3700 Series Turnkey LaserStar Marking Systems
LaserStar’s turnkey marking systems offer the benefits of a non-contact, abrasion-resistant, permanent laser mark onto almost any type of material.
A wide range of standard and custom platforms are available incorporating LaserStar’s DPSS, Q-Switch laser source technology. Choose a portable platform or a custom designed workstation which offers the speed, reliability and flexibility required for meeting stringent quality control and process certification standards.
LaserStar marking systems range from a simple enclosure to an advanced, integrated XYZ motion for step and repeat laser marking or coordinated rotary motion for seamlessly marking around a circumference, all controlled through the marking software.
As a turnkey solution provider, LaserStar’s Applications Specialists will evaluate your marking or engraving requirements, define the application goals and objectives, specify and verify the correct marking platform, and define a complete system configuration to accomplish the desired results.
• Solar & Semiconductor
• Bio Sensor Production
• Thin Film Polymers
• General Marking & Engraving Automotive (Parts and Displays)
• ID Cards & Mobile Phones
• Medical Devices & Implants
• Electronics & Sensors/Instruments
• Industrial Components
• Manufacture of Processed Parts
|
|
The Yag200 laser offers the ultimate in efficiency for personalization applications.
Its excellent YAG beam quality ensures extremely precise, consistent and fine marking. A compact, quiet benchtop marking system, with a large counter-balanced door for easy loading and unloading of parts.
This versatile machine provides permanent marking on most metal, plastic and ceramic surfaces and requires no consumables. Automatic Z reference, digital positioning display, and the Point n’Shoot laser beam facilitate part positioning and marking, optimising productivity.
Laser:
_Diode pumped laser: 1064 nm
_Average power: 12 W
_Peak power: > 25 kW
_Security: CDRH Class 1 (EN60825)
Weight & dimensions (Laser included):
_ Enclosure dimensions: 590 x 827 x 806 mm
_Enclosure Weight: 75 kg
_CCU Dimensions: 483 x 184 x 376 mm
_CCU weight: 21 kg
|
|
|
|
|
|
3800 Series Turnkey FiberStar Marking Systems
FiberStar turnkey marking systems offer the benefits of a non-contact, abrasion-resistant, permanent laser mark onto almost any type of material.
A wide range of standard and custom platforms are available incorporating fiber laser source technology. Select a standard platform or custom designed workstation which offers the speed, reliability and flexibility required for meeting stringent quality control and process certification standards.
FiberStar marking systems range from a simple enclosure to an advanced, integrated XYZ motion for step-and-repeat laser marking or coordinated rotary motion for seamlessly marking around a circumference, all controlled through the marking software.
As a turnkey solution provider, LaserStar’s Applications Specialists will evaluate your marking or engraving requirements, define the application goals and objectives, specify and verify the correct marking platform, and define a complete system configuration to accomplish the desired results.
Solar & Semiconductor • Bio Sensor Production • Thin Film Polymers
General Marking & Engraving Automotive (Parts and Displays) • ID Cards & Mobile Phones
Medical Devices & Implants • Electronics & Sensors/Instruments • Industrial Components
Manufacture of Processed Parts
|
|
GRIP/EDGE machine gathers all the philosophies which decided the success of this machines.
- high production speed: up to 200 buttons/per minute !
- Low adjusting times (first automatic machine without collets) and high
- versatility
- precision
- exclusivity ( it can engrave the whole edge of buttons which is not possible for machines with collets ) and button locking system (patented)
The GRIP/EDGE machine encloses- in only one model - the possibility to carry out two different laser workings: frontal laser marking of finished buttons at high speed: up to 200 buttons/per minute .........after a few seconds by means of a simple set up
It marks the edge of buttons by means of a new device, reaching up to 120 butt./min
|
|
The Fantom F-30 is a world class CO2 Laser Marking and Engraving System for OEM integration and stand alone operation on manufacturing and assembly lines.
The F-30 is dimensionally the smallest CO2 laser marking system available on the market today. Wave guide resonator provides the smallest available physical dimensions and highest power/weight ratio.
