Linear length gauges


43 Industrial products | 12 Companies


SOLARTRON METROLOGY
Compact spring push linear length gauge  0.5 - 20 mm | DZ/S SOLARTRON METROLOGY

The DZs are probably the shortest probes available on the market with a ...

MITUTOYO
Linear length gauge  LGK MITUTOYO

Linear Gage LGK
SERIES 542 -- Slim type

■FEATURES
* Compact design with a 12mm outside diameter.
* Excellent protection against dust and splashing water (IP66) in harsh shop-floor
environments.
* Maximum permissible acceleration values for shock and impact, 100G(11ms)
(IEC68-2-27)
* Output differential square wave signals for a wide range of applications.
* ...

Linear length gauge  LGF MITUTOYO

Linear Gage LGF
SERIES 542 -- Economical Design

■Technical Data
Accuracy: Refer to the list of specifications
(excludes quantizing error)
Resolution: 5μm, 1μm or 0.5μm
Scale type: Photoelectric linear encoder
Max. response speed: 1500mm/s
Contact point: ø3mm carbide
Stem: ø8mm or ø15mm
Bearing ...

Linear length gauge  LGB MITUTOYO

Linear Gage LGB
SERIES 542 -- Extra-slim type

■FEATURES
* Extremely compact design. Available with an outside diameter as small as 8mm.
* The small photoelectric linear encoder assures high precision over ...

Bowers Metrology
Linear length gauge  200 - 400 mm | Intex Bowers Metrology

Developed to measure both internal and external diameters and lengths, the gauge's aluminium extrusion beam gives it a rigid, yet lightweight quality - making it ideal for shop-floor environments. The simple release of a locking ...

DR. JOHANNES HEIDENHAIN GmbH
Linear length gauge DR. JOHANNES HEIDENHAIN GmbH

Length gauges from HEIDENHAIN offer high accuracy over long measuring ranges. These ...

ELEN Srl
Non-contact linear Hall effect position sensor  max. 20 mm ELEN Srl

The position sensors detect the displacement in respect of an absolute position by mean of an Hall element providing a proportional output voltage. They can be used for any movement both linear and rotary (by mean of a cam). They find a typical application on suspended ...

Onosokki
Linear length gauge  13 mm, IP64G | GS-4513 Onosokki

This rugged gauge sensor can maintain high accuracy while being used in harsh environments ( IP64G Water and Oil splash protected). In ...

Linear length gauge  30 mm, IP64G | GS-4530 Onosokki

This rugged gauge sensor can maintain high accuracy while being used in harsh environments ( IP64G Water and Oil splash protected). In ...

Waterproof linear length gauge  10 mm, IP67 | GS-7710 Onosokki

GS-7710 is a pencil type linear gauge sensor. This compact gage is designed to fit into tight spaces. In addition ...

Magnescale Europe GmbH
Digital linear length gauge  0.1 - 0.5 µm | DK812 Magnescale Europe GmbH

High accuracy, rugged gauges. Suitable for installation on machine.

* Measuring range:12 mm
...

Digital linear length gauge  0.5 µm | DK10 Magnescale Europe GmbH

High accuracy, rugged gauges. Suitable for installation on machine

* Measuring range : 10 ...

Digital linear length gauge  0.5 µm | DK50 Magnescale Europe GmbH

High accuracy, rugged gauges. Suitable for installation on machine.

* Measuring range ...

Feinmess Suhl GmbH
Linear length gauge  IKF 10/30 Feinmess Suhl GmbH

* Measuring range: 10mm, 30mm
* Resolution: 0,01 µm
* Probe with prism roller bearing
* Clamping shaft - Ø 8 h6
...

GSI MicroE Systems
Linear length gauge  1 - 2 µm | SST GSI MicroE Systems

MODEL SST
Short Stroke
Linear Encoder
• 2” or 4” stroke lengths
• Resolutions of .0001” or .000050” (English). .002 mm or .001 mm ( Metric)
• Spring loaded, ball tip probe for easy mechanical interface
• LED light source
The Model SST is a fully ...

RSF Elektronik
Glass scale linear length gauge  0.025 µm | DIT 10, DIT 30, DIT 48 RSF Elektronik

Precision measuring probes:

- for universal applications ...

RSF Electronics
Linear length gauge  DIT 10 RSF Electronics

DIT 10

Precision measuring Probe

- ...

Positek Limited
Non contact in-cylinder linear position sensor for hydraulics / pneumatics  20 - 600 mm | P100 Positek Limited

The P100 sensor is an affordable, durable, high accuracy linear position sensors specifically designed for use in hydraulic and pneumatic cylinders where long life and cost are important. The P100 linear sensor is particuarly suitable for OEM customers who require good performance in hard environments such as industrial machinery.
Performance, repeatability and stability are outstanding over a ...
