printer
Integration & Configuration
- Configuration Tools: ControlConfig Tool for alarm linkage
- Presale & Verification: Dahua Fire (Wisualarm) Presale Tool
- Solutions: Online via Wisualarm Cloud Platform; Local via DSS Pro Platform (V8.5–V8.7, server required)
- Compatible Cables: 2×1.5 mm² / 2×16 AWG
Additional Information
- Display: 4.3" LCD; optional micro thermal printer
- Suitable for installations requiring high loop/device capacity and panel cascading
- Designed to comply with EN54-2 and EN54-4 standards
