The panel-mount BD series stores 32 different sounds in one unit conveniently arranged for playback suitable in noisy factories.
* Size: 80mm square.
* 32 sounds are pre-recorded in one unit.
* 3 sound types are available.
* Maximum output level of 90dB at 1m is suitable for use in noisy factory.
* Sound volume and sound group can be selected by rotary switches stored behind the front cover for easier operation.
* Select one sound group from A to P to play back 4 pre-recorded sounds (bit input).
* Body color is available in ivory white and dark gray.
Available by Special Order
* Binary input controlled 15 sound playback type (C0090).
|
|
The panel-mount BK series stores 32 distinctive sounds in one unit, and 95dB high sound pressure is ideal for use in a noisy factory.
* Size: 120mm square with low profile body
* Available in 12-24V DC, 100V AC and 220V AC versions
* 32 sounds are pre-recorded in one unit
* 4 sound types are available
* Maximum output level of 95dB at 1 meter is suitable for use in a
noisy factory
* Sound volume and sound group can be changed by rotary switches
stored behind the front cover even after installation
* Select one sound group to play back 8 sounds by bit input or 32
sounds can be played back by binary input
* Body color is available in ivory white and dark gray
Available by Special Order
* PNP open collector transistor type
|
|
Over the last 15 years the AlertAlarm and AlertAlight ranges from E2S have become the standard for industrial signalling. With outputs from 104dB(A) to 126dB(A), the ranges provide heavy duty signals which are ideal for fire, security and industrial process applications.
Combining the alarm sounder of the AlertAlarm range with the L101 series beacon, the AlertAlight range provides a versatile audible and visual signalling solution.
Features:
- 32 or 45 tones (meeting European Standards)
- Outputs from 104dB(A) to 126dB(A)
- EN54-3 tested CPD compliant
- 3 stage alarm option
- UL listed versions available
- ABS UL94V0 housings
- Sealed up to IP66
- Available with 5 Joule Xenon, filament bulb or L.E.D. beacon (AlertAlight range)
|
|
The SpectrAlarm range from E2S has been designed to offer high performance audible and visual signalling in a single unit. Sound outputs of up to 126dB can now be combined with a powerful beacon from a choice of rotating mirror, flashing xenon or LED technologies.
Features:
- Three sizes of sounders: 112db(A), 119dB(A) and 126dB(A) @ 1m
- Three types of beacons: 5J and 15J Xenon strobe, multifunction LED, 20/25W and 35/40W rotating halogen beacon
- 45 alarm tones (UKOOA/PFEER compliant)
- 3 stage alarm option
- Volume control
- Automatic sounder synchronisation on multi-unit systems
- Beacon manufactured from UV stabilised polycarbonate
- IP65
- The sounder and beacon can also be connected separately
|
|
Federal Signal introduces the Model LP4 low profile, electronic piezo sounder. The LP4 is a compact multi- tone sounder ideal for OEM and general alarm applications.
- Operates on 9- 28VDC
- Choice of 28 tones
- Produces 82- 100dBa @ 10' (92- 110dBa @ 1m)
- Compact size - 3" tall x 3.66" wide
- Panel or wall mount
- PLC compatible
- CE Compliant
- Type 4X, IP54 (IP65 with optional deep base)
|
|
For optional installation in signalling devices. Cabinet of aluminium.
- Load rating: 25W
- Impedance: 8 Ohm
- Sound pressure level (1W/1m): 105dB / 112dB @ 1500Hz
- max. Sound pressure level (1W/1m): 120dB
- Frequency range (-10dB): 620-12000Hz
- Transmission angle: 90° / 90°
- Dimensions (mm): 110x80
|
|
|
|
|
|
Multi-Tone Sounder in Unique Design
The Multi-Tone Sounder 144 is an ideal complement to WERMA’s existing product range, impressing with its high sound output and simple mounting. During the development of this audible signal device special emphasis was placed on an elegant but nonetheless functional design suitable for an industrial setting.
114 dB sound output for a wide range of signalling
In operation the new Multi-Tone Sounder generates a sound output of 114 dB. A total of 32 different tones are available for a diverse range of applications. In addition to continuous and alternating tones in a range of frequencies, a large selection of defined, international signal tones are also available.
The tones can be quickly and simply set via DIP-switches, furthermore, 3 tones can be triggered externally via separate terminals.
