VersiStart i II
two-phase controlled soft starter
controlled by microcontroller
integrated bypass relay
current and torque reduction during acceleration
integrated motor overload protection
motor PTC connection
voltage range 200 - 440V or 200 - 575V
options:
Ext. operating panel and interface (29000.25901)
Interface for ext. operating panel (29000.25902)
DeviceNet module (29000.25903)
Modbus module (29000.25904)
Profibus module (29000.25905)
Module for pumps applications (29000.25906)
Finger protection (29000.25907)
|
|
SOFT STARTERS
- 12 to 1200A starter ratings; internal bypass contactor
up to 245A
- Torque control starting
- Total motor protection incorporated
- Digital control and adjustment
- RS232 and RS485 ports for remote control and
supervision
- Property ASCII and Modbus® RTU protocols.
AC MOTOR DRIVES (VFDs)
- Three-phase motor ratings, 0.2 to 315kW range
- Versions: Single or three phase types
- Compact size
- Automatic tuning function
- Sensorless vector control
- Special function for pump and fan duty
- Active earth leakage protection.
AUTOMATIC POWER FACTOR CONTROLLERS
- Version with 5, 7, 8 or 12 steps
- Microprocessor supervision and control
- Accurate current measure in TRMS
- Use in co-generation systems
- Versions with relay or static outputs.
BATTERY CHARGERS
- 1 charging level
- Versions for 2.5 to 12A lead-acid batteries
- Adjustable charging current limitation.
AUTOMATIC TRANSFER SWITCHES
- Supervision of two three-phase supply lines
- Supervision for assistance of generating sets
- Supervision of motorised circuit breakers
- Supervision of events and diagnostic test
- TRMS voltage measures
- Remote control and supervision.
|
|
Electronic soft starters
Easy retrofitting even into existing plants
With bypass relay
Current reduction during acceleration
Extremely simple parameterization with three (four) potentiometers
Economically priced substitute for star-delta starters
Reduction of current/voltage peaks by parameterizable soft start ramp
Soft start with rated motor torque possible for applications with high-inertia starting
When making inquiries, please indicate: motor rating, rated motor current, current consumption of motor, application, number of starts per h
|
|
PETER electronic is developing the VersiStart II series, a new powerful generation of soft starters offering proven quality and dependability in a slim and compact design. Because of its narrow design, the microcontroller-equipped soft starter is extremely space- and cost-saving.
The VersiStart II series can be individually programmed and thus easily adapted to customer-specific requirements. The soft starters are especially suitable for controlled acceleration and deceleration of electric motors and allow, inter alia, jerkless torque increase and current reduc-tion during the starting phase. With this new development, PETER electronic offers a low-priced alternative to star-delta starters and an intelligent solution with a high degree of functionality at low investment cost.
|
|
Motor control :
Efficient reduction of torque and starting current
Incandescent or infrared lamp starting :
Reduction of inrush current
Increase in life expectancy
Transformer control (loaded) :
Elimination of saturation current
Improved control and protection
Whatever your application :
Diagnosis of network, load and state of product
Better balance of and less interference on starters
(full control of the 3 phases!)
Simple use faciliting implementation and adjustements
As compact as an electronic contactor
Dimensions
|
|
Digistart is a multifunctional electronic starter with microcontroller. It is suitable for use on all the three-phase asynchronous induction motors, and assures :
- Starting management: All the traditional systems concerning motor starting (direct, star-delta, etc.) can draw a starting current that can vary between 7 and 9 times the motor rated current.
Digistart, can limit by simple adjustment, ina precise way, the current during the entire starting up phase.
- Protection of motor and driven machine: The starting up, the protection and the system automation imply the numerous elements installation making the electronic cabinets complex and costly. Digistart provides supplementary functions that limits the need for additional equipment with a consequent reduction in cost of material, manpower and running costs.
- Progressive stop control: The impact of harsh stops on certain low inertia applications, especially pumps, induces mechanical shocks, hydraulic disturbance or noise pollution.
Digistart, by generating a voltage at the motor terminals during the deceleration phase, extends the time taken for the motor to come to rest.
|
|
Smooth motor starts and stops, can reduce mechanical shock, leading to longer motor life, less frequent servicing and lower maintenance costs.
G3JA - Soft Starters
3-Phase Hybrid Soft Starters Extend Motor Life
Specifications
- G3JA-C Soft Start, Kick Start, Current Limit Start, and Soft Stop functions for 3-phase inductive motors satisfy motor performance needs for a wide range of applications
- Internal protections include protection against overload and phase loss
- Smooth motor starts and stops can reduce mechanical shock, leading to longer motor life, less frequent servicing and lower maintenance costs.
|
|
These soft starters are microprocessor controlled and are designed to work with asynchronous motors connected in open delta configuration. By using this technique the soft starter can handle more power than when connected in a conventional star circuit. Motors of up to 55kW open delta (37kW star)can be controlled with this range of units.
The M300 range limits the current during start-up and so it is more efficient. All settings are made through a touch panel which incorporates an LED display.
They protect the mains supply from sags and damaging surges (transients), whilst reducing the current demand during start-up.
|
|
WEG soft-starters, microprocessor controlled and fully
digital, have been designed to provide high performance
in starting and stopping electric motors. The keypad
offers a friendly interface for parameter adjustment
making the operation much easier.