Up to 1000 characters per second writing speed brings F-30 to the level of the fastest marking systems in the industry.
The F30SP is completely sealed and requires no gas connections. It is air cooled and does not require any water lines.
Combination of a low M2 high-quality laser beam and a unique fast rising square wave pulsing characteristics allows smaller focus spot sizes. The F30SP laser can be pulsed at repetition rates of up to 25kHz.
|
|
The CO2 laser marking is ideal for marking on:
Plastics
Wood
Glass
Product Packaging
Rubber
Standard Features of the MECCO CO2 Laser Marking System:
10, 30, 60 and 100 Watt models
Windows-based software interface
Integrated Safety Shutter
Industrial Computer
19” Rack Power Control Box
High Performance Scanhead
140mm square mark field (other field sizes available)
Real-time system controller
24 bit I/O Card
Two-Year System Warranty
Optional Accessories:
Visible Pointer for mark preview
100mm, 250mm and 305mm square mark fields
Class I Safety Enclosure
Rotary Indexer for cylindrical marking
XY and Z Class 1 Automated Workstations
Rotary Workstations
CO2 Laser Marking System Benefits:
Compact design for minimal footprint
45,000 hours + of laser lifetime before recharging
Mount in any orientation
Air-cooled design (no water or external chiller required)
Zero maintenance
Low cost of ownership
|
|
|
|
|
|
ProWriterTM F20
Blazing Fast Marking Times
High Repetition Rates Providing High Production Throughput
Exceptionally Clean Marks with little Heat Affected Zone
Means no detrimental effect on sensitive applications
High Contrast Marking Ratios
Important for Character & Logo, Visibility, Barcode & 2D Matrix Code Readability
Excellent for Marking : Metals, Plastics, Ceramics, Composites & More!
Annealing - Black surface marks on metals created by bringing carbon to the surface
Surface Etching - Creating high contrast surface marks by changing the material characteristics without material removal
Ablation - Shallow, permanent marks with some material removal
Engraving - Deep marks in all materials for performance or 2D, 2½ D and 3D effects
Ultra Compact Marking Head Design for Easy Integration into any Automation System
Integrated Fiber Laser Marking Systems for all Industries - Automotive, Aerospace, Commercial, Electronic, Medical, Tools & Tooling, Packaging, and Trophies & Awards
Automatic, Semi-Automatic, and Manual Parts Handling Systems
Most Powerful CAD/Graphics Based Software in the Laser Marking Industry - Laser Marking Studio
Total Software Control of all Marking & Engraving Processes with our Graphical Point & Click Interface
Advanced Interface for Seamless Coupling of Automation and Marking Parameters
3D Layering of CAD & Graphics Files
Most Comprehensive list of Barcodes & 2D Matrix Codes - includes free updates for two years
|
|
|
|
|
|
3800 Series Marking Sources
FiberStar Marking Sources offer the benefits of a Direct Metal Marking, non-contact, abrasion-resistant, permanent laser marking onto almost any type of material. High-speed, high precision, micro-marking FiberStar systems are ideal for a wide range of industries and integration applications.
FiberStar Systems offer state-of-the-art technology with the highest laser beam quality and more than 30,000 hours of maintenance-free operation. High precision markings are achievable on almost any type of material including stainless steel, strength alloys, carbide, copper, titanium, platinum, aluminum, as well as a wide variety of medical-grade alloys and plastics.
Identification text, serial numbers, corporate logos, 2-D data matrix, bar coding, graphic and digital images, or any individual process data can be produced with laser marking.
• Logos, certification symbols, barcodes,serial codes, and 2-D data matrix code
• Simple custom text, serial numbers, bitmaps, graphic and CAD-files (HPGL)
• Marking and cutting of foils and light-gauge steel sheets (i.e., labels) in
one cycle
• Rapid marking on precious metals with heat-sensitive materials
• Plastic materials: day & night design for items such as mobile phone
keyboards, dashboards, and other illumination components for aerospace
and automotive markets
|
|
LMF2000 fiber laser marker
Features:
- Largest Q switch range of 2-500 kHz
- High speed, High Contrast marks on plastics
- High speed annealing and engraving of metals
- XP & Vista Windows based software
- Rotary and XYZ integrated motion
- PC, touchscreen, pendant or standalone
- In line vision option
Miyachi Unitek's new LMF2000 Yb: fiber laser marker is designed for high speed laser marking, laser engraving, and laser ablation resulting in high contrast marks on both plastics and metals. With all the advantages of fiber technology, user configurable options and unique features the LMF2000 can be tailored for optimized production.
