IDEALFLEX Cable Carriers
It is a closed cable carrier made of galvanized sheet, which consists of a carrying section and a steel guiding strip which is connected to one of the four sides of this section. This enables only a one-way bend to the side of the steel strip. Bends in the other directions are disabled. It is proven by load tests that nor after 10 million cycles are the cables damaged nor is the flexible carrier worn.
IDEALFLEX meets the technical and safety regulations and complies with the DIN 57113/VDE 0113 standards.
The cable carrier is also resistant to all cooling liquids and lubricants commonly used with machine tools.
Attachment
On both ends of the section, there are stubbed or riveted on flanges which can be attached by several ways. (See the table.)
Cables and hoses which are laid loose in the section must be fixed to both ends of the carrier. To ensure the maximum service life of IDEALFLEX, it is necessary to provide its support or guiding in a channel if the section is long. The length of the channel should be equal to at least a half of the length of elevation. The most suitable attachment of the end of a cable carrier is in the middle of the elevation distance. In this way the shortest length of the carrier and the lowest price can be achieved.
-RM quality (for a low rate of movement) to 20 m/min IDEALFLEX with a steel guiding strip.
- RS quality (for a medium rate of movement)
20 to 50 m/min
IDEALFLEX with a steel guiding strip glued with a special adhesive.
- RV quality (for a high rate of movement) over 50 m/min IDEALFLEX with a synthetic guiding strip glued with a special adhesive
|
|
CC9-1 Standard 23" [584 mm] long when fully extended
CC9-2 Manufactured to order, 29" [736 mm] long when fully extended
Use with round cable
Quick disconnect chassis fasteners
|
|
Various holding systems for fitting cable protection conduits. Individual holders or a stackable system are available.
Type HS (conduit holder)
Conduit holder system made from polyamide, arrangable in rows and stacks. The holder can be screwed on directly. Optional accessories enable the bracket to be adapted to a wide variety of installation situations.
Flexible system
Stackable
Arrangable in rows
Compatible with single holder types UH, UHF and USH
Type HS (accessories)
HS/F >pfeil
de fixation (comme UHF).
HS/U holder is simply snapped onto the footHS/C >pfeil
ning foot (as KAF). Foot can be snapped onto top hat and C-rails.
HS/U holder is simply snapped onto the foot
Flexible system
Stackable
Arrangable in rows
Compatible with single holder types UH, UHF and USH
|
|
Balustrade cable tray
Glass reinforced Polyester (GRP / FRP). Pultrusion. 0% halogen.
designed for structures with guard rail or stair type access
adapted for emergency escape routes and exits thanks to the option of routing cables inside
delivered in 3 to 6 m lengths
|
|
Hot press moulding process enabling a complete range of functions and also a variety of fittings to be produced.
K² is suitable for routing cables over stretches with a complex configuration.
- 9 widths, 3 heights: 19 sizes in stock
- Unrivalled speed of installation by interlocking
- Complete system of fittings
|
|
Slotted Wall Duct
Standard slotted wall Pro-Duct features break-away fingers which provide additional access for wire leads. Each section of the duct is provided with two score lines. The upper score line is used to break away fingers when a greater opening is required. The lower score line allows the sidewall to be smoothly cut for joints and "T's". Certain sizes of slotted wall wiring duct are available in intrinsic blue color. This indicates that the control panel is intrinsically safe - often required in applications where explosive gases exist. Contact HellermannTyton for details and specific sizes of intrinsic blue, slotted wall wiring duct.
|
|
This is by far the largest product range, with a high number of articles.
Including: Cable trays/-ladders, wide span cable trays/-ladders, vertical ladders and mesh cable trays - everything in different load/span classes , siderail heights and width as well as material and corrosion protection.
Of course there are also fittings, covers, barrier strips and connectors corresponding to the siderail height and width as well as cantilever brackets and hanging pendants with load-capacities of 100 N to 10,000 N.
