IKO Linear Bushing is a high precision linear motion rolling guide which travels along a shaft to achieve endless linear motion. In the external cylinder, a retainer, steel balls, etc. are compactly incorporated. Wide variations in size are available for selections suitable for each application.
Features:
Low frictional linear motion
Steel balls are accurately guided by a retainer, so low frictional resistance and stable linear motion can be achieved.
Simple replacement of conventional plain bushings
It is easy to use Linear Bushings instead of conventional plain bushings, because both types are used with a round shaft, and no major redesign is necessary.
Wide variations
For each dimensional series, standard, adjustable clearance and open types are available with and without seals, so the best linear bushing for the application may be selected.
Stainless steel type
Linear Bushings made of stainless steel are also available. This type is suitable for applications where corrosion resistance is important.
|
|
|
|
|
|
Linear rolling bearings
Linear rolling bearings are available as monorail guidance systems, track roller guidance systems, shaft guidance systems with linear ball bearings, flat cage guidance systems, guidance systems with linear recirculating roller or ball bearing units and as driven units (actuators and tables). Furthermore, INA also manufactures special miniature guidance systems for small design envelopes such as those in mechatronics and precision engineering. These very compact elements with very high load capacity, low friction and high rigidity are available as cage or recirculating systems. Due to their compact design, they can often replace solutions requiring significantly greater space.
Linear plain bearings
While in rolling bearing arrangements the bearing elements are separated by rolling parts (the rolling elements), in plain guidance systems the movable component slides on a static guideway or shaft. Depending on the type of guidance system, the sliding layer is applied to the movable or the rigid component. Lubrication is carried out by means of lubricants embedded in the sliding layer.
|
|
Precision Linear Bearings Series L
Description
Bore Diameter 2 ... 6 mm
Outer Diameter 4 ... 12 mm
Load Rating, Static 8 ... 250 N
Load Rating, Dynamic 10 ... 245 N
Precision Linear Bearings DBL Series
Description
Bore Diameter 3 ... 25 mm
Outer Diameter 7 ... 40 mm
Load Rating, Static 27 ... 1332 N
Load Rating, Dynamic 26 ... 1162 N
|
|
OILES 500 Guide Unit BK Type
Guide unit bearing
STANDARD PRODUCT
CUSTOMIZED PRODUCT
Guide unit bearing for reciprocating motion using OILES 500
OILES 500 Guide Unit is for reciprocating motion with high durability by employing OILES #500SP bearing at the sliding area.
Features:
- High rigidity guide unit with mechanical strength.
- Available in different product length from between 20 to 40 inside diameter.
|
|
LM76 E-Z...GO linear ball bearings are designed to meet or exceed the industry standard in linear ball bearings. We offer A Series, Self Aligning
and standard, drop-in replacement pillow block bearing assemblies. Moreover, as an engineering/manufacturing company, we believe that we are your best resource in engineering the right solution to your application requirements. That's right, we design the right solution because we offer - and are well versed - on so many selections. We have been tempered by so many interesting and challenging applications. Our experience spans 68 plus years and our product line is extensive. But...extensive product line is one thing, knowing what your talking about is another.
|
|
|
The TRCA series is a pre-engineered carriage assembly which has either SLBO or DLBO pillow blocks mounted to a 6061-T6 black anodized precision machined aluminum plate. The pillow blocks are doweled to the carriage plate and are pre-aligned to match LinTech's TRSA series shaft assemblies. The use of a TRCA carriage assembly and a TRSA shaft assembly in a mechanical positioning application greatly reduces the time consuming process of mounting & aligning two shafts and pillow blocks. Each carriage surface is precision machined which allows for accurate mounting of customer loads. Also, carriage assemblies are available with pre-machined stainless steel inserts, which allows easy mounting of customer loads to the carriage plate. Carriages are provided with pillow blocks for shaft diameters from 1/2 to 2 inches, and come in standard carriage lengths from 6 to 30 inches.
|
|
This NB Slide Rotary Bush is designed to enable perfect, rectilinear/rotary complex motion. It offers considerable space-saving compared to conventional combinations of rectilinear and rotary bearings.
