The TecnoMax edgebander with glue pot
The ME 15 and ME 20 automatic edge banders are entirely designed and built by MiniMax backed by the experience and expertise of the SCM Group.
Compact, precise and versatile. Rapid retooling when changing over from one edge band thickness to another. These were the main design specifications around which the machine was developed.
The ME15 and ME20 will apply a variety of edge bands ranging in thickness from 0.4 mm to 2.0 mm. The machine has an automatic loader for edge rolls and a pneumatic end cutter unit which guarantees a clean, precision cut on the leading and trailing edges of the panel.
Main optionals:
Edge thicknessing kit up to 1.5 - 2 mm
* angle fence with numeric indicator
* roller unit on worktable
* numeric indicator for cutter setting on trimmer
* cutters with shaped profile (2 mm radius)
* bearings for trimmer
Coil holder plate 730mm
Single-phase motors 50/60 Hz
The trimming unit has its own 0.37 kW motor and trims the surplus edge banding using two, widia-tipped cutters with a 75 mm diameter. Trimming precision is guaranteed by two, chromed copiers which are bearing mounted to ensure smooth panel feed.
A top-mounted 0.18 kW feeder ensures uniform, powerful panel feed through the machine.
The machine is reasonably priced and therefore well within the reach of woodworking workshops and small carpentry businesses and what is, potentially, a wide market.
|
|
|
|
|
|
ALA 23, AUTOMATIC EDGEBANDING MACHINE FOR SMALL TO MEDIUM INDUSTRIES
ALA 23 is the new edge banding machine offered by CASADEI, simple, flexible and reliable, available in different compositions, suitable for small to medium industries searching for high quality finishing and good production output.
ALA 23 can process edges within a thickness range from 0,4 to 8 mm and a working height from 8 to 55 mm. Furthermore it is provided with: a glue pot unit with a capacity of 1,5 kg, a quick heating system and an automatic internal device which reduces the glue temperature in case the machine is not used for a certain period of time; a cutter with an efficient edge saving device, which allows for the optimisation of the waste; and a pressing unit with pneumatic pressure regulation and with 3 rollers, the first one of which is powered with a clutch system, meanwhile the second and the third have opposed tapering for a perfect adhesion of the edge.
ALA 23 also has an end cutting unit, tilting up to 15°, which can take up two positions (one for straight cuts at 90° and one for chamfered cuts of the excess edge at the front and back of the panel) and a trimming unit, tilting from 0 to 10°, which removes the excess edge at the top and bottom end of the panel.
Some versions are equipped with an infeed pre-milling unit, with an automatic timing intervention device to avoid panel chipping, and with a rounding unit which allows the machining of the corners even of soft/post-formed panels with its agile and precise movements and in one pass.
|
|
|
The Biesse edgebanding centres in the Rover C series mean that it is possible to complete processing of a shaped and edgebanded panel in a single machine. The ease and speed with which the operating sections are tooled up, rapid changeover of the boring head bits and the automatic working area reconfiguration system make Rover C Edge processing centres suitable to machine small batches.
|
|
Edge Banding Machine,Edge bander
EBM508C EBM509 EBM509RA
Panel length 120mm 120mm 120mm
panel width 110mm 110mm 110mm
Tpanel thickness 10-55mm 10-55mm 10-55mm
Edge thickness 0.4-8mm 0.4-8mm 0.4-8mm
Speed 13m/min 13m/min 13m/min
Power 6.35kw 7.3kw 7.3kw
Pneumatic power 0.55Mpa 0.55Mpa 0.55Mpa
Machine size(LXWXH) 3930X1300X1470mm 4350X1300X1470mm 4750X1300X1530mm
Weight 1200kg 1500kg 1750kg
Edge Banding Machine,Edge bander
|
|
