Now we like to present the new HPV-2 high-speed video camera extending capabilities through new technologies and additional features.
The HPV-2 is a PC-controlled camera. Up to four HPV-2's can be synchronised to obtain three-dimensional images or simultaneous images from four different perspectives.
Shimadzu HPV-2 offers ultra-high speed video recording up to one million frames per second (fps) and maintains the excellent spatial resolution at any recording speed. It comprises a new developed single-chip CCD image sensor (IS-CCD). This sensor allows capturing high-speed images even under (a relatively) weak illumination.
Features
* Up to 1 million frames per second frame rate
* Constant resolution regardless of the frame rate
* Capture up to 100 single frames
* Excellent performance under low illumination
The HPV-2 is suitable for wide-range applications in various fields of science and technology, for example, studies on hydrodynamics, destruction processes, shock wave development, visualizing machining processes as well as fast chemical reactions. In the field of life science, medical research and sport science, HPV-2 will be an important tool too.
Often, conventional high-speed video camera resolution drops down as recording speed is increased. The spatial resolution of the HPV-2 does not deteriorate, even at the highest frame rate. The camera maintains excellent 312 x 260-pixel resolution at all recording speeds permitting detailed analysis of high-speed phenomena.
Easy-to-use, multifunction software
|
|
|
The i-SPEED camera system can be operated by almost anyone - just power on and it is immediately ready to start capturing your high speed events. No longer do users have to wait for the PC to power up - connection to the RCP (Remote Control Pad) or Olympus CDU (Camera Display Unit) allows full control of all camera functions. Immediate data analysis is possible to allow decision making at the source, making measurements on images that are synchronized to other data events with a live graphical display.
|
|
Based on a camera architecture first introduced with the Phantom® v12.1, the v640 provides a 4 megapixel sensor and greater than 6 gigapixel/second throughput. That means full-resolution frame rates of over 1500 frames-persecond (fps), and 1920 x 1080 HD-resolution frame rates of over 2700 fps.
The v640’s high-resolution timing system yields a timing resolution of better than 20 nanoseconds. Frame rate, frame synchronization and exposure accuracy are all improved over previous generations of high-speed cameras. And, an external frame synchronization signal is available via a dedicated BNC for easier cabling and increased signal integrity. A GenLock input is available for synchronizing the playback of recorded cines to other video gear.
|
|
|
Shoot 1000 frames-per-second with the Phantom HD at 1920 x 1080 and 14-bits-per-pixel and you will need 3.6 GB of memory for each second of recording! A 4-second recording could take up to 15 minutes to save using standard Gb Ethernet. Equip the Phantom HD with a CineMag, and save the shot to non-volatile memory in about 10 seconds.
|
|
Behind USB uEye SE is a family of affordable and extremely compact industrial cameras with USB interface for professional use in automation, quality assurance, security technology and non-industrial applications.
By using the widespread USB technology our cameras can easily be connected to a wide range of systems.
uEye industrial cameras come equipped with a line of high-quality CCD and CMOS sensors. Our wide range of products extends from several models with VGA or Wide-VGA resolutions and a maximum of 87 full size images per second to high-resolution mega pixels cameras. Almost all these models are available with colour or monochrome sensors at the same price.
USB uEye UI-2410SE industrial camera models, VGA (640x480)
- 1/3" CCD sensor, global shutter, progressive scan
- max. 75 fps, 111 fps in AOI-mode with 320x240 pixels
- Exposure: 0,04 - 640 ms (freerun mode)
- Binning vertical
- AOI horizontal and vertical
- Asynchronous, universal trigger
- Digital out
|
|
Phantom Miro Airborne Camera
The Miro Airborne® is the best of our popular Miro 3 and Miro 4 cameras combined into a single unit ideal for Airborne® applications. Get the ruggedness and form factor of the Miro 3 with the secure, removable image storage of the Miro 4.
