Máquina de laminar de rolo a rolo R2R

automáticacom corte longitudinalindustrial

Overview
The Crest R2R Laminator Slitter combines protective and functional lamination, heavy-duty shear-cut trimming and precision tension-controlled rewinding in a single continuous workflow. One pass, one operator, one finished roll. Originally engineered for printed PET on self-adhesive PE foam and thin PVC. Configurable around a broader range of printed roll materials and converting requirements.

Key capabilities

• Integrated roll-to-roll converting: lamination, shear-cut trimming and rewind in one pass
• Adjustable heatable laminating rollers to handle a wide range of substrates and adhesive systems
• Heavy-duty pneumatic shear-cut trimming for clean edges on thick and rigid substrates
• Automated web tension regulation via a closed feedback loop across unwind, lamination, trimming and rewind stages
• PLC + HMI control and a configurable platform adapted to web width, lamination setup, trimming configuration, backing application and rewind tension

Three functions — one pass

• Laminate: Apply protective films and functional layers in one workflow. Supports self-adhesive PE foam, thin PVC backing and protective laminate over UV-cured, latex, solvent and eco-solvent printed media.
• Trim: Heavy-duty pneumatic shear-cut trimming that cleanly cuts tough substrates (including thick PVC) without cracking or deforming the material, delivering a precise finished width straight off the line.
• Rewind: Precision tension-controlled rewinding with wide tension range: high torque on the unwind for rigid substrates and delicate handling at rewind to protect print and laminate quality.

Applications / Where it is used

• Print finishing & sticker production — converting printed PVC, PET and self-adhesive vinyl
• Wide format & decorative roll media — wallcoverings, canvas, banners and floor graphics
• Custom configurations for specialty printed roll materials and technical substrates

Best suited for

• Manufacturers of printed wallcoverings and decorative wallpapers
• Producers of canvas, banner and floor graphic roll media
• Wide format print finishers converting roll-printed output
• Specialty roll material converters with custom requirements
• Production lines seeking to integrate lamination, trimming and rewinding to reduce handling and alignment errors

Suitable materials

• Printed wallcoverings
• Decorative wallpapers
• Canvas prints
• Banner media
• Floor graphics
• UV-cured, latex, solvent & eco-solvent prints
• Foam backing layers and self-adhesive vinyl
• Specialty printed media

Frequently noted product information

• Engineered for a wide, accurately controlled tension range to protect print quality and roll structure
• High torque available on unwind for rigid substrates; delicate, low-tension handling at rewind for fragile media
• Platform is configurable around material type, web width and production process

Caractéristiques / spécifications techniques

• Product name: R2R Laminator Slitter
• Functions: Lamination, heavy-duty shear-cut trimming, precision tension-controlled rewinding (integrated)
• Control: PLC + HMI
• Lamination rollers: adjustable, heatable (supports a wide range of substrates and adhesives)
• Trimming: heavy-duty pneumatic shear-cut system for thick PVC and rigid substrates
• Tension control: automated closed-loop web tension regulation across unwind, lamination, trimming and rewind
• Configuration: configurable platform (web width, lamination setup, trimming configuration, backing application, rewind tension)
• Typical supported substrates: printed PET, printed PVC, self-adhesive PE foam, thin PVC, UV-cured, latex, solvent and eco-solvent prints, banner, canvas, floor graphics
• Warranty: 5-year warranty applies provided a service agreement is in place