Talking about a system, the material and surface integrity are dovetailed with each other too.
|
|
Cable tray systems
* Cable trays of every size and design
* Optimum cable routing in all areas of electrical installation
* Complete product ranges with all logical system components for any task
* Both for horizontal and vertical cable routing
* Special surfaces for guaranteed corrosion protection – even in external areas
Cable trays
Wide span cable trays
Fittings
Straight connectors
Angle connectors
Adjustable connectors
Joint plates
Covers
Cable holders
Distribution boxes
|
|
|
|
|
|
InfoStream® Multi-Channel Raceway
HellermannTyton's InfoStream Multi-Channel Raceway is a revolutionary design for non-metallic raceway system. The elliptical shape is aesthetically pleasing when compared to other designs. By using the three rails to snap in dividers, the InfoStream system can accommodate up to four separate channels of electrical, voice, data, video or fiber optic cabling. InfoStream's unique and patented design make installations quicker and easier. The raceway and fittings are manufactured from a UL 94V-0 rated material.
Features a unique, elliptically shaped profile which is currently offered only by HellermannTyton. The rounded profile offers both a sleek appearance and also helps absorb shock if the raceway is inadvertently struck. InfoStream speeds installation as the raceway's hinged cover can be partially mounted prior to laying cables, while doubling as a ledge, preventing wire and cable from falling out of the raceway during installation.
Compatible with HellermannTyton's single channel TSR line of raceway, InfoStream offers up to 4 separate channels for electrical, voice, data, video or fiber optic cabling. The InfoStream system is U.L. Listed to U.S. and Canadian safety standards. InfoStream is available in 8 and 10 foot lengths in office white and electrical ivory.
|
|
Wire Management Systems
Managing the hundreds of thousands of feet of cable found in a typical construction job site can be a formidable challenge. Thomas & Betts offers hundreds of products to help wiring professionals route and conceal wiring. Leading T&B brands include
T&B® cable tray, T&B Express Tray®, Steel City® floor boxes, Ty-Duct™ wiring duct and accessories, and Omni-Plus® voice/data accessories.
|
|
|
|
|
|
Exel Composites Cable Support Systems offer engineers a structural product for solving many design and plant engineering problems, enabling long term reliable support of expensive and often critical cables. Products possess unique properties which enable them to resist many corrosive environments, particularly where conditions indicate that conventional materials will not provide an economic service life.
Constructed from glass reinforced thermoset resins, Cable Support Systems are designed and manufactured with a structural integrity normally only associated with steel and aluminium, but without their corrosion, weight and electrical conductivity problems. Procuts resist acids, salts, alkalis and a wide range of aggressive chemicals and environments which have drastic effects on galvanised steel and aluminium. They have a superior strength to weight ratio compared to steel or aluminium whilst maintaining a similar structural integrity. Pultruded fibreglass profiles have a specific gravity of one-fourth that of steel and two thirds that of aluminium, allowing for considerable simplified erection and handling. Composite cable ladder and tray is non conductive and non magnetic, meaning a safer support system. Fibreglass composites are transparent to radio frequency transmissions.
A wide variety of industries take advantage of the benefits of composite Cable Support Systems. e.g. Chemical Processing, Petrochemical, Mineral Processing, Ports and Harbours, and Aluminium and Bauxite Processing.
Exel quality and environment policy complies with the requirements of the standards ISO 9001:2000 and ISO 14001 (Bureau Veritas Certification).
|
|
Mesh cable tray systems
Magic mesh cable trays
Mesh cable trays
C mesh cable trays
Fittings
Straight connectors
Angle connectors
Adjustable connectors
Joint platesCovers
Mesh angles
Cable holders
|
|
We can offer you different cable tray profiles, including the P.S profile, and the P.S.n. profile (new product).
The P.S. profile is a safety product, with its shape designed to reduce the risks of injury during installation.
Moreover, the P.S. edges improve the rigidity of the structure. This asset enables lighter tray to be used, allowing for greater distances between supports. In turn, this leads to a reduction in the number of parts required and hence, to a reduction in assembly cost.
Several other types of cable tray profile are available: Straight, Omega, C profile edge, etc.
