AP&T´s niche tools and production solutions are available in product areas like deep drawing, fire extinguishers, heat exchangers, air duct parts, pressure vessels and filter housings. We also manufacture complete assembly lines for microwave oven cavities. 3-5 operations in separate machines. Manually or semi-automated lines. Hydraulic, pneumatic and servo powered.
|
|
Industrial production line of condensers entirely automated and robotized, calling upon:
* 10 robots,
* a table XY of 15 m ²,
* 5 control systems per vision,
* 2 welding machines ultrasound,
* 9 vibrating bowls.
|
|
Line of assembly of limp of cellular culture
This line of assembly is articulated around an intelligent transport system made up of shuttles on monorail in closed loop. The prints of the shuttles receive the products to be assembled. The shuttles stop at each station described hereafter, where the various stages of assembly are carried out:
1. Deposit bases by a robot
2. Treatment of the bottom of the base
3. Deposit lids on the bases
4. Welding ultrasound of the lid on its basis
5. Leak test of the bottles
6. Clipsage of the cap on the neck of the bottle
7. Ejection of the bad bottles
8. Plugging of the graduation
9. Transfer of the bottles on a conveyer of exit
|
|
|
|
|
|
Assembly lines
The Dynamic Assembly System (DAS) is a modular factory platform for light assembly, inspection, test, repairing and packing applications. DAS combines flow oriented dynamic production control and modular automation for increased production efficiency. This modular automation platform includes a range of standardized modules as workstations, conveyors and flexible buffers. Robot cells can be integrated into the line.
The goods are transported on product carriers with a RFID tag. It includes our flow management software "Youtilize" to execute orders, route the product carriers, gather quality data, handle stock and provide electronic work instructions to operators. Both the plug-and-play modules and the product carriers have their own embedded intelligence.
Modularity standardized communication allows step-by-step automation.
It is easier to add features to the assembly line when needed. Features are easily tested offline and testing is not interrupting production. The integrated modular system from FlexLink is effective, requires minimum
maintenance and is easily adjustable to changing needs in the production process.
|
|
Complete production lines.
(Small islands) of assembly made up of, FIFO, support work stations of press and screw driver for the assembly in great series in the mechanical engineering industry.
|
|
-assembly systems, lines and devices,
-armature and stator winding machines,
-testing systems and equipment
|
|
Amongst the characteristics of our machines, such as the industrial design and ease of operation, one of the key aspects is modularity, a feature that facilitates installation of sizeable systems within only a few hours.
Our modular designs also have the consequence that installed systems can be versatile owing to their upgradability. Individual stations of sections of a modularly-designed system can be upgraded or developed to take advantage of new technical advances.
|
|
Reliable, high-performance systems for the assembly of micro-technology parts
Automation expert with over 40 years experience, mta builds on its highly-qualified people as well as on its unique know-how especially in the soldering and dispensing processes, to provide the best turnkey assembly system solutions to its customers.
Thanks to mta's R&D department, its techniques, products and services are constantly adapted to the market developments and the needs of its customers.
mta production units based on rotary tables or semi-automatic or fully automatic lines have, to date, assembled, soldered, dispensed and tested several billion parts throughout the world.
|
|
The Linear Type System represents high-performance solutions with unlimited possibilities.
The principle:
At 64 individual operation procedures per cycle, at 80 cycles per minute, it’s possible to assemble even intricate elements economically. This technology is based on single cam driven stations which are being synchronized by an upright shaft. Available in up to 4-track versions, the linear type, run with targeted flow of material, comes as a high-performance device with a turnout of 320 parts per minute, at an elevated output level.
* Multiple lines of products or product variants
* High flexibility by the use of exchangeable as well as connectable and disconnect-able stations
* Integration of several processes, such as printing, corona treatment, bagging, hot stamping, sealing, ultra-sonic-welding, and of course much more
* A concept that is based on a proper flow of materials
* From raw material to finished product
|
|
bott workplace systems meet all the requirements for flexibility, modularity and functionality. Our workplace systems can be adapted to your individual specifications.