The Slide Rotary Bush therefore requires less installation space.
|
|
Linear Motion Components
Including spline shafts, linear bearings and linear motion shafts
Spline shafts, linear shafts, linear bearings
Spline Shafts provide anti-rotation for one axis motion or a drive mechanism with rotation for two axes of motion. They are designed for light to moderate load applications, where low cost, low friction, and long life are primary design considerations.
Range Details
* Spline shafts, basic and anti-backlash, Ø3.18 to Ø12.70mm
* Linear motion shafting, standard Ø3 to Ø12mm, hollow Ø10 to Ø12mm
* Linear bearings, corrosion resistant Ø3 to Ø5mm, precision Ø6 to Ø12mm
|
|
The NB slide bush is a linear motion mechanism, utilising the rotational movement of ball elements. It can be used in a wide variety of applications, including transportation equipment and semi conductor production equipment.
The NB stroke bush is a linear and rotational motion mechanism utilising the rotational motion of ball elements between an outer cylinder and a shaft. Smooth motion is achieved under high-speed and high-acceleration conditions. The NB stroke bush may be conveniently used in a wide variety of applications.
The NB slide rotary bush is a highly accurate rigid component providing smooth continuous linear and rotational movement. It is much more compact than a standard slide bush with separate rotational bearings.
|
|
|
Linear ball bearings are bushings with recirculating ball tracks which provide low friction movement and the possibility of unlimited stroke. With the range of linear ball bearings, plain bearings and accessories it is possible to construct simple and economical linear guiding systems to suit a wide variety of applications.
|
|
MicroGuide
Features
* Industry standard, drop-in replacement
* 440C stainless steel construction (little or no lubrication required)
* High precision accuracy (up to ±0.01mm)
* Whisper quiet movement
* Extremely smooth operation
* Unlimited Stroke
* Gothic arch ball groove geometry enables single rail application
* Technical engineering support from Danaher Motion
* Contact Danaher Motion for custom lengths and configurations
|
|
MISUMI provides more than 1 Million mechanical components for the assembly automation. We delivery components europewide in averagely 6-8 days GUARANTEED delivery from the day of purchase, stock items available from 2 days delivery.
MISUMI 24/7 Web Ordering System (WOS) represents a full-fledged e-Commerce solution, which you can use, for the first time, independently from the catalogue in paper form, to configurate MISUMI products, submit quotations and place orders.
For more information about MISUMI, WOS or for ordering a catalogue please visit: www.misumi-europe.com
MISUMI - Precisely Meeting Your Demands
|
|
Linear system - Linear ball bearings
Characteristics
1. Compact design
Our linear ball bearings carry out integration on the most reduced space from 4 to 6 lines of balls, from where a high degree of accuracy of bearing under request for all the orientations of load.
2. Maximum loading of use
We guarantee a load of higher maximum use by the exclusive use of nanomaterials of authenticated quality and by a technique of advanced manufacture.
3. Maximum precision
The optimal play ensituation of work is one of the most delicate points for the use of the linear ball bearings. We bearing units are delivered with exact borings and tolerances.
|
|
|
Linear bushing guides can be put together from over 1,000 designs and variations to meet all demands and applications, which means that users can select exactly what they require for every task.
|
|
|
|
|
|
The linear recirculating bearing are produce in economic for standard application and for precision application.
The linear recirculating bearing are composed by a cylindrical outer ring, by a cage that retains the balls, by two end rings to retain the cage and/or, when required, contact seals.
All of the components are designed and assembled to optimize the unit performance.the outer ring is suitably hardened to provide the longest possible life expectancy.
The cage made of steel, stainless steel or engineered resin, depending upon the type of bearing selected, provide the retention and allow the proper recirculation of the balls.
