PRODIS-ADC: Digital Process Meter from ASM
The PRODIS® product family consists of digital process meters with a 6-digit LED display, developed and produced by ASM, a leading manufacturer of linear and rotary position sensors. PRODIS-ADC is a process meter designed especially for sensors with an analog output.
PRODIS-ADC is designed for use with analog position sensors to display angular and linear displacements. A high resolution A/D converter processes the signals from sensors with a voltage output 0…10 V, current output 0/4…20 mA or voltage divider output.
The meter is programmable to display values within preset start/end range or values in units as inches, mm or degrees. A tare function or programming lock can be activated with two control terminals.
The sensor excitation is supplied from the meter. With four membrane keys, all parameters can be programmed for signal evaluation, scaling and output function. Optional comparator functions are available with 4 NPN open-collector outputs and 2 NO/NC relay outputs.
|
|
2 products to suit all your need in remote displaying : ATT 300 and ATE 300.
• ATT300 : can work with any current or voltage input of any transmitter : pressure, humidity, temperature, air flow, air velocity...
Display : -9999 to 99999
Display of the reading : 5 matrix digits
Display of units : 4 digits
Power supply : 24 Vac/Vdc
Analog inputs : 3 x 4-20mA, or 3 x 0-10V, or RS232 + one current or voltage input.
Housing : Stainless steel, IP65
Output : RS232
Modbus system (RS485 network)
•ATE 300 : can display 3 parameters (for example humidity, temperature and pressure). Can be installed flush-mounted or wall-mounted.
Display : -999 to 9999
Display of the reading : 4digits/7segments
Display of units :4 digits/14segments
Power supply : 24 Vac/Vdc
Analog inputs : 3 x 4-20mA, or 3 x 0-10V, or RS232 + one current or voltage input.
Housing : IP65
Output : RS232
Modbus system (RS485 network) |
|
The ATE300 is a multichannel indicator specially dedicated to flush-mounting (or wall-mounting) installations.
• Alternating display of 1 to 3 parameters
• 3 analogue inputs : 3 x 4-20mA or 3 x 0-10V
• 1 RS 232 digital input for KIMO external transmitter (class 200 & 300)
• 1 RS 485 digital input/output (Modbus protocol integrated)
• 22 pre-set units and 3 configurable units
• Configuration via software or remote control
• Electroluminescent front display, made of brushed stainless steel or white
lacquered
|
|
Features:
Simple low cost indicator with front dimensions 48x24 mm
and LED size 8 mm
Power supply 10 ... 30 VDC
Analogue inputs 0-10V, 0-20 mA and 4-20 mA
Display range -19 999 to 99 999, adjustable zero and full scale value,
14 bits of resolution
Latch input to freeze the display, minimum/ maximum record memory
Easy to set up by only two front keys and menu support
Delivery includes adapter frame for 50x25 mm cut out and
label set with dimensions |
|
Digital display unit (DA 10), also available with additional relay output
(DA 12/14), for electronic transducers.
Display
5-digit graphic LCD display, backlit
(white), text-based user interface,
user interface language selectable
(German/English/French), selectable
units of measurement.
Measuring range
±99.999 digits (min. and max. fully adjustable) |
|
As well as the standard functions - preset, alarms, RS232 output, Max, Min, Difference, etc - Solartron digital readouts and dual digital displays boast a number of new functions.
For example, the new "Scaling Factor" function can be used to compensate for angled or lever operated probes, or diameter when measured in a V block. It also enables measurement of angles or squares.
Other new functions include the "Gauging Mode" - allowing global pass/fail evaluation of up to 30 scan channels -and "Max A Max B".
Ergonomically designed for the operator, the DR700 can be used with multiple probe fixtures using either Linear Encoders, Digital Probes or a combination of both - making it a truly versatile addition to the Solartron "Orbit" range.
|
|
LDSS - LARGE DIGITAL DISPLAY FOR SERIAL INPUTS
Ideal for Production line Monitoring, Temperature Zones Monitoring on the Plant Floor, Tank level Monitoring, Operation Timing, Storage/Process Temperature Monitoring...etc...,
The LDSS is the perfect solution to display a value that is currently stored in a register and displaying it on the plant floor.It is capable of accepting RS232 or RS485 as the input and displaying it as a remote or slave display.
- Exist in 2 versions, with display heights of 2.25" readable to 130' or the 4" readable to 180'.
- Input: accepts serial ASCII data from an host device
- Selectable for RS485 or RS232 serial interface
- Display capability: full numeric, limited alphabetical (missing M,W & X)
- Decimal point transmetted with the value
- Display selections: secondary display capability, Display scroll option
Supply a complete monitoring solution in combination with the Data Station Plus, the Modular Controller or one model of the G3 series |
|
As well as the standard functions - preset, alarms, RS232 output, Max, Min, Difference, etc - Solartron digital readouts and dual digital displays boast a number of new functions.
For example, the new "Scaling Factor" function can be used to compensate for angled or lever operated probes, or diameter when measured in a V block. It also enables measurement of angles or squares.
Other new functions include the "Gauging Mode" - allowing global pass/fail evaluation of up to 30 scan channels -and "Max A +Max B".
Ergonomically designed for the operator, the DR700 can be used with multiple probe fixtures using either Linear Encoders, Digital Probes or a combination of both - making it a truly versatile addition to the Solartron "Orbit" range.
|
|
Intrinsically safe analogue indicators - GSI / BSI series
Located in EX area
Field mounting (IP66) or panel mounting
3 1/2 and 4 1/2 digits display or bargraph
4-20 mA loop powered
Front face programming
Agreement : ATEX II 1G
Options : alarms, backlight, internal calibrator, set point station |
|
ESA Text Terminals are designed
for applications that require an
interface that is easy to use and
program. All of the function keys,
including the 18 supplementary
keys of the VT160W, can be used to
give direct commands like Start and
Stop to the machine.