Designed and tested for Airborne® applications, the Miro Airborne® is an ideal digital solution. (Some Airborne®-specific environmental specifications listed below are target specifications still under validation -- Airborne® certification pending.)
|
|
The AVT Pike family consists of five fast and robust IEEE 1394b (S800) C-Mount cameras, which are equipped with highly sensitive high-quality CCD sensors. Each of these cameras is available in black/white with clear glas filter as well as in color with IR cut filter.
The cameras, operating in 14-bit mode, impress in almost any situation by their ability to produce highly sophisticated images. A wide selection of different resolutions between VGA and 5 MPixel (VGA, 1 MPixel, 1.45 MPixel, 2 MPixel, 4 MPixel and 5MPixel) leaves no wish unfulfilled and provides the right camera for all individual applications.
Due to its IEEE 1394b interface, it provides up to 62.5 MB/s and runs perfectly together with IEEE 1394a products in the same bus system.
|
|
|
|
|
|
Phantom HD 65 Camera
Our new Phantom digital widescreen cinema cameras aren't just about replacing film or video with some new technology, they're about creating a new way of seeing time.
The Phantom 65 lets you experience control over your shot in ways that you have never experienced in the past. With the Phantom 65, the 65mm cine frame now exists for you to experience in digital format.Exposure time is no longer dependent on the camera's frame rate or limited to a few shutter openings. The Phantom 65 lets you set the exposure time in increments of one microsecond. Apply shortened exposure times to achieve the look of a hard edge street video, or lengthened exposure times until you've captured the indefinable, unmistakable feel of film.
The Phantom 65 arrives with 8 Gigabytes of internal memory standard, 16 Gigabytes as an option. But this is just the start of methods we provide to store your work. Take advantage of the hot-swappable non-volatile solid state recorders -- our Phantom CineMags. These low profile modules mount snugly to the top of the camera body and store 256 or 512 Gigabytes each.
Digital imaging provides for multiple triggering and recording modes that can be tailored specifically for your application. Advanced camera setup and image file downloads using a common GB Ethernet connection are accomplished using a PC and the Phantom software. Image files can easily be converted to TIFF stacks, MOV, or AVI formats using this included software package.
|
|
|
|
|
|
Phantom HD Camera
This new Phantom is not just a high-speed camera, but an instrument that gives the cinematographer 35mm depth of field either at HD or 2K resolutions! The Phantom HD now combines the visual quality of high-definition imaging with the high frame rates of specialty cameras.
Whether your imaging needs encompass broadcasts of rapidly moving sports events, the production of commercials, a music video, an award-winning documentary, monitoring a rocket launch, or possibly you are an innovative cinematographer working on a special film project that needs "a new look" to tell the story, the flexibility and virtually limitless control of the HD will provide you with outstanding results.
The Phantom HD allows you to select any frame rate from 1 to 1,000 fps in increments of one frame per second at HD resolution. Shift the frame rate a little and move the scene to a slightly future viewpoint. Or shift the frame rate a lot and move the scene to some long passing moment in time. With the Phantom camera's shutter, variable to 1/500,000 second, and radically adjustable framing rates, you have seamless control of the duration, speed and time of a story element.
The HD can be configured for "live" broadcast or studio production and has a continuous video output that includes HD (720p, 1080p, 1080i) standards. Multiple triggering and recording modes can also be tailored to your application.
|
|
Phantom v12 Camera
The Phantom V12.1 has the highest throughput of any CMOS-based digital high-speed camera. At a chosen resolution, you'll get the fastest possible frame rate. At a chosen frame rate, you'll get the highest possible resolution.
Add sub-microsecond exposure for controlling motion blur, industry-leading light sensitivity, and advanced features found on no other high-speed camera and you have the ideal solution for your high-speed imaging needs.
|
|
|
The Phantom Miro eX-Series provides the perfect balance of resolution, speed, and light-sensitivity in a self-contained solution enabling anyone to capture high quality, slow-motion movies. A built-in touch screen display is used to set up the camera as well as immediately view results. Battery power means freedom from power cords. Flexible triggering helps you capture even the most challenging events. Removable CompactFlash™ memory provides safe, secure and portable storage for valuable slow-motion content.
|
|
Phantom v310 Camera
Vision Research sets a new standard for affordable, high-performance 1 megapixel digital high-speed cameras with the Phantom v310.