|
|
|
The i-Series Fiber Laser was specifically designed for maintenance-free OEM applications. It delivers a diffraction limited (M2<1.05) laser beam directly to the worksite via a metal sheathed single mode fiber cable. These compact service-free lasers are designed to operate under high shock, vibration and dust conditions, with relatively high humidity and temperatures. They do not require routine replacement parts or materials; they require only a low voltage power source. Wall-plug efficiencies up to 50% result in a compact size, reduced utilities, and trouble-free air cooling. Fiber-to-fiber architecture means a robust, monolithic design with no optics to align or maintain, no mechanics to stabilize, and with the focusable power and high power densities needed for the most demanding applications.
|
|
|
|
|
|
FiberTower™ Series is the new generation of Fiber Laser Material Processing Systems for Direct Parts Marking, UID (Unique Identifier), and Deep Engraving. It is the most advanced, compact, industrial grade, mid size, Fiber Laser Marking and Engraving systems available on the market. FiberTower™ series employs the new generation of solid state Ytterbium fiber laser systems of near infrared spectral range (1060-1080nm) with a unique combination of high peak power, ideal beam quality, fiber delivery and highest electro-optical wall-plug efficiency
The result is a cutting-edge system that can be integrated into any production line at a cost reduction of nearly 25% over traditional Fiber Laser Systems. Considering the cost reductions of no consumables and low power consumption, the FiberTower™ Series Laser Systems are now the most cost effective, eco-friendly and flexible apparatus of Direct Parts Marking, UID, and Deep Engraving in the Aerospace, Automotive, Medical, Defense, Semiconductor and other markets. Not only can this series match 80% of all industrial applications but it will save any consumer money on operating cost and proves the most affordable system on the market.
The FiberTower™ Series Equipment is safe, compact, and service-free, designed to meet individual marking needs with the ability to mark a wide variety of materials using many different techniques including Direct Parts Marking (DPM) of alphanumeric, logos, serial numbers, part numbers, lot and date codes, schematics, graphics, deep engraving and more. It can be delivered as a stand-alone system that can be integrated into any production line or with full turnkey workstations.
|
|
|
|
|
|
The Q-Switched Fiber Laser Marking Kit is a safe, state of the art, low-cost alternative for laser marking with Nd:YAG and Nd:YV04 lasers(Lamp-pumped, Side-pumped Diode and End-pumped Diode).
It features independent components, including a Q-switched Fiber Laser, Scanning Head, PCI Control Board, Power Supply, and software configured for your specific application.
Main Features:
- Up to 2mJ Energy Per Pulse
- Q-Switched Fiber Laser With Pulse Energy - 80 to 500ns Pulse Duration
- Excellent Beam Quality (M2 < 1.05)
- 10 to 80 or 20 to 100kHz Tunable Repetition Rate (depend on the laser module)
- 1064 -1080 nm Center Wavelength
- Fiber Delivery - Fiber Outputs With Integrated Beam Expander and optical isolator
- Up to 50% Wall-Plug Efficiency
- Maintenance Free Operation - 50,000 to 100,000 Hours MTBF
- Compact Rugged Air-Cooled Package
- Sealed Optical Path From Laser to Scan Head
- Custom OEM Specifications Available
- No alignment required
- Takes 110 Volts standard plug.
- Laser draws only 300 watt (less than computer).
