APEM, a comprehensive range of professional Led indicators
- PROFESSIONAL LED indicators for panel mounting
- Seven different diameters: 6, 8, 12, 14, 16, 19 and 22 mm
- Three different bezel shapes: prominent, recessed and flush
- Bezel materials plated in bright chrome, black chrome and satin chrome
- Solder lug, quick-connect, professional pin or professional wire terminals
- Standard diffused red, green, yellow, blue and white LEDs, plus bi-colour, tri-colour and flashing LEDs
- Complementary range of super bright, water clear LEDs also available (sunlight visible)
- Optional panel sealing to IP67
Integral resistors permit direct professional connection to 12V, 24V,110V and 230V.
APEM, the broadest offering in the switch market: miniature switches, industrial switches, LED indicators, professional switching professional panels and professional joysticks. |
|
• Filament lamp or neon illumination
• LED illumination, dc or ac ratings (mains 125/250V dual rating)
• Red, yellow, green, clear or blue colours (as standard)
• Panel mounting holes from 5.8mm to 25mm diameter
• Front of panel sealing to IP54
• Wide choice of profiles
• Circular and rectangular formats
• RoHS compliant
|
|
VCC's CMS 322 lens is designed to provide a means of protecting equipment from both drip or splash conditions while displaying panel or circuit board mounted LEDs.
The traditional methods of moisture sealing have been the use of bulky military style indicator lights requiring o-rings, nuts and washers. While these units are effective, they do not provide aesthetics desired in today's modern equipment designs. As a result, engineers faced with the problem of moisture sealing are forced to design elaborate display panel windows with special gaskets. When limited by design funds, engineers have attempted to industrial seal standard panel professional lenses or indicator lights with adhesives such as RTV. These methods are very expensive in component hardware, extremely labor intensive and lack required aesthetics.
VCC's CMS 322 low-profile lens is equipped with a moisture sealing gasket. Tests by an independent environmental testing laboratory have shown that the lens provides an effective seal against splash and drip conditions. In addition to the water tests, the lens and retaining systems were tested up to 6Gs of shock and from 0 to 2000Hz of vibration. An operating temperature test from -40°C to +85°C and a UV test were also performed. The conclusions attained upon completion of these tests were that the CMS Series lens and the retaining systems used exceeded all test criteria. |
|
The pleasing aesthetics of Fulleon's remote indicators provide a refreshing contrast to other products available on the market.
- Attractive Design.
- Multi-Purpose Indicators.
- Wide Operating Voltage. |
|
| ... products without technical information |
| |
Latest technology Light Emitting Professional diodes (LEDs) configured into a high-density matrix. This advanced range of Led readout Panels is ideally suited to a wide variety of applications such as Loading-Bay Signalling, Shutter Door Status, On-Site Traffic Management, Dockside Signalling, Factory Control, “FIRE” Alarm Warning, “STOP” Signalling, etc.
Standard 24Vdc, 115Vac and 230Vac models are available and all units are enclosed in an IP65 UV-stabilised polycarbonate housing (200x150x80mm) for protection against the elements.
Single colour units employ a front lens the same colour as the indicating LEDs, whilst dual colour units employ a neutral ‘smoked’ front lens.
Standard colour combinations are shown; other colours and colour combinations available from a choice of Red, Amber, Green, Blue or Clear, available to special order.
|
|
DF30 Display Facia is available in four different window sizes, extra small, small, medium and large as listed below.
Any combination of these window sizes can be supplied in any format, mixed as required in a single display to make up the appropriate matrix required.
Extra Small (30x15mm)
Small (30x3Omm)
Medium (60x3Ornm)
Large (60x6Omm)
|
|
| There is plenty of information in today's business world. Information is useful only when given to the right person at the right time in the right way. We give the information the right meaning. In traffic as well as industry. |
|
DF30 is available in four different window sizes, extra small, small, medium and large as listed below.
Any combination of these window sizes can be supplied in any format, mixed as required in a single display to make up the appropriate matrix required.
Extra Small (30x15mm)
Small (30x3Omm)
Medium (60x3Ornm)
Large (60x6Omm)
|
|
PAN3V
Format DIN 48x48
The PAN3V is a small economic panel especially studied for the starting cupboards or the electric control panels.
It makes it possible to announce :
- 3 gathered information.
- "Start, stop, default".
- "presence of the 3 three-phase tensions" of an electric departure.
Supply :
- Low voltage (12Vac/dc, 24Vac/dc, 48Vac/dc).
- Hight voltage (130Vdc, 220Vac, 380Vac).
Equipped with 3 removable indicators LED "high luminosity" (possible colors: green, yellow, red, blue, white), of its connector suppliers scewless removable, its test lamp optional outside, it is very easy to install and will save to you an precious time.
Option :
Lamp test output. |
|
When size matter ! Discover the economical new range of Red Lion Large Professional displays : the LD series, to visualize your main production datas from a distance.
LD
Large Display Professional counter and Rate Indicator
- 2.25" & 4" High Red LED Digits
- Available in 4 or 6 Digit Versions
- Single or Dual Counter with Rate Indicator
- Programmable Scaling and Decimal Points
- Programmable User Input
- AC or DC Powered
- 5 AMP Form C Relay
- Aluminum NEMA 4X Case Construction
LDT
Large Display Timer and Cycle Counter
- 2.25" or 4" High Red LED Digits
- 6-Digit Bi-directional Timing Capability
- 5-Digit Cycle Counting Capability
- Selectable Timer Ranges and Operating Modes
- Elapsed Timer and Preset Timer Functionality
- Serial Communications (Selectable RS232 or RS485)
- Programmable User Input
- AC or DC Powered
- 5 AMP Form C Relay Output
- Aluminum NEMA 4X Case Construction item
LDA
Large DC Volt/Current/Process Display
- 2.25" & 4" High Red LED Digits
- Programmable Scaling and Decimal Points
- Programmable User Input
- Dual 5 Amp Form C Relay
-Aluminum NEMA 4X Case Construction
-RS232/RS485 Serial Communications
- Universally Powered
LDSS
Large Serial Slave Display
- 2.25" or 4" High Red LED Digits
- Displays up to 6 Digits of Serial ASCII Data
- Dual Display Buffer Allows Alternating Displays
- Selectable RS232 or RS485 Serial Interface
- Connects Directly to Red Lion Products with Serial
- Programmable User Input
- AC or DC Powered
- Aluminum NEMA 4X/IP65 Case Construction |
|