Simplest possible mounting in 4 steps
WERMA consciously designed the Multi-Tone Sounder and the optical-audible combination in order to ensure quick and easy mounting in just 4 steps: Simply fix the base in the required position, insert the connection cable and attach. Finally, snap the upper part of the sounder into place and secure it to the base with the screws provided.
The different mounting options (wall, floor or ceiling mounting) guarantee optimal sound propagation for the Multi-Tone Sounder as well as the best possible visibility for the LED double flash.
|
|
|
|
|
|
Sonos Beacon (DC)
A general purpose beacon for fire, security and industrial applications.
- Simple 'First Fix' installation (no second fix wiring)
- Smooth flow cabling for faster installation
- Quick connect/disconnect
- No locking screw required
- Weatherproof to IP65 (deep base units)
- High efficiency LED beacon consumes less than 5mA
- Low current LED beacon as standard (xenon beaconavailable on request)
Overview
A general purpose beacon for fire, security and industrial applications.
With the TimeSaver base, connections are made to the base during the initial wiring phase which results in faster and more reliable installation. The beacon head 'twists and clicks' into the base on commissioning, avoiding the wiring and connection problems associated with traditional beacons.
Deep base units have weatherproof protection to IP65 and can be used in all locations both indoors
and outdoors.
The Sonos Beacon utilises a full faced, translucent case which provides a much larger lens area and a greater spread of light.
Sonos Beacon units have a red colour base as standard and are available with a red or amber lens.
|
|
|
|
|
|
Multi-Tone Sounder 139 and 141 and
Flash/ Multi-Tone Sounder Combination 439 and 441
Whether in automated equipment or building installations, across a diverse range of industrial and commercial settings, audible and optical-audible signals are indispensable in today’s world.
Loud multi-tone sounders 139 and 141 with 32 different tones
The multi-tone sounders 139 and 141 from WERMA Signaltechnik provide 32 different tones and frequencies for a diverse range of applications. In addition to continuous and alternating tones in a range of frequencies, the new multi-tone sounders also provide a large selection of defined international standard tones. The sound output can be adjusted in accordance with the ambient noise up to a level of 110 dB (Multi-Tone Sounder 141), or 105 dB (Multi-Tone Sounder 139).
Multi-tone sounders in combination with light intensive xenon flash
Many applications call for the reinforcement of the audible signal by an optical signal. WERMA’s optical-audible combinations 439 + 441 provide the optimum solution: A loud multi-tone sounder in combination with an intensive xenon flash.
These flash/multi-tone sounders, in addition to an innovative and attractive design, can also generate a flash energy of up to 2.5 Ws (Combination 441), or 1.6 Ws (Combination 139). In addition, 2 tones can be triggered externally and the optical and audible signals can also be triggered separately.
|
|
|
|
|
|
|
The sirens are used as alarm, warning or signalling devices. Thanks to theircharacteristic siren wail, they generate an unmistakable and penetrating alarm. The high volume of the wail and ist allround directivity guarantee, that a suitably large range is attained. The different sizes and versions of the sirens open up a broad range of applications, including signalling for critical situations. Used with the protection cover available as optional extra, the sirens are suitable for outdoor use. Sirens for special voltages and frequencies are available on request. The housings are made of aluminium die cast and coated in light grey with weatherproof paint. The protection cover for the sirens F0 and FI is made of weather-resistant plastic. The protection covers of the other versions are made of sheet steel and coated with weatherproof paint. When using a protection cover, the motor conforms to protection degree IP 44 and the siren housing to IP 22. The sirens are designed for short-time operation S 2 –15 minutes according to VDE 0530, Part 1. For the power supply connection the sirens F0 and F1 are equipped with a cable gland Pg 9 and the types FII – FIIIb with a cable gland Pg 13.5.
|
|
The EWH/EWHS series horn style audible alarm with large volume is perfect for use in noisy factory.
* 32 sounds are pre-recorded in one unit.
* 3 sound types are available.
* Large sound volume up to 105dB at 1m is adjustable with volume control, perfect for use in noisy factory.
* Available in 12/24V AC/DC, 48V DC, 100V AC and 200V AC versions.
* Meets water and dust-tight IP65 construction.
* NPN transistor open collector compatible (for EWH series, 24V type only)
* Universal stainless steel mounting bracket permits easy installation in any location.
