Engine Controller – EC-1
Compact engine controller with optional J1939 engine communication. The integrated communication makes remote control possible and with an optional GSM modem, the EC-1 can forward SMS/text messages.
Features include:
- Engine control
- Engine monitoring
- Multi-language display
- Engine CAN bus communication
- 6 configurable binary inputs
The EC-1 is an attractive alternative for key starters if you require extra communication such as engine communication or remote communication
|
|
Control unit unipos C110:
- linear path controller
- CNC + PLC
- controls max. 9 axes, servo motors or stepper motors
- DC motors on request
Control unit Unipos 120 / 220:
- Point to point controller
- Control unit to control stepper motors
- CNC
Control unit unipos 420-W:
- continuous path controller
- CNC + PLC
- Controls max. 8 axes, 4 axes simultaneous
Control unit unipos 820-W-/WH:
- CNC-Controls + PLC
- max. 64 axes with 8 NC-channels (SERCOS/Analog)
|
|
The XLe compact (96x96x57) all-in-one controller comes with a 128x64 LC-Display and has full monochrome graphics capabilities. It is equipped with built-in I/O coupled with the dual protocol capabilities and optional internal telecommunication modules.
The OCS with its full IEC61131-3 integrated development environment for logic, HMI design, networking and I/O configuration is a very capable PLC with full graphics capability. The operator interface used in the XLe series is a high visibility graphics monchrome LC-Display with blue LED backlight offering excellent readability to the user in the most difficult conditions.
~ Cscape™: All Units are programmable with a Free Software ~
|
|
Microvision Plus (3 axis interpolated controller)
All the power of a numeric controller with ISO programming in a cheap structure based on a RISC 16 bit processor. Monochromatic 5” display can be touch screen which improves navigation making it more user friendly. Drivers can be connected to the controller either through analog +/-10 V. signals or digital PWM or Step / Direction. Besides a considerable number of I/O “on board” many other devices can be added or remoted using the 2 available CANopen serial ports.
|
|
From the monitoring-for-function of the sensors to self-monitoring Control Units, Mayser supplies the right Control Unit for every safety system. Acting as a link between the sensor and the machine control, it analyses the incoming signals and immediately triggers the required measures.
In cooperation with the Elge GmbH company, we can also supply Control Units for special safety systems and other applications.
|
|
|
The main engine is considered the lifeline of the ship. The WE22 constantly monitors and optimally controls the main engine.
|
|
The Keystart range provides manual start/stop and automatic fault protection for generators, pumps and other engine-driven applications:-
* Simple, compact design
* 92 x 92 mm or 68 x 68mm DIN panel cut-out
* Security keyswitch
* Fuel, starter and timed preheat control outputs
* LED and icon indication of preheat, fuel on and fault conditions
* Overspeed shutdown option, with link-selectable input source (magnetic pickup or AC generator)
|
|
|
|
|
|
Engine monitoring system Watch-free system model : WE500
- Larger screen size
The LCD screen size is enlarged from 12.1" to 15". The image resolution is enhanced from 800 x 600 pixels (SVGA) to 1024 x 768 pixels (XGA). The number of display colours is also increased from 12 to 16,777,216. Furthermore, two larger size of LCD displays can be connected externally as an option.
- Mimic screens are made available
- Remote control for pumps and valves
Mimic screens provide remote control for pumps, valves and other kind of devices.
- Hardcopy function is added
Hardcopy is available by using a printer comes standard with the system
- Trend analysis display feature is enhanced
All analogue measurements can be viewed anytime as trend diagrams for continuously sampling of them.
- Download feature is provided
Connecting a purpose-built PC to the system allows monitoring points to be added, deleted or changed on site.
- The all-in-one configuration and the dual hot standby capability are inherited
High serviceability and reliability of the system are contributed. The compact design with 700 mm width (80 mm wider than WE300HG) can minimize the installation space.
|
|
New Backgauge Control System for CNC machines. Up to 3 axis of servo, or inverter control, The accuracy and friendly user interface helps you obtain great results again and again.
Main features:
* Easy to install and use
* Improve production
* Improve quality of final product
* Memory capacity for 100 programs up to 1000 lines each
* Graphic Colour LCD Screen - 320 x 240 Pixels
* Automatic push out of paper: to help the operator to handle the paper
* Air table control
* Label Optimisation Mode
* Quick cut mode
* ‘Teach’ mode programming
* Loop quantity programmable
* Encoder Feedback
* Imperial and metric
|
|
ELECTRONIC CONTROL FEATURES
100% duty cycle
Superior Accuracy (1/2% over full range)
Compact electronic and mechanical design
No clutches or brakes
Multiple size plunger / flow capability
Severe duty design standard
Local micrometer stroke indication
Split signal capacity (standard, field adjustable)
Direct or reverse acting (standard, field adjustable)
Each side can operate independently or in unison
Adjustable feedback signal to tune output
Low maintenance
No overshoot or hunting
Wall and panel mount remote controllers (w/indication) available
|
|
The Elliott Digital Governor (EDG) is a compact, cost efficient, packaged electronic speed control unit for precise, reliable speed control of mechanical drives or induction generators. The EDG has simple push-button control to provide improved reliability and speed control over hydraulic governors without the use of wearing parts such as linkages and bearings. Additionally, it does not require a separate programmer as required by many other speed control methods.
