Positive Locking Brackets
Promount's superb range of PAC positive locking brackets set the industry standard for mounting tools on military and emergency vehicles and in a multitude of applications in the workplace or at home. Whereas webbing straps will loosen over time, and tools are at risk from being scratched and damaged, these non-corrosive tool mounts hold the tool firmly on all sides, using non-scratch and highly specced polymers and GRP Plastics
|
|
ITW TekFast Brackets offer our customers unique, cost effective alternatives to traditional metal-formed bracketry.
Key benefits of our plastic bracket designs:
- Cost Effective - Plastic molded parts offer high value, low cost, yet maintain structural integrity.
- Part Number Reduction - Integrated fasteners reduce complexity
- Non - Corrosive
- Ergonomic - Snap fit, reduced installation efforts, user friendly designs.
- Performance - Designs suitable for high strength, high temperature applications.
- Function - Design flexibility offers solutions for virtually any application.
|
|
|
|
|
|
Bluid-in Zeropoint Quickclamping cylinder K10, K20, K40, square
Hydraulic release
Cover and piston hardened
Repeat accuracy < 0,005 mm
Assembling diameter: K10: Ø50mm, K20: Ø78mm K40: Ø102mm
Max. pull in force 40 kN (hydraulic)
Max. pull in force 30 kN (pneumatic)
Max. holding force 105 kN
Use:
Can be used as a single clamping point or combined with round installation Zeropoint Quickclamping cylinders in base plates, machine tables, clamping profiles, columns and towers, swivel bridges, machine pallets and clamping pallets. A square Zeropoint Quickclamping cylinder prevents the pallet from twisting. The indexing function enables positioning every 90°. Specially suitable for use in turning.
Note:
The installation Zeropoint Quickclamping cylinders have high holding and pull-in forces with very small installation dimensions. Hydraulic pressure is only needed for unclamping (min. 50 bar / max. 60 bar). The Zeropoint Quickclamping cylinders are mechanically locked in the clamped position. The advantages of this are that there are no cumbersome lines and no danger of leakage. Square pallet for screwing onto the pallet see item no. 6370ZA.
On request:
- Installation diagrams on request
- Automation solutions such as media ducts, sensor of locking monitoring, blowing off and isolated applications
|
|
|
|
|
|
Bluid-up Zeropoint Quickclamping cylinder K10, K20, K40, square
Hydraulic release (or pneumatic)
Cover and piston hardened
Repeat accuracy < 0,005 mm
Size: 85x85mm, 120x120mm, 150x150 mm
Pull in force 40 kN (hydraulic)
Pull in force 30 kN (pneumatic)
Holding force 105 kN
Use:
Can be used as a single clamping point or combined with round surface-mounted Zeropoint Quickclamping cylinders in machine tables, clamping profiles, columns and towers, measuring machines, assembly stations in connection with clamping flanges no. 6370ZB). Clamping flange size 20 for K10, size 40 for K20, for K40 integrated onto the housing.
Note:
Hydraulic pressure is only needed for unclamping (min. 50 bar / max. 60 bar). The Zeropoint Quickclamping cylinders are mechanically locked in the clamped position. The ad-vantages of this are that there are no cumbersome lines and no danger of leakage. The hydraulic version has 1 connection for clamping / unclamping (G1/4 or G1/8). Square pallet for screwing onto the pallet see item no. 6370ZS.
On request:
- Automation solutions such as media ducts, sensor of locking monitoring, blowing off and isolated applications
- Can also be supplied with centering pins for quicker and more precise installation
|
|
Precision, height adjustable, vibration damping machine mounts for accurate, efficient and economical machine installation
Typical applictions: Machine tools, Rubber machinery, Printing and Packaging Machinery, Injection Moulders
|
|
|
|
|
|
Fitting Gas Springs is now Easier than Ever
Arvin Motion Control (AMCL), manufacturers of Camloc Gas Springs, has introduced a new range of mounting brackets for it's industry leading gas spring range.
The new brackets are designed to suit the extensive range of Camloc end fittings, creating a wide range of easy to assemble fixing options.
This flexibility makes AMCL's Camloc products more attractive than ever, combined with our unique Vari-Lift technology, which allows design engineers to vary the gas spring pressure during prototyping.
The brackets are available in a wide range of styles, including 90 degree, flat and raised, the new brackets are drilled to accept M4 and M6 fixings - making it easier to fasten to timber and steel frameworks using screws or dowels. They are designed to accept DIN / ISO standard fixings.
Manufactured in carbon steel with a zinc and yellow passivate coating, the components have passed a minimum of 72 hours salt spray testing under ASTM B117.
The brackets are designed for ease of assembly with ball pins for ball cups and ISO thread for threaded pins for lock nuts and split pins. The brackets combine compact design with strength - offering an extensive force range capability.
Benefits:
- High corrosion resistance, 72 hours salt spray under ASTM B117
- Wide range of styles, including 90 degree, flat and raised
- Designed to accept DIN/ISO standard fixings
- Drilled to accept M4 and M6 fixings
- Cycle tested for standard force capability 800 Newton's
- Ease of assembly with ball pins for ball cups and threaded pins for lock nuts and split pins
|
|
Adjustable Angle Clamp 30
Adjustable Angle Clamp 40
Angle Clamp 30 with Locking Lever
Angle Clamp 40 with Locking Lever
Adjustable Angle 30
Adjustable Angle 40
Turning Angle 30
Turning Angle 45
Pivot Angle 130
Floor Brackets
Steelangles
Alu Connection Angles
Die-cast Zinc Angles
3-way Connection Angles
|
|
| ... products without technical information |
| |
|
|
|
|
General
Suitable for use with DIATEST bore gauges (e.g. split-ball probes) for serial measuring of small parts
Also suitable in connection with special applications, favoured for use together with DIATEST floating holders
Checking stand MST-58
Measuring stroke adjustable from 0 to 33 mm/1.3"
Platen: Ø 58 mm/2.3"
Top of stand continuously adjustable
Maximum height of work-piece including gauge: 140 mm/5.5"
Accessories: clamp-on-vee attachment for positioning of work-piece
Universal stand MST-102
Measuring stroke adjustable from 0 to 130 mm/5.1" with stop
Size of platen: 100 mm x 100 mm/4" x 4" (larger platen available in standard programme)
Different jib arms to hold measuring system
Extensive range of accessories in standard programme
Mini fixture KM
Especially suitable for measuring small work-pieces in combination with BMD plugs
Optimal position due to possibility for adjustments and accessories,
model as gauging station with several mini fixtures side-by-side.
Suitable for multi-plane plugs
|
|
| ... products without technical information |
| |
|
These sturdy fixtures hold thick or thin gauge steel securely in place for optimum welding. Powerful, permanent magnets are mounted in stainless steel housing, and available with an adjustable or fixed 90º angle.
|
|