Basic modules with adjustable working height, runners/castors and cable/hose reels ensure that everything you need is always ready to hand. bott creates for you an absolutely flexible and ergonomic working environment. All components of our workplace systems are designed to be adaptable to staff needs and tasks. The result is custom single or group workstations which simplify all working processes.
|
|
Technical data and special features
Ability to run new part variants without retrofitting
Installation location: Ontario, Canada
Assembly line footprint: 10 x 4 m
Servo-driven cam-indexing conveyor system
Compact machine layout
Flexibility for new programs
Part dimensions: 850 x 650 x 700 mm
Cycle time: 7 Sec
11 Automatic stations
2 Manual stations
|
|
Description
The outstanding features of our LS fast cycling assembly system are:
* Short workpiece carrier changing times
* Modular design
* Completely jerk and impact free motion
* Flexibility: Any combination options
View a LS280 system in action: http://www.ls280.de
|
|
Assembly & Test lines
Assembly and test of a product: a clear target, that often involves considerable technical engagement. MARSILLI proposes its expertise to study together with the customer the process required to reach this target, and to implement it concretely.
For lines with tens of automatic operations for assembly and test, or for a simpler machine (not necessarily less difficult) the MARSILLI approach is always the same: to apply technologies that are part of its know-how, or to develop new ones, to comply with the customer’s requirements.
|
|
Lean Cells
Consistent with its consulting services and manufacturing philosophy in Lean Production, Wes-Tech offers lean cells for Assembly and Testing. In general, Lean Production is a manufacturing system comprising assembly cells, pull system methodology, 100 percent acceptable quality, consistent on-time delivery, respect for people, and maximum utilization of non-depreciable resources, i.e., people and raw materials.
Typically, for intensive assembly operations, lean cells become an integral part of the entire automation solution. In general, such solutions create Manufacturing Cells operating at a high ratio of automated-to-manual work content.
In cases where assembly and testing operations require relatively light automation (just enough to ensure process capability), and where the most cost-effective solution requires manual work content, the preferred solution is typically a semi-automated lean cell. Wes-Tech refers to such cells as Ergonomic Lean Cells.
|
|
Workstations and Automated Assembly Lines
BalTec (UK) Ltd specialises in the design and manufacture of quality workstations for fastening processes incorporating BalTec Presses, BalTec Riveting machines and Screwdriving Technology.
We are also continually working towards improving our assembly line products and customer service to provide the best possible solutions to all industries. This goes hand-in-hand with our policy that all our customers - however big or small, new or old - are looked after with equal professionalism.
Automated Assembly Lines
Our innovative design team together with our experienced engineers are able to constantly improve on existing, proven principles, by integrating proprietary equipment with our own to give you the automated assembly solution necessary to reduce your manufacturing costs.
|
|
|
|
|
|
Mikron Assembly Technology is the leading manufacturer of customized, high performance, high output assembly and test solutions for products that you canhold in your hand.
The systems are class 10,000 cleanroom compliant and, for medical/pharma applications, Mikron offers qualification in line with GAMP/FDA guidelines.
Mikron is active in the following main markets:
Automotive industry, Medical industry, Telecommunication, Electrical components, Consumer goods
Product Family
G05™ assembly systems:
Mikron linear assembly systems are based around two highly standardised cells: G05™ Linear Assembly and G05™ Assembly Center. They operate at up to 100 cycles/min, with the possibility of 60% reusability and ease of adaptability for new variants. The range gives the possibility of manual, semi- and fully-automatic cells, offering perfect customisation and progressive investment for individual customer needs.
G05™ feeding systems:
G05™ Polyfeed is an innovative flexible feeding system offering speeds of upto 60 cycles/min using vision based parts recognition and specially designed to integrate in Mikron assembly systems. G05™ Palletizer is a palletizing system for handling trays up to 400x600 mm.
|
|
|
|
|
|
Mikron Assembly Technology is the leading manufacturer of customized, high performance, high output assembly and test solutions for products that you canhold in your hand.
The systems are class 10,000 cleanroom compliant and, for medical/pharma applications, Mikron offers qualification in line with GAMP/FDA guidelines.