Take the wide view with our custom-designed 1280x800 CMOS sensor. The wide aspect ratio of the v310 allows you to keep moving subjects in-frame longer and see more of the event you are recording.
The v310 is controlled by our feature-rich Phantom Software. If you've used any Phantom camera before, you will know how to run the v310.
When you add Vision Research's CineMag and CineStation to your shoot you will be able to capture data at the highest throughput of the camera, down load it rapidly (i.e. 16 GB in approx 16 seconds), and have the camera ready for the next shot. This compares to 16 GB in 15 minutes or longer without the CineMag. Vist the CineMag product page.
The VRI Phantom v310 comes in two base models, either with or without a CineMag interface and comes in either color or monochrome configurations.
|
|
|
|
|
|
Phantom v5.2
Phantom® v5 series high-speed digital cameras have long been considered the workhorses of the Phantom® line, and our new v5.2 is set to continue this honored tradition.
Unlike the earlier v5's square image format, the v5.2 now offers a wider image window composed of 1152 x 896 pixels, supplying true megapixel full frame resolution. For most subjects this new rectangular aspect ratio will put more active pixels on your subject for higher image resolution.
The v5.2 is available in your choice of color or monochrome models supplying an impressive full-sensor recording speed of 1,000 frames per second, and reduced resolution settings provide rates of up to 148,148 fps.
The features you've come to expect on a Phantom® V-series camera are all there: Extreme Dynamic Range (dual-slope integration within a single frame), Continuously Adjustable Resolution (in 96x8 increments), Automatic Exposure, multi-cine recording, IRIG timing, and more.
The v5.2 is also rugged. The 1.5GB version is built for hi-g applications and does not require active cooling, optional higher capacity memory versions feature active cooling to maintain constant operating temperature and ensure highest picture quality. Plus, The v5.2 comes with a one year service contract bundled at no additional charge (optional extended coverage is also available).
If you are looking for a full featured high-speed digital imaging solution for your organization without breaking the budget, the new Phantom® v5.2 may be just what you have been waiting for.
|
|
|
|
|
|
Phantom v7.3
The Phantom® v7.3 supplies the blazing speed and high sensitivity needed to record extremely fast events.
Our v7.3 camera now includes a new turbo mode to increase recording speeds for selected windowed resolutions to as high as 500,000 pictures per second with 1 µsecond exposure times.
The monochrome v7.3 provides 14 bit image depth for extended gray scale image quality and light sensitivity. If you select a color camera, you have the opportunity to choose between 24, 36, or 48 bit images.
An extremely fast shutter controls image blur. The v7.3 offers continuously adjustable shutter speeds down to 1 µsec (1/1,000,000 second). This shutter is a true "snap shot," or "global" shutter, functioning at the pixel level, and these sensors are sensitive enough to take advantage of the camera's high speed capabilities.
This Phantom® camera can optionally be configured with the ability to record images in real-time directly from the camera! Phantom® v7.3 camera can be supplied with this optional ability to stream real-time image data to our external massive storage device known as the Image3.
|
|
|
|
|
|
Phantom v10
The Phantom® v10 has established a combination of recording speed and image resolution that will prove difficult for others to match.
The dynamic range and image detail seen in the v10 images provide a sense of realism that has to be seen to be believed. Maybe that is why it is used to provide super slow-motion for sporting events like Major League Baseball, Boxing, and the Super Bowl.
You will be very pleased with the v10's performance on shots in low light or when extremely long lenses are a project requirement.Extreme Dynamic Range® (EDR) to improve picture quality under harsh lighting conditions, auto exposure, and much more are all found on the v10.
The Phantom® v10 offers a recording speed of 480 full frame pictures per second. When reducing the resolution to 1920 x 1080 the speed jumps to almost 1,000 pps, and there are allocations to record at even higher speeds with further decreased image sizes. Shuttering is continuously varaible down to a rapid 2 µsecs (1/500.000 second).
The v10's uniqe enhanced mode allows you to boost the image quality in demanding lighting applications by reducing the maximum frame rate. We give you the power to choose.