- 2 year warranty on laser
- 5 years warranty plan
|
|
|
|
|
|
MECCO’s fiber laser is perfect for marking on:
Steel, Stainless Steel and Titanium
Anodized and Painted Aluminum Tags
Plastics
Labels
Standard Features of MECCO Fiber Laser Marking Equipment:
10 Watt and 20 Watt models
MeccoMark™ Windows-based software interface
Integrated Safety Shutter
Industrial Computer
Power Control Box
High Performance Scanhead
110mm Square Mark Field
Real-time System Controller
I/O Interface
Two-Year System Warranty
Optional Fiber Laser Accessories:
Visible Pointer for mark preview
175mm, 250mm and 305mm square mark fields
Class I Safety Enclosure
Rotary Indexer for Cylindrical Marking
XY and Z Class 1 Automated Workstations
Rotary Workstations
Fiber Laser System Benefits:
Compact design for minimal footprint
30,000 hours + of laser lifetime
Mount in any orientation
Air-cooled design (no water or external chiller required)
Zero maintenance
Low cost of ownership
MeccoMark™ Fiber Laser Marking Software:
USB 1.1 or 2.0 interface
For Windows 98/2000/XP
Intuitive, easy to learn graphical interface
Highest marking quality
Serialization and text merge
Radial and vertical text
Import many vector and graphic file types
|
|
Powered by 110/230VAC with no water-cooling requirements, these units are extremely
dependable over a long life, and are backed by a full TWO-YEAR factory warranty on the diode light source - one of the longest warranties in the laser industry.
Telesis' Zenith 10FQ was named a Top 100 Product of the Year in the November 2003 Issue of MEDICAL PRODUCT MANUFACTURING NEWS, page 37.
Innovative, compact and flexible ZENITH ® Pulsed Fiber to Fiber Ytterbium Lasers are perfectly suited for marking applications that require 24/7 "set and forget", unattended operation. Select the ZENITH ® 10FQ for low to medium speed applications and the ZENITH ® 20FQ when higher power/faster process speeds are required. The 20FQ features upgraded power and the additional long-term safeguard of a built-in, polarization/optical isolator.
|
|
Laser marking system designed to apply and verify ECC 200 2D matrix symbology directly on stainless steel beer kegs of various sizes. Ytterbium fiber laser quickly and permanently marks the 2D matrix code without compromising the strength of the pressurized keg.
Ytterbium fiber laser is a "0" maintenance device
Also features a combination barcode/2D matrix code reader.
|
|
The MISTRAL marking laser was introduced as one of the first diode-pumped laser systems, and has since been setting new standards in laser technology!
Whether it is used as a seated workplace to mark small numbers of parts, or is integrated into production lines for automatic operation – there are no limits to the flexibility of this laser. The MISTRAL's main field of use is in marking metals (engraving, annealing colors), plastics (color change, material debris) and ceramics.
The Mistral is available with 50 W and 120 W.
Advantages of this all-rounder: Nearly all materials can be permanently marked, are forgery-proof and have an excellent graphical quality. The high marking speeds and its ease of use bode well for future working processes!
|
|
|
|
|
|
Traditionally, for applications requiring high peak energy such as deep engraving and high throughput, flash lamp lasers were the only marking system options. With our line of Diode Pumped Lasers using Nd:YAG as a medium, MECCO now offers a wider variety of laser sources with diode resonators that are highly efficient, provide longer laser lifetime, and have zero consumables.
Diode pumped lasers feature q-switch control for varied marking applications and an internal chiller that eliminates the need for external cooling.
With the ability to maximize peak power, MECCO’s diode pumped lasers are ideal for marking on a variety of different materials. For surface marking on medical plastics and black annealing stainless steel, the diode pumped laser is the cost-effective solution for peak power applications.
MECCO’s diode pumped laser is perfect for marking on:
Anodized and Painted Aluminum
Deep Engraving in Steel
Black Anneal on Stainless Steel and Titanium
Plastics
Labels
Features of MECCO Diode Pumped Laser Marking Equipment:
10,000 hours of lifetime per diode pack
20W, 50W, and 100W models
Q-switched operation for highest peak energy
2x-8x variable beam expansion for versatility
5 standard lens sizes for field sizes 2” to 12” square
Modular design
Internal cooling unit, no water chiller required
Lower cost of operation than flash lamp lasers
Windows-based software interface
|
|
|
|
|
|
For high reliability and flexible operations, MECCO’s Flash Lamp Lasers, using ND:YAG as a medium, are the most versatile of laser marking systems.