EWH: Select one sound group to play back 8 sounds (bit input);
32 sounds can be played back (binary input).
EWHS: Select one sound by dip switch from 32 pre-recorded sounds.
|
|
|
|
|
|
E2S offer a range of solutions for disaster and outdoor warning such as toxic gas release, flood warning, tsunami alert, civil defence, tornado and weather warning, wide area fire and security alert.
With a choice between traditional motor driven "air raid" sirens and multi functional electronic sirens, E2S have the solution for your application.
CS disaster warning siren
Our CS disaster warning siren has sound outputs up to 125dB @ 30m (>150 dB @ 1m) and can include numerous options:
- Battery Backup
- Silent Test
- Fault Diagnostics
- Software Control (RS232, RS485, TCP/IP)
- Radio Control using secure digital telemetry
- Voice Messaging using both pre-recorded or live voice
A140
Our A140 disaster warning alarm sounder is a compact high powered unit with an effective range of approx. 1km, having a maximum output of 140 dB(A) @ 1m. The features of the A140 disaster warning sounder are:
- 32 alarm tones, 3 alarm stages
- Lightweight fibreglass housing
- Automatic synchronisation
- Ideal for battery back-up applications
- IP55 protection
- Fully programmable version available (4 alarm stages)
|
|
The Federal Signal Model A is a general- purpose electro- mechanical siren that produces a distinctive sound and tonal quality for industrial applications. It has a high maximum pitch which provides excellent contrast to industrial ambient noise. Introduced in 1918, the Model A is still used today in many rugged and extreme environments and applications.
- Available with 120VAC/VDC universal motor
- Rugged, durable and corrosion resistant
- Maintenance- free
- Produces 103dBa @ 10' (113dBa @ 1m)
- Type 3R enclosure
- UL and cUL Listed, FM Approved
|
|
Federal Signal's Model DSA Directional Speaker Array provides excellent voice and tone reproduction and is ideal for overcoming high levels of industrial noise. Design flexibility allows the user to combine up to four speaker arrays; each array will hold from two to six re-entrant speakers. Speakers have a 70º horizontal angle of dispersion, accommodating specific sound output patterns. Ideal for outdoor industrial plant warning, the Model DSA speaker array allows sound coverage to be customized to each site, preventing wasted sound level in and around the plant.
- Overcomes ambient noise of industrial environments
- Provides maximum speech recognition and tone reproduction
- Produces 121dBc @ 100'
- Three mounting kits available
|
|
|
|
|
|
Famous rotary sirens of prevention of the risks diffusing alarm at long distances within the framework of Private individuals Plan of Internal intervention and Plans of operation.
Alarms with the population, municipalities, prefectures, building sites, refineries, barracks, careers with open sky, factories, communities, administrations, army, prisons, airports...
ASSETS
> Diffusion of the sound on 360° thanks to the houses
> Its modulated by the automat included/understood in the electrical power box
> Aluminum robust alloy construction
> Polyphase motor conforms to the standards: UTE C51 100 and C 51.102
> Number of revolutions of the engines: 3000 rpm.
> Easy installation
> Reduced maintenance
Accessories: latticed ends - houses - latticed hearing - latticed crown
Options: tropicalization - rilsanisation - protection saline air - seaworthy packing - explosion-proof engine
Certain models also exist with food 220 Vca single-phase current, to consult us.
The houses allow a longer range of the sound of 10%.
References 23850/23851/23852 do not comprise houses.
Each cupboard is carried out according to the sound needs.
|
|
|
|
|
|
Powerful helped and supervised alarm system. Modern and functional, it has varied modes of release.
Frequently used for the prevention of climatic catastrophes...
Km ALERT is made up of a box and diffusers food helped in conformity with standards EN54-4 and NFS 61940
Functioning is in:
> KM ALERT NR: Its of the code alerts national (SEVESO decree 90-394) (300/600 Hz) and of the sound of end of alarm (380 Hz) and of the sound of test.
> KM ALERT E: Its of evacuation sets fire to (AFNOR NFS 32001)
(440/554 Hz) and of the sound of alarm sets fire to (440 Hz).