By taking advantage of the Phantom®'s flexible triggering capabilities in combination with extended internal memory options, our customers now have the recording time they need for any application.
|
|
Phantom v9.1
As high-speed imaging systems have evolved over time, customers have begged for more speed and higher resolution. It is a real challenge to develop a system that offers both of these qualities. This is a difficult design task, and other critical parameters such as light sensitivity further complicate the issue of developing a fast, truly high resolution imaging system that is compact, user-friendly, and affordable.
One of the latest VRI responses to this speed/resolution challenge is our Phantom® v9.1. This camera supplies high speed recording along with resolution and image quality that would have been considered impossible to achieve just a short time ago.
If you have been looking for film quality images with speeds fast enough to meet you're most demanding requirements, take a serious look at the Phantom® v9.1.
|
|
|
This high speed 12 bit CMOS camera system, pco.dimax, comprises advanced CMOS and electronics technology. With its sensitive 12 bit dynamic it enables remarkable fast image rates of 1100 frames per second (fps) at full resolution of 2016 x 2016 pixel. The system features also a variety of trigger options to cover all offboard applications that have been required by the automotive industry. The image data are transferred via GigE Vision or USB2.0 interfaces. For preview purposes a DVI interface is integrated. The pco.dimax has a smart battery control, which allows a full operation for 1 h and a data backup for 6 h. The available exposure times range from 2 μs to 1 s. This digital CMOS camera system is perfectly suited for high speed camera applications such as material testing, offboard crash or impact tests or super slow motion movie clips.
|
|
pco.1200 s
This high speed 10bit CMOS camera system comprises advanced CMOS and electronics technology. With the new approach to integrate the image memory (camRAM) into the camera itself, it enables unmatched fast image recording with 820MB/s. The system features an excellent resolution (1280 x 1024pixel) and low noise. It consists of a compact camera with an external intelligent power supply. The image data are transferred via customer selectable standard data interfaces to a computer (IEEE 1394 (“firewire”), camera link). The available exposure times range from 1µs to 5s. This digital CMOS camera system is perfectly suited for high speed camera applications such as material testing, external crash testing or super slow motion movie clips.
|
|
|
|
|
|
Lumenera's Lm075 mini CCD USB 2.0 cameras
Lumenera’s new Lm075 mini CCD USB 2.0 cameras are designed for industrial and scientific applications,particularly those with low light conditions and tight
space constraints.
Measuring 44x44x56mm, these compact cameras offer the same performance as our enhanced USB 2.0 camera line, delivering outstanding image quality and
value. Features include new locking industrial mini USB and RJ45 GPI/O connector, multiple mounting points,60 fps at full 640x480 resolution, 100+ fps at 320x240 binning mode, and on-board processing. Both color and
monochrome product models are available.
Electronic Global Shutter provides capabilities similar to a mechanical shutter, allowing simultaneous integration of the entire pixel array, and then stopping exposure while image data is read out - idea for capturing objects
in high-speed motion.
Uncompressed images in live streaming video and still image capture are provided across a mini USB 2.0 digital interface. No framegrabber is required.
Advanced camera control is available through a complete Software Developer’s Kit (SDK), with sample code available to quickly integrate camera functions into OEM applications.
Hardware and software based synchronization trigger is provided standard. 32 MB on-board memory is available for frame buffering.
All Lumenera products are supported by an experienced team of software developers and application engineers. We understand your imaging needs and are here to help you with your integration and development.
|
|
|
|
|
|
Featuring outstanding picture quality, high-speed image capturing, and the digital 1394b interface, the XCD Series is perfect for high-quality industrial and manufacturing solutions.The XCD-SX90/SX90CR employs a unique CCD that achieves a frame rate of up to 30 fps at 1280 x 960 (SXGA) resolution. With this wide range of solutions, each with feature-rich benefits, itâ¿¿s never been easier to select the right camera for your specific machine vision applications. The XCD Series of cameras adopts the IEEE 1394b interface that supports the IIDC protocol. By using this interface, users can transfer images to a host PC at speeds of up to 800 Mb/s.
