Monitoring software ZAmon

analysiscommissioningparameterization

Product overview
ZAmon Desktop software enables rapid on-site connection and configuration of ZAdyn frequency inverters and the ZArec4C power recuperation unit using a notebook. With the ZAmon STICK, inverters and recuperation units can connect to ZAmon Mobile via Bluetooth, allowing commissioning, parameterisation, diagnostics and optimisation from a smartphone. ZAmon also supports parameter data storage and transfer between ZAdyn and ZArec devices and facilitates generation of documentation for elevator systems.

Key benefits

• Time-optimised commissioning and parameter transfer for elevator drives
• Analysis and optimisation of drive behaviour and elevator performance
• Fast diagnosis of faults (rail joints, door bolt gaps, communication issues with control systems)
• Secure storage, management and restoration of parameter sets
• Streamlined creation of system documentation and reports

Features

• ZAmon Desktop: PC-based application for connection, configuration and in-depth analysis
• ZAmon Mobile: Smartphone app for Bluetooth-based commissioning and monitoring (requires ZAmon STICK)
• ZAmon STICK: Bluetooth interface to connect ZAdyn inverters and ZArec4C recuperation units to mobile devices
• Quick access to parameters and functions of ZIEHL-ABEGG control units
• Parameter backup/restore and transfer between devices to speed up rollouts
• Diagnostic logs and analysis tools for fault localisation and optimisation

Technical specifications

• Supported devices: ZAdyn frequency inverters; ZArec4C power recuperation unit
• Connection methods: USB (ZAmon Desktop) and Bluetooth (ZAmon Mobile via ZAmon STICK)
• Main functions: commissioning, parameterisation, diagnostics, analysis, optimisation, parameter backup/restore
• Output: generation of documentation and reports for elevator systems
• Documentation: instruction manual available in English (PDF)
