- Maximum capacity: 510 g (EU - C 500), 1200 g (EU - C 1200)
- Accuracy: 0,01 g
- Pan: diam. 110 mm (EU - C 500), 150 mm (EU - C1200)
- Linearity: ± 0.02 g
- Serial Output RS232
- Operating temperature: 10° - 40° C (recommended 15 - 30° C)
- Seven segments display, small decimal digits
- ON/OFF display
- Universal power supply (100 - 240 V)
- Strenghthened anti-shock system
- Piece-counting function
- Practically indestructible weighing cell with no transport problems
- It stores in memory the weight if the electricity supply is lost
- Sampling with 10 pieces and multiples till 100 pieces
- Automatic calibration with external mass
- User friendly membrane keyboard
- Dimensions (w x d x h) : 210x355x120 mm
- Net weight: 3,3 kg
|
|
The Eilersen shock proof digital industrial scales are used where high accuracies are demanded in tough environments with shock loads, heavy vibration or lots of water and corrosion.
The scales are all fitted with the Eilersen Digital weighing systems, with OIML or ATEX certified displays or with one of the Eilersen range of Digital modules for Profibus, DeviceNet, CAN, Modbus or by the analog 4-20 mA output module.
-Weighing capacities from 200 g to 30 tons with resolutions from 10 mg
-Scales are produced with dimensions according to customer specifications.
-Shock proof digital load cells, tolerate up to 3000 % overload with no overload and sideload protection devices - ideal for very tough environments.
-Load cells are sealed to IP68.
-High accuracies - certified versions according to OIML R60/R76 with up to 10.000 scale divisions.
-3 years guarantee on the digital scales with shock proof load cells.
A full range of software modules for standard weighing, special purposes and customer specific applications are available. |
|
Characteristics
Absolute measuring system with sensor retaining carriage.
Type LT-S
Measuring range 140 - 3040 mm
Resolution (max.) programmable 0,1 µm
Accuracy (typ.) +/- 5µm
Characteristics
Compact absolute measuring system with rod to push.
Type LT-G
Measuring range 60, 100 mm
Resolution (max.) programmable 0,1 µm
Accuracy (typ.) +/- 5µm
Characteristics
Solid absolute measuring system with rod to push.
Type LT-PI
Measuring range 100, 200 mm
Resolution (max.) programmable 0,1 µm
Accuracy (typ.) +/- 5µm |
|
-Robust technology and design
-High tolerance of up to 1.000 % overload
-Plug-and-play installation
-High accuracy, High resolution
-Hermetically sealed to IP68
-Interfaces: RS485, Profibus DP, DeviceNet, 4-20 mA, 0-10 V
-Digital filters
-ATEX certified
-3 years warranty
-Patented worldwide
The shockproof digital load cell is based on a capacitive measurement principle where a non-contacting ceramic sensor is mounted inside the load cell body. As the load cell contains no moving parts and the sensor is not in contact with the load cell body, the load cell tolerates shocks, torsion, and very high overloads and sideloads. Therefore, the mechanical installation of the load cell can be done without expensive and complicated mounting kits and overload protection devices.
The electrical installation of the digital load cell is pure plug-and-play as the signal from the non-contacting sensor is directly converted, compensated and calibrated by a microprocessor to a digital load cell output in grams, kilograms, or Newton. Measurements and status codes are transmitted as RS485 data on a single wire coaxial cable (RG-58) which may be up to 100 meters long.
The technology and mechanical design of the Eilersen load cells is covered worldwide by a number of patents. |
|
-Robust technology and design
-High tolerance of up to 1.000 % overload
-Plug-and-play installation
-High accuracy, High resolution
-Hermetically sealed to IP68
-Interfaces: RS485, Profibus DP, DeviceNet, 4-20 mA, 0-10 V
-Digital filters
-ATEX certified
-3 years warranty
-Patented worldwide
The shockproof digital load cell is based on a capacitive measurement principle where a non-contacting ceramic sensor is mounted inside the load cell body. As the load cell contains no moving parts and the sensor is not in contact with the load cell body, the load cell tolerates shocks, torsion, and very high overloads and sideloads. Therefore, the mechanical installation of the load cell can be done without expensive and complicated mounting kits and overload protection devices.
The electrical installation of the digital load cell is pure plug-and-play as the signal from the non-contacting sensor is directly converted, compensated and calibrated by a microprocessor to a digital load cell output in grams, kilograms, or Newton. Measurements and status codes are transmitted as RS485 data on a single wire coaxial cable (RG-58) which may be up to 100 meters long.
The technology and mechanical design of the Eilersen load cells is covered worldwide by a number of patents. |
|
|
|