Moreover, because multiple cameras can be connected in a daisy-chain configuration, users can enjoy the benefits of simplified operation in a multi-camera system. When these XCD cameras are daisy-chained, Bus Synchronization and Broadcast Delivery are available. With Bus Synchronization, users can capture images from different angles simultaneously simply by sending a single trigger from the host PC. Broadcast Delivery allows users to capture images from multiple cameras using a software trigger instead of a hardware trigger, which helps to minimize the occurrence of false triggers. This function also allows users to change the settings of multiple cameras simultaneously.
Their compact design and rugged body enables the XCD Series to be integrated into a wide variety of industrial environments.
In addition, the XCD series incorporates features such as partial scanning, binning, and a hardware LUT (Look Up Table).
|
|
pco.inspector highspeed
This high speed 10bit CMOS camera inspection system comprises advanced CMOS and electronics technology. It is packed together with an excellent Tablet PC LM1600 into a case with batteries and tripod. Therefore, the inspection system can be used anywhere operated for more than 2 hours by its own batteries.
With the new approach to integrate the image memory (camRAM) into the camera itself, it enables unmatched fast image recording with 1GB/s. The system features an excellent resolution (1280 x 1024pixel) and low noise. It consists of a compact camera with an external intelligent power supply. The image data are transferred via customer selectable standard data interfaces to a computer (IEEE 1394 (“firewire”), camera link). The available exposure times range from 1µs (50ns optional) to 5s. This digital CMOS camera system is perfectly suited for high speed inspection applications such as production line fault detection and motion analysis.
|
|
pco.1200 hs
This high speed 10bit CMOS camera system comprises advanced CMOS and electronics technology. With the new approach to integrate the image memory (camRAM) into the camera itself, it enables unmatched fast image recording with 1GB/s. The system features an excellent resolution (1280 x 1024pixel) and low noise. It consists of a compact camera with an external intelligent power supply. The image data are transferred via customer selectable standard data interfaces to a computer (IEEE 1394 (“firewire”), camera link). The available exposure times range from 1µs(50ns optional) to 5s. This digital CMOS camera system is perfectly suited for high speed camera applications such as material testing, external crash testing or super slow motion movie clips.
|
|
|
|
|
|
Lumenera's Lu075 High Speed Camera
This high-speed USB 2.0 camera provides 60 fps at 640x480 pixels. Based on a high-quality 1/3" CCD sensor with fast global shutter - ideal for capturing objects in motion. Low light sensitivity provides capture in even low light conditions with 8 or 12 bit digital output. I/O control for synchronization with strobe and peripheral devices. Advanced camera functions are available through a comprehensive Software Developers Kit, with sample code and full technical support to quickly integrate camera functions into your application.
CAMERA SENSOR
Image Sensor 1/3" format, 5.8mm x 4.9mm array
Effective Pixels 640 x 480, 7.4µm square pixels
Frame Rate 60 fps at 640x480, 100+ fps 320x240 (binning)
Sensitivity High
Dynamic Range 60dB
Exposure Auto / Manual
White Balance Auto / Manual
Dimensions (W x H x D) 2.25 x 3.85 x 1.56 inches
Mass ~300g
Power Requirement USB 2.0 bus power, or external 6VDC, 500mA
Power Consumption ~2.5Watts
Operating Temperature 0° C to +50° C
Operating Humidity 0%-95%, Non-condensing
Interface Connector Standard USB 2.0 cable
Lens Mount C-Mount (CS-mount option)
Frame Buffer 1 frame buffer (optional expansion to 50 frames)
|
|
Alta Scientific Imaging Systems
Highest Speed, lowest noise, 16/12 bit dual digitization to >10MHz, TEC cooling to >55C. Lifetime warranty on CCD chamber seal. Fast USB 2.0 and 100Base-T Network Interfaces, advanced I/O control. The Alta imaging systems represent cost effective advanced imaging technology not found anywhere else.