Characteristics of linear bearings :
1. High rigidity
- Linear bearings with steel outer ring offer high rigidity due to the large number of balls in contact. The units can be supplied with a steel cage and, when low weight is required, with resin cage.
2. Easy of assembly
- The standard units can carry load in every direction. The large variety of housing units and shaft supports allow simple and easy mounting.
3. Ease of replacement
- These units follow internationally recognized boundary and are therefore dimensionally interchangeable with competitive units.
Replacement due to wear or damage is quick and simple.
Linear bearings can be supplied in the following versions :
- Closed type
- Open type
- Flanged type
- Double and triple type, with and without flange,
- Center mount flange type,
- In steel, stainless steel,
- Self aligning,...
|
|
RKB Standarized self-aligning units of thermoplastic housings with inserts made by stainless steel fitted with normal grease or with FDA approved no-toxic grease) or chrome steel.
Pillow blocks UCP and flanged (4/UF and 2/UFL clamping bolts) units are supplied with plastic end cover and grease nipple.
RKB linear bushes.
|
|
While the NB stroke bush has a limited rectilinear traveling stroke, it works with minimal wear resistance and enables smooth linear/rotary complex motion. It can therefore be used with a variety of devices.
The NB stroke bush is designed to allow the ball bearings to rotate smoothly. The finely ground outer case contains a retainer which forms a staggered arrangement of the steel balls in machined holes on its inner surface. Each ball in the retainer may rotate smoothly in its individual hole while the outer case moves in a rotary and/or rectilinear reciprocating motion.
|
|
HIWIN linear bearings enable high precision linear motions on round shafts by utilizing endlessly recirculating balls.
The patented recirculation curve enables HIWIN's linear bearing to sustain heavy loads with low noise and high stiffness.
HIWIN's diverse lines of linear bearings perform under almost any environmental conditions and load capacities to satisfy a wide range of applications.
|
|
The NB slide bush is a linear motion mechanism, utilising the rotational movement of ball elements. It can be used in a wide variety of applications, including transportation equipment and semi conductor production equipment.
The NB stroke bush is a linear and rotational motion mechanism utilising the rotational motion of ball elements between an outer cylinder and a shaft. Smooth motion is achieved under high-speed and high-acceleration conditions. The NB stroke bush may be conveniently used in a wide variety of applications.
The NB slide rotary bush is a highly accurate rigid component providing smooth continuous linear and rotational movement. It is much more compact than a standard slide bush with separate rotational bearings
|
|
WM Berg stocks a vast array of bearings to suit every design need, such as: The Ball, Needle Roller, Sintered bronze, Oil-less, Teflon, Thermoplastic, Thrust, Roller Thrust, Spherical and Linear ball.
Sizes range from 1/8" (3mm) to 1" (25mm) diameter. Ball Bearings are offered in ABEC-0 through ABEC-7 qualities. Our shafting can be obtained in inch or metric, threaded, with rough cut, saw cut or machined ends, made to any length within 1/16" and special end configurations upon request.
We carry Split Hub, Shaft, Threaded Shaft, and Squeeze Clamps in assorted sizes. Our Gear, Sprocket, Dial, Dual Gear, and Phase Adjustable Hubs are available in both pin and clamp hub styles.
|
|
These bearings are used in lower load applications where self alignment is not required. The precision fit between the bearing and shaft is built into the bearing as a result of the solid steel shell. These bearings utilize a molded plastic bearing ball retainer assembled inside a hardened and ground shell.
- Designed for use on end supported PowerTrax™ HG “L” shafting.
- Solid steel shell, no seals.
|
|
|
Linear bushing guides can be put together from over 1,000 designs and variations to meet all demands and applications, which means that users can select exactly what they require for every task.
|
|
Well known as A-bearings, these all-steel bearings are the original precision anti-friction linear ball bushing bearings offering the following features:
* A coefficient of friction as low as .001. When replacing high friction plain bearings, Precision Steel Ball Bushing bearings dramatically improve machine productivity and efficiency.