Main characteristics (model
dependant):
- Alarms, passwords, recipes
- Mathematical functions
- Two drivers run simultaneously
- Serial or parallel printing
- Integrated Profibus-DP and CAN |
|
Large Displays for process control
· Inputs: ±10V, ±0-20mA.
· Three digits size available : 57, 100 and 250 mm.
· From 2 to 5 digits, 1 or 2 displaying sides.
· Serial line option (RS232 or RS485) and dual relay output option.
|
|
The DM- 100 Digital Load meter displays motor load. The DM-100 can be adjusted to read the motor load in :
- Percent 0 - 100%
- Horsepower
- kW or W
The input for motor load indication comes from the analog output of a Load Controls, Inc. Load Control or from a LCI Powel Cell power transducer
. |
|
A comprehensive range of high accuracy multi function digital metering systems offering measurement, display and communication of over 100 parameters, including true RMS measurement for total harmonic distortion and power quality data. Integra products are fully programmable via a simple menu driven interface and can be integrated into energy management systems via various communication protocols. To suit requirements, Integra offers pulsed, analogue and digital output options, and a choice of DIN, ANSI and JIS case styles, with high quality LED or LCD display.
|
|
Microprocessor Instruments:
microprocessor Bargraphic Display Scaling Meter, Microprocessor Temerpature Controller, Microprocessor Power Quality Meter, Microprocessor Counter. |
|
PAX Series : Large range of Intelligent panel meters
The PAX Meter is the workhorse of our panel meter line-up. From its sunlight readable display to the wide variety of field-installable options cards, the PAX Meter will easily handle your application requirements. Select from the widest range of inputs in the industry, including models for both digital and analog signals. Their Comms capability allows data collection at various points of the machine and communicates the information to your management system, while still providing the machine operator with a localized display. Installing a complete system? Learn how to put a PAX Meter to work for you.
PAXC - Counter
PAXCK - Timer & Real Time Clock
PAXD - DC Volt & Current Input
PAXDP - Dual Process Input Meter
PAXH - AC True RMS Voltage and Current Meter
PAXI - Counter Rate Meter
PAXP - Process Input Meter
PAXR - Rate Meter
PAXS - Strain Gage Input
PAXT - Thermocouple & RTD Panel Meter
PAXTM - Preset Timer
Display of 5 LED digits of 14mm, with variable intensity for good outdoor readability (factor 1 to 15)
These intelligent solutions can be enabled with optional plug-in cards, for set point alarms (2 or 4),analog output and communications (RS232, RS485, Modbus, Devinet, Profibus), enabled Ethernet via external module (ICM8) |
|
| When your application calls for variable indication, Digital Panel Meters (DPM) are the right tool. Voltage, current, pressure, volume, temperature, frequency and other parameters can be monitored and displayed. With a variety of input and ouput options, DPMs can be used in most any application and the product's short depth makes it flexible and accommodating to panelbuilders' needs. |
|
- Input Supply 4-20mA
- Up to 5 Digits of Display Range
- Sensor Drift Compensation at 0%
- Universal AC Supply Voltage |
|
The Simpson Gima series digital power meters provide a single source of instrumentation for all measurement and metering requirements. The Gima series offers accurate, high-speed, continuous measurements irrespective of harmonics and waveform interruptions. Each Gima unit can be used as a single-phase or a three-phase meter.
Features
- Four model types designed to fit a wide range of applications
- One meter to measure all your values
- 1/4 DIN (96 x 96 mm bezel, 92 x 92 mm cutout) needs only 2.8" (71 mm) behind the panel
- Easy installation - Software detection / correction of wiring errors
- Wide, backlit LCD display for easy viewing
- Safe and easy to use - Four keys select all parameters |
|
Applications:
SW4000 series multi-functional digital readout can be installed in all kinds of machine tools and supply the measuring location when used together with the linear scales.
Features:
1. Employed with advanced IC,24-bit counter with unique digital filtering technology, Systematic
2. Anti-jamming in power and signal an reach 2200V or above.
3. Display data both in Chinese and English
4. Can recall the current disposition after power failure
5. Can work right between AC90V and 240V
6. Coordinate zero reset, divide by 2, display set numeral, ABS coordinate, INC coordinate,1000 grounds of user coordinate
7. Shrink rate counter
8. Detect the RI
9. Divide holes on a circle, divide holes on an oblige line
10. Arc manufacturing, ramp manufacturing (SW4000-2, SW4000-3)
11. EDM manufacturing (SW4000-E)
12. Edge detecting (optional) |
|
A complete system consists of one or more Linear Encoders, commonly referred to as scales, and a Digital Readout.
The Linear Encoder monitors the machine travel and the Digital Readout (DRO) displays the distance moved or machine table position to the operator.
The axis display is large and clear and the keyboard is designed to be easy to use.
Many functions can be taken off the keyboard to support
the work at the machine.
Depending on application you can choose between
different versions of the readout. |
|
A very powerful micro-controller manages and processes all the information [position, calculation, etc.] trasmitted by the transducers or entered by the user. Having such a highly evolved but user-friendly digital Readout means increasing the production performance of the machine on which it is installed considerably.
|
|
The DRO 100S is a 1 to 3 axles position display for simple Positionierabeiten.
Ideally e.g. at grinding machines or for the measurement of the stroke of a press.
Small dimensions and a simple operation distinguish this counter. |
|
|
|