All our tray models are compatible with an extensive range of accessories: cranked, interlocking splice bars, both flat and for crimping; tray base joints; 90° and 135° angled bends; convex, concave, cruciform, T joints etc.
|
|
|
T-SCOPIC : a decisive innovation in cable management. All you need to do is to pull the cable tray out from the other. Therefore , a length of 4 metres of cable tray is installed in one operation as opposed to 3 metres for standard equipment. T-SCOPIC offers a full safety auto-locking system. Installation time saved : 50 %
|
|
We can offer you different cable tray profiles, including the P.S profile, and the P.S.n. profile (new product).
The P.S. profile is a safety product, with its shape designed to reduce the risks of injury during installation.
Moreover, the P.S. edges improve the rigidity of the structure. This asset enables lighter tray to be used, allowing for greater distances between supports. In turn, this leads to a reduction in the number of parts required and hence, to a reduction in assembly cost.
Several other types of cable tray profile are available: Straight, Omega, C profile edge, etc.
All our tray models are compatible with an extensive range of accessories: cranked, interlocking splice bars, both flat and for crimping; tray base joints; 90° and 135° angled bends; convex, concave, cruciform, T joints etc.
|
|
BS series of light, medium, and heavy duty safety return flange cable trays range.
Height : 25,35,50,60,75,85,100,110 mm .
Widths from 50 to 600 mm
|
|
|
UNIFIL basket tray series for any industrial and commercial application requiring à good ventilation and an easy identification of cables. Fast installation with clip-on couplers and accessories. Height : 30, 54 ,100 mm. Widths : 50 to 600 mm.
|
|
Specially for: transport and industrial environments.
BK is made by the hot pressmoulding process.
- 3 sizes available
- Rigid and self-supporting
- Quick and easy to load / unload
|
|
| ... products without technical information |
| |
Chainflex® are the special cables for Energy Chain Systems® – tested, tested, tested and tested.
As a manufacturer of Energy Chains® and special Energy Chain® cables, igus® uses the possibility of testing many different types of chains and cables on a practice-oriented basis At the company-own technical training center in Cologne, numerous series of tests are carried out on a parallel basis under the most difficult conditions. At the present time, there are more than 35 test setups with their test results being summarized in databases. This extensive, current data pool provides precise, reliable information on the actual service life and is also the basis of new product developments at the company. The test data for Energy Chains® and cables, but also for ready-made systems, are, however, described in such detailed form that igus® confirms a functional guarantee for its Energy Chain Systems®.
|
|
MAN-MADE MACHINES
LAPP MULLER is the partner of robots, gantries, machine tools manufacturer for the design and the production of power lines, power/control, servomotors and safety control systems.
- ROBOCABLES F3
Miniaturized cable for drag chain
- ROBOCABLES F1X
Miniaturized cable for very long and high speed drag chain
- ROBOCABLES UL
All our range of ROBOCABLES with UL homologation
- ROBOCABLES BUS
Cables answering to all existing bus protocols
- ROBOCABLES CLEAN ROOM
Complete range of ROBOCABLESÒ for use in Clean Rooms, with DIN ISO 14644-1 certificate
- HYBRID UMBILICALS
Composite robotics cables interface with electric hydraulic pneumatic and optic
- HARNESS CABLES
- ROBOTS EQUIPMENTS AND SERVICES
These companies trust us :
STAUBLI, COMAU, KUKA, ABB, PEUGEOT CITROEN, NELSON, SAMSUNG, FIAT, DURR, MICHELIN, ROBOTEC….
|
|
- Very great flexibility. For intensive uses.
- Normal Tension: 300/500V.
- Tension of test: 3000 V. -5°C with +70°C.
- Radius of curvature without shielding ø cable x10.
- Radius of curvature with shielding ø cable x12.
- Press-packing-sock for chain cable carrier to consult us.
|
|
Trailing cables for Cable Chains 300 volt ~ 300/500 volt ~ 600volt ~ 0.6/1 kV
PVC Control and Power Cables
Low capacitance zero halogen PUR Electronics Cables
PVC/PUR Control Cables
PE/PUR power and servo single conductors 0,6/1 kV
TPE-E/PUR Electronics and Control Cables
TPE-E/PUR servo single conductors 0,6/1 kV
|
|
|
|
see the results for the following category :