Whether you are surface-etching 2D Data Matrix and serial numbers or deep engraving bumpy bar codes and logos, MECCO’s flash lamp laser can do the job.
Since the user can control peak power, beam expansion, and field sizes, the flash lamp laser has the flexibility to mark on materials from hardened steel to soft plastic. It truly is the most versatile and flexible laser on the market.
The Flash Lamp Laser is perfect for marking on:
Anodized and Painted Aluminum
Deep Engraving in Steel
Black Anneal on Stainless Steel and Titanium
Plastics
Labels
Based on industry-proven technology, the flash lamp laser can work in all types of environments and applications. Its rugged design ensures long flash lamp laser lifetime with minimal maintenance.
Features of MECCO Flash Lamp Laser Marking Equipment:
50W, 85W, 100 and 150W models
Q-switched operation for highest peak energy
2x-8x variable beam expansion for versatility
5 standard lens sizes for field sizes 2” to 12” square
Modular design
Water-cooled design
Windows-based software interface
|
|
General description
Application: Marking control icons on high-end appliance tops
Features:
- 50-watt diode-pumped Nd:YAG laser
- 16-bit high precision galvanometers
- 10"x10" marking field
- Programmable linear laser motion
- Part length sensors for four discrete appliance families
- Manually adjustable Z-axis laser motion with digital position display
|
|
Eclipse® 100LY Lamp-Pumped Laser Marking Systems
For the Ultimate in High Speed, High Quality Product Identification, the Eclipse® 100LY Lamp-Pumped Laser is designed for hard surface treatments. It's the powerful, reliable choice for marking titanium and their high strength alloys, medical implants and hard plastics.
|
|
|
|
|
|
LaserStar’s turnkey marking systems offer the benefits of a non-contact, abrasion-resistant, permanent laser mark onto almost any type of material.
A wide range of standard and custom platforms are available incorporating LaserStar’s DPSS, Q-Switch laser source technology. Choose a portable platform or a custom designed workstation which offers the speed, reliability and flexibility required for meeting stringent quality control and process certification standards.
LaserStar marking systems range from a simple enclosure to an advanced, integrated XYZ motion for step and repeat laser marking or coordinated rotary motion for seamlessly marking around a circumference, all controlled through the marking software.
As a turnkey solution provider, LaserStar’s Applications Specialists will evaluate your marking or engraving requirements, define the application goals and objectives, specify and verify the correct marking platform, and define a complete system configuration to accomplish the desired results.
• Solar & Semiconductor
• Bio Sensor Production
• Thin Film Polymers
• General Marking & Engraving Automotive (Parts and Displays)
• ID Cards & Mobile Phones
• Medical Devices & Implants
• Electronics & Sensors/Instruments • Industrial Components
• Manufacture of Processed Parts
|
|
General description
Application: Engraving alpha-numerics on flat and curved surfaces.
Features: A 25-watt CO2 laser system with bowl feeder contained in a noise reduction enclosure.
|
|
The Fibre200 is the ideal solution for high volume personalization.
Able to mark on both metals and plastics at unparalleled speeds in high resolution. A versatile machine providing permanent, black marking for optimum productivity. No additional consumables or external cooling system required.
Minimal maintenance needed, long diode life span (MTBF of 100 000 hours). Its speed and marking quality offer complete satisfaction.
Laser:
_Pulsed fibre laser: 1,064 nm
_ Average power: 20 w
_Peak power: 12kw
_Safety: CDRH Class 1 (EN60825)
Size and Weight:
_Casing dimensions: 590*827*806 mm
_Casing weight: 75 KG
_CCU dimensions: 483*184*376 mm
_CCU weight: 17 kg
|
|
IC Tray Marking Systems are designed for marking parts transported in JEDEC trays. The flexible, graphical operator interface provides the easiest setup for IC and JEDEC tray configurations. Our systems allow the users to serialize and mark parts including those in tray configurations with missing or an odd numbers of parts.