The EDG has numerous standard design features including a large, continiuous LCD display and a wide, continuously adjustable governing range from 200-10,000 Hz. Idle speed, ramp rate and turbine speed are programmable, while electrical trip speed is pre-programmed. Optional features include remote trip and start/stop capabilities. The unit is sized for 19-inch rack mounting and can be configured for NEMA A or NEMA D operation. The standard enclosure is NEMA 4X and is suitable for wall mounting.
|
|
DST2600 is a compact and affordable gen-set controller system for power up to 40kVA.
DST2600 makes available all the functions of a traditional gen-set stand-by panel: full AMF controller with engine and generator protections, contactors for power transfer, battery charge maintainer, power relays for engine commands, measurement systems and display for electrical and other physical quantities.
|
|
|
|
|
|
Combustion Control and Monitoring Systems
Combustion and emission control, why?
In 1997 with the Kyoto's Conference and its regulations, the Governments decided to pay more attention to the CO2 flue gases reduction.
The European target for CO2 reduction is 8% compared to the year 1990 values.
Ascon is one of the leaders of this new conscience of environmental effects, managing, energy and financial saving.
Four guide lines have been defined: energetic renewable resources , diffusion of implementations to improve the final energy use, electrical energy production, and urban road traffic reduction.
One of the most important steps is to improve the plants efficiency by means of the continuous control of the flue gases oxygen content.
This type of control enables:
combustion efficiency optimisation by means of the control of the air/fuel ratio (energy saving);
check of correct plant working under different operating conditions, simple identification of possible anomalies and then relevant corrections (safety);
reduction of Nitrogen oxide pollution (to reduce environment impact).
Remember, a correct combustion means: economy, safety, cleaning.
Clean Combustion = Energy and money saving
At present each moderate investment on this matter enables a considerable energy saving with the consequent money surplus which means a quick pay-back of the investment and more.
|
|
|
|
|
|
Libratherm offers ready to use control panel for electrical furnaces, ovens or any other electrical heating system, which can be used by the OEMs or the end users. The panels are fabricated as per the auto-cad drawing using the high grade steel and are duly powder coated. The size, volume and the air circulation arrangement of the panel is chosen as per the requirement. Depending upon the requirement and application of heating system and desired degree of temperature accuracy the temperature controllers, controlling method and the end controlling device is selected. The panels can be supplied for single phase load or three phase load.
The main controllers can be simple On/Off controllers (model DTC-300, DTC-720) or more precise single or multi loop PID controllers (model PID-300, PID-966, PID-723 or PID-8000) or the single or multi zone Ramp/Soak profile programmers (model PRC-300, PRC-309, PRC-8000 etc…) The parallel safety controllers can be selected as model DTC-300 or linearized controller model DLC-301.
The final controlling device can be a suitably rated electromechanical contactor or solid state relays for single and three phase load. For larger capacity heating systems requiring precise control, thyristor power controllers (either phase angle controlled or burst firing control) are incorporated, having single phase, two phase or three phase star/delta load configuration. The suitably rated heavy duty terminals or bus bars are provided for heater and power line connections. The load connections are isolated using the suitable contactors in series to isolate the heating system during maintenance of the panel or the heater load.
|
|
Crowcon's 35+ years gas detection expertise has been instrumental in developing a range of control panels to suit all applications. All our fixed gas monitoring systems can be interfaced with any fire and gas detector and distributed control system (DCS). In addition each system can be engineered to drive remote annunciators and mimic panels.