> Km ALERT b: Its of national alarm stopping (decree 90-918)
All km ALERT have the 3 sounds
- Alarm
- End of alarm
- Test
Consumption of a diffuser: 200 Watts
Hull of the glass fiber diffusers
High index of protection: IP 55
Telephone release in option
Capacity battery: 18 Ah
Autonomy: 30 hours in day before and 15 minutes out of alarm
Section of cable for releases: 0,75 mm ² SV1V
Facility of assembly and connection
Temperature of - 10 with + 40°C
Moisture from 50 to 85%
|
|
Electronic sirens KMP diffuse audio and vocal preregistered but such direct messages by microphone (Public Address).
These sirens are used for the prevention of the risks natural and industrial (PPI/POI).
Studies personalized by our engineering team.
The siren is made up of the diffusers, of the amoire of order with amplifiers of 300 with 3000W according to the desired sound power.
The control system with screen LCD and microphone announces a synthesis of defects and can diffuse all the types of sounds (AFNOR, SEVESO...) and text messages (recording on chart SD thus modifiable).
Basic configuration: 2 diffusers in omnidirectional or directional assembly.
The sirens are fed in 230Vac. 2 batteries of 12V ensure the emergency power supply of the system which is autonomous 72 operating hours.
|
|
Motor Driven Sirens
Duplo
The Duplo is a powerful motor driven siren which produces a very high sound output despite its physically compact construction.
- High output siren sound (127dB)
- Rugged construction for use in all environments
- Long life and run time
- Low voltage DC and high voltage AC for use in all applications
- Weatherproof to IP65
- Mounting bracket for ease of installation
Overview
The Duplo is a powerful motor driven siren which produces a very high sound output despite its physically compact construction.
With its weatherproof design, the Duplo can be used both indoors and outdoors for security, fire alarm, process control alarm and general safety warning.
Due to its rugged construction, the Duplo be used in arduous conditions including mining and quarrying
applications.
The Duplo has a continuous rating and has been designed for longevity
|
|
GN 4 SERIES
Lift bitonal electronic alarms.
* High sound level.
* LED light warning.
* Power supply 6-24 V dc
* sound level (dB at 1 m): 90 dB at 6 V or 110 dB at 12 V
* frequency (Hz): 2.500
* wall bitonal lift alarm (dim. 104 x 88 x 30 mm)
GN 4/I SERIES
Lift bitonal electronic alarms.
* High sound level.
* LED light warning.
* Power supply 6-24 V dc
* sound level (dB at 1 m): 90 dB at 6 V or 110 dB at 12 V
* frequency (Hz): 2.500
* embedded bitonal lift alarm to mod. 503 box
GN 5
Lift bitonal electronic alarms.
* High sound level with any voltage.
* LED light warning.
* Power supply 5-24 V dc
* sound level (dB at 1 m): 118 dB
* frequency (Hz): 2.500
* wall bitonal lift alarm (dim. 104 x 88 x 30 mm)
|
|
* Fully enclosed motor
* Weatherproof
* Adjustable siren direction
* AC or DC operation
Heavy duty, industrial design, motor driven siren that emits a continuous loud piercing wail.
Mounts to any solid surface using two bolts. May be swiveled through 180°, vertically or horizontally, depending on orientation of bracket.
|
|
Electronic alarms and multisound sirens
Description
Simplicity and speed of installation thanks to pre-cabled and pre-assembled products
Manufactured in conformity with the requirements of the RoHS (Restriction of Hazardous Substances) European Directive.
Electronic alarms
Each unit contains 16 sounds
Panel mounting. DIN standard installation
Up to 90 decibels in a compact size
Simple volume adjustement (0 to 90 dB) thanks to an easy front panel access
IP 54
Panel color: black or white
Standards and certifications: CE, UR.
Sirens
All 43 alarm sounds can be controlled by external signal
Up to 105 dB in a compact size
Registration mode to choose and register the sounds of your choice
Easy volume adjustment and sound switching without using tools
IP 53
Standards and certifications: CE, UL.
|
|
* AC model 122 dB @ 100 ft. (30.5 m)
* DC model 125 dB @ 100 ft. (30.5 m)
* Omni-Directional
* Continuous duty motor
* 8 horn, equal length, dual row
Designed for medium or small, growing communities this siren is a true workhorse. It is also our most popular dual tone siren. Rated at 122 dB, the Cat. No. EWS-V6 is an omni-directional siren which produces continuous 360° coverage, making it a superior alternative to a rotating siren. The Cat. No. EWS-V9 is a battery powered version of the EWS-V6. The EWS-V9 includes a motor starter, charging system and battery box.
|
|
TS 85 P and CITY are the new family of self-protected electronic sirens of AVS Electronics. The new design has been projected in modern and elegant shapes.