BCL's systems verify part position in the tray, pin location for orientation of the part, and the part type to ensure the correct part is loaded into the tray. Our systems are fully automated and provide real time power measurement to ensure marking parameters are within tolerances before marking begins.
|
|
The level of flexibility provided with frequently changing motifs and the
very low workstations costs make the ALFALAS® "CT-60" benchtop laser particularly well suited to use in the advertising material industry, for example for promotional gifts.
The ALFALAS® "CT-60" benchtop laser unit is a low-cost alternative to the classic way of producing clichés by etching and exposure.
The tampon printing cliché is produced in a few minutes using a digitalised inscription layout in a vector format (*.ai or *.plt).
|
|
CO2 Lasermarker TX020
As the first real alternative to conventional ink based product coding systems – TAUFENBACH presents a new aircooled CO2 Lasermarker TX020. Core component of the new system is the ultra-compact CO2 laser tube - Made in Germany - out of own production.
- worldwide smallest CO2 Laser Marking System
- an alternative to established ink based - systems
- very low operation and investment costs
- Laser Marking System for production lines
- ultra - compact Marking head (2,5 kg)
- touch screen operation panel
- Marking speed up to 1700 characters/ sec
- Ethernet, USB and RS232
- 20 watt
|
|
QUADRA CO2
The QUADRA series perform one of the most complete solutions available on the market for the buttons marking and engraving with a CO2 laser. QUADRA is able to automatically select, load, centre, mark (on the face and on the edge) and unload more on 100 buttons/min. with a size 12-60 Lin and 10 mm of thickness. For any button QUADRA is able to do automatically a visual check of the quality and discharge the rejected pieces and the correct positioning and centering of the marking in function of the button holes position.
|
|
Features and benefit:
1.High fiber laser output power
2.available for OEM application.
3.Wider marking range
4.Long and lasting working time
5.Marking characters or graphics with depth(2mm)
6.Precision and fine marking lines(0.1mm)
7.Easy operation and maintenance
8.Marking area:70*70mm/100*100mm
9.Aplication:metal,PC keyboard, PVC, acrylic, electric Board.....
|
|
Miyachi's new ML-7320C Yb: fiber laser marker is designed for high speed laser marking, laser engraving, and laser ablation resulting in high contrast marks on both plastics and metals.
With all the advantages of fiber technology, user configurable options and unique features the ML-7320C can be tailored for optimized production.
- Largest Q switch range of 2 – 500 kHz enables high speed high quality marking on steels and plastics
- Full featured user friendly software
- Complete integration flexibility with PC, touchscreen, standalone through I/O control or remote programming, LAN connectivity
- Integrated motion control for XYZ and rotary
- Unique guide beam implementation enables class 1 with guide beam on
- Multi language capability
- Low cost of ownership
|
|
|
|
|
|
Laser Marker ML-9001A
CAN EVEN PROCESS AND MARK WORKPIECES WITH A HIGH REFLECTION RATIO
LD-pumped YVO4-Laser with Second Harmonic Generation (SHG).
DESCRIPTION
Second Harmonic Generation (SHG) is a visible-light laser with a wavelength of 532nm (green), which is half of the fundamental wavelength (1,064nm).
Features of SHG
SHG can mark on silicon wafers, WLCSP, thin memory cards, thin ICs etc. without damaging the internal device.
It enables very precise and high contrast marking on a wide range of materials as plastics, copper and gold.
Compact and lightweight
Ideal for production lines where space is limited.
Energy efficient
Low power consumption, thanks to a highly efficient laser diode.
Fully air-cooled
Maintenance is reduced to a minimum.
Low maintenance
Except cleaning of the protection glass and two air filters no further maintenance is required. Depending on usage more extensive maintenance / replacement of consumables might occur after several years.
Application software LM Draw for creating and executing processing data.
- 2D code marking is standard
- Supports DXF file reading
- Auto hatching function
- Automatic write order optimization function
- Thanks to the strong drawing functions, processing data is created efficiently.
Guide light function
This function shows the work writing position and processing area.
Various processing areas
Choose the best processing area for the shape of your workpiece and application
Automatic backup function
The time and operation count can be specified and the operation log is backed up automatically.
|
|
|
|