Mikron is active in the following main markets:
Automotive industry, Medical industry, Telecommunication, Electrical components, Consumer goods
Product Family
G05™ assembly systems:
Mikron linear assembly systems are based around two highly standardised cells: G05™ Linear Assembly and G05™ Assembly Center. They operate at up to 100 cycles/min, with the possibility of 60% reusability and ease of adaptability for new variants. The range gives the possibility of manual, semi- and fully-automatic cells, offering perfect customisation and progressive investment for individual customer needs.
G05™ feeding systems:
G05™ Polyfeed is an innovative flexible feeding system offering speeds of upto 60 cycles/min using vision based parts recognition and specially designed to integrate in Mikron assembly systems. G05™ Palletizer is a palletizing system for handling trays up to 400x600 mm.
|
|
Assembly systems to application specifications
* Modular assembly lines and hybrid systems on the basis VARIOMODUL®
* Assembly machines with individual degrees of automation
* Automatic assembly systems (circular indexing machines, robots)
* Integration of laser machining
* Integration of function test stands
|
|
4-Component Ball Plunger Assembly Machines
1,000 parts per hour
Our assembly machine automatically loads four components and assembles them into the final product. Integrated checking of final assembly with automatic sorting - during unloading - is one of many key features of this assembly machine. System includes five bowl feeders for automatic loading of all components, handling a wide range of ball plunger sizes. Custom machines also available.
|
|
We conceived the Servo Cell as an introduction to automated manufacturing worth the money.
The principle:
Part of intricate assembly stations is carried out by manual work, but – simultaneously - time- and quality-relevant operations are executed fully automated on the machine. An assorting quality check is controlled by the machine, which will identify flawed parts and treat them as such in order to avoid any waste of material. The technical design of the Servo Cell can be widened modular-like: In that case, manual work places are also automated, just via docking to an extra Servo Cell. Naturally, the Servo Cell comes as a highly re-usable product.
* Semi-automated production of 0-series
* Increased numbers of production which cannot be covered by manual working places alone
* Line production for an annual output quantity of up to 500.000 pcs
* Checking the assembly possibility of the product – Proof of Principle (POP)
|
|
Modular systems for flexible and customized automation
We develop and manufacture complex system solutions for assembling products of up to a 0.5m³ cubage for the automotive industry and the respective components supplying industry as well as the micro-engineering / micro-optics industry. We also design, layout and supply unique complex assembly systems of modular design meeting high quality standards. For example, we develop the following systems:
JENOMAT for airbag modules
JENOMAT for electrical heating elements
JENOMAT for gear modules
JENOMAT for fan components
JENOMAT for engine mountings
JENOMAT for optical fibers
JENOMAT for intake tubes
JENOMAT for flashing lights
|
|
|
|
|
|
automated assembly center
Mikron Assembly Technology is the leading manufacturer of customized, high performance, high output assembly and test solutions for products that you canhold in your hand.
The systems are class 10,000 cleanroom compliant and, for medical/pharma applications, Mikron offers qualification in line with GAMP/FDA guidelines.
Mikron is active in the following main markets:
Automotive industry, Medical industry, Telecommunication, Electrical components, Consumer goods
Product Family
G05™ assembly systems:
Mikron linear assembly systems are based around two highly standardised cells: G05™ Linear Assembly and G05™ Assembly Center. They operate at up to 100 cycles/min, with the possibility of 60% reusability and ease of adaptability for new variants. The range gives the possibility of manual, semi- and fully-automatic cells, offering perfect customisation and progressive investment for individual customer needs.
G05™ feeding systems:
G05™ Polyfeed is an innovative flexible feeding system offering speeds of upto 60 cycles/min using vision based parts recognition and specially designed to integrate in Mikron assembly systems. G05™ Palletizer is a palletizing system for handling trays up to 400x600 mm.
|
|
|
|
|
|
AGME design and manufacture rotary table assembly machines with AGME standard equipment incorporating the most modern technology in the automation industry. These special machines allow components to be transferred to different work stations with a rotary movement and they are designed to manufacture our customer’s parts in the most cost effective way.