For a full listing of Alta Series models please see:
Alta U Series USB 2.0 Cameras
Alta E Series Network Cameras
Apogee Instruments offers a broad range of professional imaging solutions. Over the years we have built an impressive list of satisfied customers. We are confident that you will find a solution to fit your needs at a cost that won't break your budget.
|
|
|
Hamamatsu has been a pioneer in the world of ultrafast science and technology, i.e. phenomena occurring faster than one billionth of a second. Streak cameras are an indispensable tool in the world of picoseconds and femtosecond phenomena, capturing information that no other instrument can provide. Hamamatsu Systems Division also offers dedicated streak camera systems for specific applications such as the C4780 - Fluorescence Lifetime Measurement System - as well as Picosecond Light Sources and Picosecond Photodetectors.
|
|
Lumenera's Lu075 High Speed USB 2.0 Industrial Camera
This high-speed USB 2.0 camera provides 60 fps at 640x480 pixels. Based on a high-quality 1/3" CCD sensor with fast global shutter - ideal for capturing objects in motion. Low light sensitivity provides capture in even low light conditions with 8 or 12 bit digital output. I/O control for synchronization with strobe and peripheral devices. Advanced camera functions are available through a comprehensive Software Developers Kit, with sample code and full technical support to quickly integrate camera functions into your application.
|
|
Ranger - The fastest camera in the world for three dimensional shape measurement!
The Ranger camera measures 3D features at unmatched speed producing a complete data set of the object measured. Providing a 3rd dimension adds height and shape measurement data, which can be critical when correctly classifying an object. Ranger is the key component in many market leading in-line inspection machines used in the Electronic, Semicon, Wood, Robot Vision, Plastic, Rubber and Food industries.
The Ranger acquires up to 35,000 profiles per second, each containing up to 1536 high quality 3D coordinates. This is more than 45 million 3D points per second!
The complete 3D calculation is done inside the camera and the ready-to-use 3D coordinates are sent directly to a standard PC via CameraLink or Gigabit Ethernet. This eliminates the need for expensive post processors.
|
|
|
|
|
|
Phantom CineMag & CineStation
High-Speed imaging is memory hungry
Shoot 1000 frames-per-second with the Phantom® HD at 1920x1080 and 14-bits of memory depth and you will need 3.6GB of memory for each second of recording!
Just getting that much data out of the camera can take minutes. Those are precious minutes you'd rather be shooting, maintaining the momentum and pace on set.
Introducing the Phantom® Cinemag® . Hot-swappable, non-volatile memory magazines for the Phantom® Digital Cinema cameras.
Cinemag® in HandThe Cinemag® comes in two sizes--256GB and 512GB. Record directly into a Cinemag® on the Phantom® HD at speeds up to 450 fps at 2048x1080. At higher speeds, record into camera RAM and "upload" to the Cinemag® in seconds. With the Phantom® 65, record directly into the Cinemag® at up to 90 fps. On both cameras, higher direct recording speeds are available at lower resolutions.
When a Cinemag® gets full, or when you are done with a series of shots, pop the Cinemag® off the camera and snap another one on. You can later use the camera as a "docking station" to view and download your high-speed movies. Or, use the Phantom® Cinestation® (available in late 2007) connected to a PC and keep your camera free for doing its job--shooting high-speed scenes. The Cinestation® supports both raw digital file and video workflows by providing a fast file download capability as well as the ability to play the Cine files stored on the Cinemag® over dual HD-SDI video outputs.
Access the data in the Cinemag® from the Phantom® Software, just as if you were accessing recordings stored on a camera.
|
|
Version 675 is the latest general release of the Phantom camera control software. This version includes support for the Phantom v12.1, v210, v310, v710, v640, Miro eX family and the 10Gb version of the CineStation as well as most other Phantom cameras, and includes many enhancements and support for new features like the internal and external mechanical shutters. It is a recommended upgrade for most Phantom users.
To see what is new, please read the Release Notes. Read back to the last revision you have installed to see all changes. Not all interim releases are made available for download, so your current release may be back a few pages.
To download this software, you must be an existing Phantom camera customer. Please be prepared to provide the serial number of one of your Phantom cameras for validation. After reviewing your request, we will send you an email with a URL to your personal download location.
|
|