SSW05
• Power rating: 0.75 to 75 HP (0.55 to 55 kW)
• Power supply: 220 to 575 V
• Built-in by-pass
• DSP control
• Remote keypad (optional)
• Built-in motor protections
• PID regulator
• DSP control
• Ambient Temperature up to 55 C (131º F)
SSW06
• Power rating: 30 to 2650 HP (22 to 1950 kW)
• Power supply: 220 to 575 V
• Built-in by-pass
• Removable HMI with LED and LCD display
• Kick-Start function for loads with high inertia
• Pump control for intelligent pumping system control
• Full digital / 32 bits RISC microcontroller
• Eletronic motor protection
• Ambient temperature up to 55 C (131º F)
SSW07
• Power ratings: 6 to 30 HP
• Voltage: 220...575V
• Built-in Bypass
• Built-in EMC filter
• High starting duty cycle
• Three-phase controlled
• Integral motor and starter protections
• Programmable KICK-START function to start high break-away torque loads
• Remote HMI
• Very compact product
• It is able to operate in 55ºC without derating
|
|
|
Devices for different power classes are available for continuously optimized startups and shutdowns and for eliminating sudden stresses on conveyor systems, elevators and pumps. Different models ranging from compact devices with built-in bypass contactor through to large modular units with current-limited startup help to reduce maintenance costs.
|
|
ASTAT%u2122 Solid State Reduced Voltage
GE offers 3 lines of ASTAT solid state reduced voltage starters. The ASTAT SD is a line of compact, high performance three phase starters, available to 25hp @ 460v. The SD is a full functional soft starter with complete starting/stopping control and fault diagnostics. The ASTAT IBP Plus is a line of bypass solid state starters featuring a fully rated bypass contactor. These starters are rated up to 300HP @ 460v. The design is completely wired allowing quick, simple installation into either new or exisxting installations as a replacement for traditional starters. Bypass contactors are a must for enclosed installations where free air movement is not possible. The ASTAT CD Plus is the most full featured starter in the ASTAT lineup. Parameters include soft start voltage ramp, kick-start, current limiting, an energy saving feature, thermistor input, soft stop, pump control, DC injection breaking, communications, jog/slow speed and tachometer feedback.
|
|
Soft starter DS6
"In Line" starter in a compact design up to 110 kW
DS6 the smallest soft starter world-wide in the 75 – 110 kW class.
Provided in just two sizes the DS6 enables a two-phase controlled motor start for assigned motor ratings from 18.5 kW to 110 kW (at 400 V). During uninterrupted operation the thyristors are bypassed via internal bypass contacts.
Simple and easy handling comparable with the devices of the DS4 series. Using three setting options: USTART (start voltage in %), tSTART (start-up time) and tSTOP (delay time) in seconds (s) the start conditions can be adapted to suit the respective application.
Two light-emitting diodes (LEDs) provide operational status indications and error diagnostics; two potential-free relay contacts (ready for operation, top-of-ramp) can be used to control external components.
The dimensions and connection terminals correspond to the proven Moeller standards for the circuit-breakers NZM1 (up to 55 kW) and NZM2 (up to 110 kW).
|
|
Electronic soft-start modules 2.2...7.5 kW
Mechanical
¨ Low adjustable starting torque
¨ Reduced cost of drive components
Conveyor belts
¨ Falling over, banging or slipping of products, parcels etc. is eliminated
Electrical
¨ Reduced starting current (with SM, SM2X, SM2 only)
Applications
¨ Conveyor belts
¨ Packing equipment
¨ Long-travel drives for cranes
¨ Compressors
¨ Heat pumps
¨ Vibration transporters
¨ Machines with gearbox, belt or chain drives
¨ Special version for pole-change motors
Features
Switch-on torque and run-up voltage ramp separately adjustable.
¨ Module housing for mounting on 35 mm DIN rails. Very compact version with the width of a standard contactor (45 mm or 90 mm with SM2X)
¨ Terminals and potentiometers are well protected against accidental contact
¨ Easily retrofitted
¨ Can be used as a combined soft-start and injection brake using the electronic brake modules LEKTROMIK B1
|
|
Compliant with IEC60439-1, Form 3a and Form 3b
A variety of functions have been integrated and grouped appropriately
for efficient and reliable operation
Factual statement has been issued by Lloyd's Register
CE mark compliance
Impact on the environment is reduced by using fewer parts
Weld-free construction facilitates disassembly
Extensive use of galvanized steel sheets inside panels
The new, high-performance MCCB, TemBreak2 has been employed
PLCs are used for starters
Easily changed circuitry specifications let us respond quickly to customers'
needs
Shorter delivery times
Circuit specifications can be checked easily on flow charts
The design, construction and parts selection has been carefully considered, in order to reduce the
chance that an operator will come into contact with live parts, and to prevent extensive damage in
the unlikely event of an accident.
Can comply with IEC60439-1, Form 3a (GS22B) and Form 3b (GS22F).
a) Bus bars are isolated from functional units
b) All functional units are individually isolated
c) Terminals are isolated from functional unit groups
The functions necessary in marine group starter panels (GSP) have been reviewed in order to provide
efficient and reliable integration and grouping.
a) The internal wiring has been standardized, and cable connectors are used for the control wires
b) Relay circuits and timer circuits have been replaced with PLCs
|
|
Introducing the 1st intelligent starter capable of integrating motor control, control and changeover functions in a unit 45 mm wide! Compact, simple and modular, it adapts to all the applications.
Applications
Industry: ideal solution when the motor starter needs to be decentralized in the machine or the process
|
|