AGME rotary transfer machines carry out a wide range of forming and assembly processes: simple operations of pressing, riveting and marking as well as more special operations like bush or spring insertion, tube forming, bending, flaring, crimping and screwing. These work modules can also incorporate automatic feeding systems, positioning and adjustment units, robots, subassembly control and test stations and all necessary fixtures. These special modules can be automatic or semiautomatic with one or two manual loading station.
These machines require minimum adjustments and are fully automatic. Thanks to the process controller in the machine it is possible to eradicate human error and provide savings on cycle time and quality
|
|
VELOLINE is the new linear pallet base system completely mechanically controlled and manufactured by VELOMAT.
An innovative system of transmission operates the indexed motion of the conveyor. The cams directly engage the pallets, ensuring absolute precision and repeatability of position. The precision, experience and accuracy guaranteed by COLOMBO FILIPPETTI in the manufacturing of components, allows high speed operation with intermittent high velocity motion, smooth and without vibrations. The pallets are made of aluminium and their shape or dimensions do not depend on the conveyor. There is the possibility to choose stroke, number of pallets and index time.
We can supply it for operation in any orientation, with pallets facing vertical or horizontal. The space between the sides of the pallets is sealed with a rubber seal to keep out dust and debris.
|
|
VELOMAT 500 SYNCHRO is the new rotary base assembly system manufactured by VELOMAT. Consisting of mechanical controlled manipulators and an indexing rotary table. The base system is characterised by a single motor, operating both indexing table and manipulators in an absolutely synchronised motion. The pick and place motion of the manipulators is obtained by the synchronised motion of two reciprocating plates that are controlled by a Colombo Filippetti cam mechanism. Thanks to mechanical synchronised motion and to the small masses moved, the base system VELOMAT 500 SYNCHRO is able to offer many features such as: precision, high speed, low vibration, quiet motion, and absolute repeatability of movement. VELOMAT 500 SYNCHRO is the solution to assembling that requires precision, reliability, low costs and high production rates.
|
|
VELOMAT SRL is the leading base machine manufacturer for high production automated assembly applications.
VELOMAT machines are created by incorporating the line of patented quality components manufactured by COLOMBO FILIPPETTI with VELOMAT experience in the assembly automation field.
VELOMAT 1000 Synchro is a rotary base machine completely mechanically operated and manufactured by VELOMAT. The pick and place motions of the individual manipulators is obtained from the rotary indexing table, operated by a Colombo Filippetti cam mechanism following optimised kinematic laws of acceleration and deceleration. The final movements being extremely smooth, precise, and without vibration. The main characteristics that distinguish VELOMAT 1000 SYNCHRO are: high rigidity of the manipulators, high flexibility and vast ranges of cycles, high weight carrying capacity, adjustable strokes in horizontal and vertical direction, and high production rates.
|
|
Technical Info:
- Feed, pick and place
- Integrating diverse functions
- Output 30 - 120 ppm
- Flexible and re-configurable
- Reliability and robustness
- Process Integration
- Bespoke functionality
- Attractive payback
|
|
SANKYO BH Series Linear & Rotary Assembly Base Machine
- Cam driven: accurate, high speed, high capacity, reliable
- 0 to 90-cycles per minute continuous or cycle on demand
- 6 to 24 indexing dial stops
- 0 to 12 came driven linear handlers
- Lift stroke 0~50mm, extend stroke 0~60mm (custom free)
- 90 to 330 degree index period
- Sychronized linear & rotary motions with 1 motor
- Linear precise motions with ±0.02mm accuracy
- 1-input shaft revolution equals 1-full cycle
- Clutch-brake drive up to 80 stop/starts per minute
- Multiple timing sensors, adjustable, for interlock/stop motor
- Optional quick adjust torque limiter with overload sensor
- AC, DC, UL/CE approved, explosion-proof, motor drives
|
|
- Focus your engineering resources on the most strategic expertise in the project.
- Cam driven systems are our core business while designing and making efficient and reliable transmissions is our daily mission.
|
|
|
|