Our fixed gas monitoring range consists of:
Vortex 1 to 12 channel control system
Gasmaster 1 to 4 channel control system
Gasflag Single channel control system
Gasmonitor Plus 1 to 16 channel control system
CellarSafe CO2 monitoring system
Ditech modular gas and fire detection and extinguishant control system
|
|
The production line offers follwing features:
- Inline assembly concept (3 assembly cells in a row)
- Concept is designed für 3 diferent product types
- Special system design for flexibility, high precision clean production run
- Free flowing workpiece carrier system
- Special palletizing system for parts feeding and providing final assembled parts
- Bowl feeder for micro parts
- Open control system Simatic S7 and bus system DP
- Cycle time 10 sec. (6 units per minute)
- Technical availability 86%
- Working operations: parts feeding, pick and place operations, orientating, high precision mounting, testing, parts palletizing
- Rohwedder services: Process planning, system development and design, complete supply and implementation of production line, production assistance (SOP)
|
|
Features:
-Superior Low Energy Control for Micro Welding
-Ultra Fast Closed Loop Control
-Single Phase Power Supply
-Three Feedback Modes for DC Welders
-Graphical Display and Intuitive DC Welder Monitoring
The UB25 linear DC welder provides unsurpassed levels of control for micro-miniature resistance welding. This DC welder power supply should be used for smaller applications where closed-loop feedback control and fast response times are required. Safety critical applications such as those found in the medical and automotive markets will benefit from UB25’s precision low energy control.
|
|
Low Power Linear DC Welder with Built-in Monitor - UB25
Features:
- Superior Low Energy Control for Micro Welding
- Ultra Fast Closed Loop Control
- Single Phase Power Supply
- Three Feedback Modes for DC Welders
- Graphical Display and Intuitive DC Welder Monitorin
The UB25 linear DC welders (successor to the Unibond II) provide unsurpassed levels of control for micro-miniature resistance welding. These DC welder power supplies should be used for smaller applications where closed-loop feedback control and fast response times are required. Safety critical applications such as those found in the medical and automotive markets will benefit from UB25’s precision low energy control.
|
|
|
Tide Powercon electronic intelligence power controller has inlaid high performance computer chips and various functions, such as measurement, control, protection and remote control all in one, and the controlling program and protective parameters can be changed, completely satisfying requirements of users and professional assembly factories on automatic control of different generator sets.
|
|
|
|
|
|
TEM10 are mounted on canopies. They allow the Manual and Automatic operation and the removal of power through alternator by socket protected by switches.
The degree of protection is IP55 in the command part, while it is IP44
in the socket place (IP 55 is an optional and it can be requested with special sockets).
These panels are suitable for being used daily in a generator in safety. Actually, they are characterized by sturdiness, components reliability and a lot of care during assemblying phase. A 10 poles connector (which is placed on the front part of the sockets panel) ,allows to connect to a Mains/generator transfer switch panel (i.e. ATS-E) managed by the Control Panel.
These panels are equipped with all it is necessary for their installation: bolts, power cable to connect to alternator (up to 125Amp), metal plug to be inserted into the panel to connect the engine cables.
They use an electronic device which is named TE806. It is simple and reliable. It is also homologated for being used in the most severe environments with maximum security. All controls related to mains and generators electrical measures and all engine controls are shown on a 4 led digits display. It is an easy and powerful device with a lot of available functions.
|
|
For Maximum Combustion Efficiency Through Complete Mixing Of Fuel Gas And Air.
Selas Combustion Controllers equipped with PosiMix® Mixing Valves are precision premix systems for blending fuel gas and air. They are suitable for most fuels, mixing them with room air and compressing the mixture to deliver a precise, preset gas/air ratio at uniform pressure to the burners.
FEATURES & BENEFITS
Completely self-contained
Capacities available from 500 to over 150,000 cfh of mixture
Output pressure to 6 psi
Precise gas/air ratio maintained over a wide turndown
Available with automatic ratio control
Low installation cost - single pipe delivery system for one or more control zones
For use with any clean commercial fuel gas containing less than 40% hydrogen
Rugged - provides years of trouble-free operation
Low maintenance
|
|
No matter what the application, Draeger's System Centers will design a monitoring system for your specific needs.
Whether it is a single wall mount unit for only one or a few points, a 19" rack mounted modular controller, or a full blown SCADA system with cabinetts to house the electronics and wiring, our experienced engineers will help to design the system that fits. Even PC monitoring consoles with event log displays and zoom-in plant layouts are available from Draeger Safety.
|
|
|
|
|
|
AB425S:
New universal control unit for almost all sewing machine drives with 1 or 2 stepping motors.
* Control unit for Efka DC1500 or DC1550 motor
* - and 2 stepping motors Efka SM200 and SM 250
* - or 3. party products up to 60V and 5A phase current
* User customized programming of individual and even complex functional sequences in a higher programming language for specially designed sewing workplaces and sewing automats using Efka C200 compiler
* Flexible pre defined seam programs
* Synchronous operation of all drives
* X/Y function
* Output signals for use on sewing automats
* USB port for data storage uploading and downloading
* Updates via USB with email possible
* Flash technology, no EPROM
* Digital parameter setting directly on the control unit
* Programmable light barrier functions
* Separate knee switch connection for KN19
* Integrated tread monitor function
* Wide range of HMI: Variocontrol V810, V820, V850 und Variotouch V900
* Easier mounting on sewing machine thanks to compact control box housing
* 29 short-circuit proof outputs
* 28 digital inputs freely programmable
* 2 analog inputs
* 2 digital / analog converter output (0-10V)
* Operating hours counter
* Machine operating time monitoring with optical or acoustic signal for maintenance
* Expandable to other Efka drives via CANefka
|
|
R50MP motor pump control unit is suitable to control and protect Diesel and motor pump engines.