Characterized from the same design they are different in the dimensions : TS85P has space for a max. battery of 7 Ah, while the most compact CITY has space for a maximum. Battery of 2 Ah. On both models it is also reserved a wide space that following the installer customize the cover with the company logo.
TS85P and CITY are individually 100 % computer tested in order to grant the usual AVS Electronics reliability.
|
|
AE&T proposes to you a broad choice of electronic or electromechanical sirens of power.
The powers of our sirens are spread out of 130 with 155dB brought back to 1m.
Only, in bunch or rises on a mast, our sirens cover the whole of your requirements in term for evacuation and alarm:
- Evacuation in noisy industrial environment
- Diffusion of the national sound of alarm
- Alarm with the populations
- etc
Range:
T130: electronic siren of 130dB with 1m
- 64 sounds with the choice (of which the sound of alarm national) freely programmable
- possibility of making of the Address Public
- IP54
T140 Siralert: electronic siren of 133dB with 1m
- 32 sounds with the choice and its of alarm national
- IP 53 and IP56
T145 Siralert: electronic siren of 136 with 155dB with 1m
- Diffusion of sounds and messages personalized of which the national sound of alarm
- possibility of making of the Address Public
AT3/AT4: siren with multidirectional turbines of more than 140dB with 1m
|
|
The siren to guarantee its efficiency, must be installed in an extremely visible place, both if it is mounted outdoor or indoor. This envolves an aesthetic impact that increases insofar as the building has details of aesthetic and architectonical value.
For this reason, the Tecnoalarm sirens have been the first components of the product range that have been redesigned, in cooperation with Pininfarina, in order to transform them into objects of design and improve significantly their integration into any environment.
The series SAEL for outdoor mounting includes a version for wireless installation, whereas the sirens SIREL for indoor mounting are available in several versions: traditional, with acoustic signaling only or white stroboscopic flashing light.
|
|
The siren to guarantee its efficiency, must be installed in an extremely visible place, both if it is mounted outdoor or indoor. This envolves an aesthetic impact that increases insofar as the building has details of aesthetic and architectonical value.
For this reason, the Tecnoalarm sirens have been the first components of the product range that have been redesigned, in cooperation with Pininfarina, in order to transform them into objects of design and improve significantly their integration into any environment.
The series SAEL for outdoor mounting includes a version for wireless installation, whereas the sirens SIREL for indoor mounting are available in several versions: traditional, with acoustic signaling only or white stroboscopic flashing light.
|
|
|
EAO buzzers with up to 95db with continuous or intermittent tone and protection up to IP 65. The buzzer can be modified with bezels for raised or flush mounting.
|
|
The IS-mC1 combined alarm sounder & L.E.D. beacon has been designed for installation in intrinsically safe environments (Zone 0). The IS-mini range also includes stand alone intrinsically safe alarm sounders and L.E.D. beacons and is definitely the most effective method of signalling in Zone 0.
Features:
- Zone 0, 1 & 2
- EEx ia IIC T4 (Tamb.-40 to +60°C)
- Maximum 100dB(A) output
- 49 alarm tones, 3 alarm stages
- Array of 6 high intensity L.E.D's
- Sealed to IP65
- ATEX, FM, IECEx
|
|
Bus scheduler
The G0700 scheduler can centralise several "sub-stations" or several buildings via BUS.
These "sub-stations" can be made up of J3000 or J3500 alarm panels. It is therefore possible to maintain local processing and signalling (multitask function and downgrade mode).
The centralisation can be RS485, RS422 (2 wire, 4 wire) type, Modbus RTU or Jbus.
Other links possible: optic fibre, modem, ETHERNET.
Standard centralisation possible 1Km, 620 inputs.
The G0700 carries out the following functions:
- Controls the presence of the modules on the bus
- Sends alarms towards one or more other buildings.
- Displays alarms on other carry panels or on PC screen.
- Prints text and date “on the fly”.
- History backup on compact flash card
(option G0200 Printer Memory).
- Transmission of information to supervisor or automat.
- Reproduces the alarms transmitted by the supervisor or the automat on the indicator panel.
Applications:
- Industry, Airports, Hospitals, administrative buildings.
|
|
|
|