* All-steel construction, for maximum system rigidity.
* Two accuracy classes allowing for immediate improvements in system positioning and repeatability.
* Availability in fourteen bore sizes and nine configurations.
* The RoundRail* Advantage minimizes installation time and cost.
* Steady state travel speeds up to 10 ft/s and accelerations to 450 ft/s2 without the use of derating factors.
* An operating temperature up to 600 degrees F.
* Availability in a self-aligning pillow block housing for ease of installation and use.
* Worldwide availability from over 1800 authorized distributors.
|
|
- The linear bushing is cylindrical shaped
- The outer ring is machined with the highest possible precision
- It has a wide range of applications
- Linear bushings are available in two series with different dimensions
- 2D & 3D CAD Drawings
|
|
OILES LF Guide
Guide unit bearing
STANDARD PRODUCT
Guide unit interchangeable in dimensions with linear bushings
OILES LF Guide is a guide unit in which OILES Drymet LF and dust seal are structured in aluminum housing.
Features:
- Usable without lubricating because of OILES bearings.
- Usable in the vapor because of rustproofed aluminum housing.
- Excellent wear resistance and low friction coefficient.
- Easy to fix and interchangeable with ball type bearings.
- Realized low price owing to the simple structure.
|
|
|
|
|
|
|
Adjustable precision guide bushes with optional wedging guide bushes “type SPIETH” are round of linear guiing devices for all ranges of the precise machine and building of devices. The employment of these guide bushes is indicated if the advantages of the slider, z. B. high absorption, to be used are and smallest guidance play one requires. Thus these guide bushes at Führungsgestellen, at round carriage guides, at headstock guides, at press tappets become etc. successfully assigned. Additionally to the linear movement also simultaneous rotating motion is possible. High acceleration values are unproblematic during according to arranged lubricant supply. The environment parts which can be made simply can be implemented in usual ISO tolerance. Existing adding play always permits an easy assembly, also when large dimensions. The demanded close guidance play is optimally stopped during the assembly procedure. Both small geometrical errors of the environment parts can, and operatingcaused influences, like e.g. arising higher temperatures, to be considered. With possibly arising wear a play adjustment is possible. The advantages in summary: - Inexpensive one, guide bush ready to be installed. - Easy assembly also when large dimensions. - The guidance play can be stopped during the assembly procedure. - Sliding friction in combination with precise guidance possible. - Simple connecting units which can be made. - For sliders typically high absorption available. - Accurate centric play restricting. - Fast disassembly facilitates machine service.
|
|
A new feature of the eccentric adapter bushing is designed to improve performance. Modern Linear adjustable bushings are designed with a knurled surface where the bushing contacts the carriage plate. This feature improves the holding ability of the bushing and wheel once it has been adjusted. Bushing slip is a leading cause of maintenance in this type of linear system.
Modern Linear adapter bushings are designed to replace existing bushings available in the marketplace.
New fasteners are in development to completely eliminate the possibility of wheels losing position during operation.
|
|
Eliminates Backlash, Reduces Friction
The NB Ball Spline is designed for mechanical applications which require both linear motion and torque transmission. The rolling contact of the balls eliminates backlash and reduces friction, helping you to achieve super precision and reliability.
The spline shaft facilitates additional machining and high accuracy because of a round shaft shape. Since the spline shaft is also machined by cylindrical grinding, it has a high sealing performance and a well-balanced structure that reduces the vibration and noise during rotary motion. Moreover, it has great geometrical moment of inertia and high rigidity. This enables a long-term, high precision linear motion.
|
|
The NB ball spline is a linear motion mechanism utilising the rotational motion of ball elements. It can be used in a wide variety of applications, including robotics and transporttype equipment.
The NB rotary ball spline can be used for both rotational- and linear motion. It can be used in scalar robots, the vertical shaft of assembly equipment, tool changers and loaders.
|
|
|
|