It includes an engine protection unit ,which is named PDM1MP, which, besides running indications, stops the engine in case of alarm. It also protect the water pump by means an instrument which allows work pressure surveying and setting up the minimum and maximun value of pressure at which the engine needs to be stopped.
|
|
|
|
|
|
BODAS controllers for quickly and affordably creating a mobile-hydraulic complete solution without time-consuming and expensive hardware development.
The RC controllers are the heart of the BODAS system with multifunctional inputs and outputs for the control of the electrohydraulics components in the machine. BODAS RC controllers are optimally meeting the requirements of mobile working machines with a diversified application spectrum.
In complex applications, multiple controllers can be connected via the CAN bus to form a network. The number of the inputs and outputs can be extended quickly and economically with the CAN I/O-extension module RCE. Safety features integrated in the standard version enable simple and reliable machine diagnostics.
Matched to the RC controllers, the BODAS software modules offer preconfigured application solutions for drive and working hydraulics. A comprehensive tool chain for parameterization, for diagnostics and for flashing the BODAS controllers is available with the BODAS-service.
For custom solutions, you can use the BODAS RC controllers as a freely programmable platform.
Features:
- Safety features:
-Detection of cable break
-Detection of short circuit
-Monitoring the outputs
-Bosch watchdog module
-Central switch for all power outputs
- Output stages with pulse-width-modulated current regulation (PWM)
- Robust case
- High EMC > 100 V/m
- Download the software from a PC to the flash memory
- CAN bus or RS232 interfaces
- Interfaces matched to Rexroth electrohydraulics
|
|
Electronic controllers are designed for electric motor drives
based on the battery supplied asynchronous motors, electronicaly commutated brushless motors with permanent magnets and DC commutator motors. They are designed for use in various
drive systems. They are built in the MOSFET technology. Their
method of operation is adapted to the operation with various
types of motors. Controllers are designed on the basis of
processors; therefore a wide setting of functions is possible.
They are built for the nominal voltages from 12 V to 80 V
and control of load currents up to 800 A.
|
|
|
The CVC electronic controller has been designed as control system for hydrostatic tracks vehicles with separate - left and right - hydraulic circuit. The CVC controls in closed loop the displacement of the two pumps, or the speed of the two wheels, to make sure that it corresponds to the given command in whatever use conditions.
|
|
Switches and controllers
with integrated motor protection
switches: 1-, 2-, 3-step
Control unit:
transformer
5-step and stepless, electronic stepless
Regulated by:
stepless, temperature-, pressure-, humidity-, air velocity
Electronic Control Units
Electronic control units for stepless speed control of voltage-controlled 1- or 3-phase fans. The devices are available in various ratings and formats. Rosenberg offers electronic control units with manual speed selection as well as devices for simple control applications (temperature-pressure control).
|
|
|
|
|
|
BODAS controllers for quickly and affordably creating a mobile-hydraulic complete solution without time-consuming and expensive hardware development.
The RC controllers are the heart of the BODAS system with multifunctional inputs and outputs for the control of the electrohydraulics components in the machine. BODAS RC controllers are optimally meeting the requirements of mobile working machines with a diversified application spectrum.
In complex applications, multiple controllers can be connected via the CAN bus to form a network. The number of the inputs and outputs can be extended quickly and economically with the CAN I/O-extension module RCE. Safety features integrated in the standard version enable simple and reliable machine diagnostics.
Matched to the RC controllers, the BODAS software modules offer preconfigured application solutions for drive and working hydraulics. A comprehensive tool chain for parameterization, for diagnostics and for flashing the BODAS controllers is available with the BODAS-service.
For custom solutions, you can use the BODAS RC controllers as a freely programmable platform.
Features:
- Safety features:
-Detection of cable break
-Detection of short circuit
-Monitoring the outputs
-Bosch watchdog module
-Central switch for all power outputs
- Output stages with pulse-width-modulated current regulation (PWM)
- Robust case
- High EMC > 100 V/m
- Download the software from a PC to the flash memory
- CAN bus or RS232 interfaces
- Interfaces matched to Rexroth electrohydraulics
|
|
|
ITC manufactures and sells a wide range of electronic equipments for dosing pumps control. From equipments that control the CI, RedOx, pH and EC to Fertigation Controllers with automatic pH regulation and the fertilizers in the irrigation water.
|
|
|
|
