Automatically remove and elevate ferrous materials such as chips, turnings and small parts. Conveyor mechanism is totally enclosed. Wide variety of configurations can be assembled from standard design sections.
Chip & Parts Conveyor - Standard Utility Model 68
Standard model for lightweight material.
Chip & Parts Conveyors - Low Profile Permanent Magnetic
Control lightweight ferrous materials.
Chip & Parts Conveyors - Model 6
6-1/4 in. (159mm) deep housing to transport small volumes of chips.
Chip & Parts Conveyors - Model 9
9-1/4 in. (235mm) depth for greater volumes.
Chip & Parts Conveyors - Model 12
12-1/4 inch (311mm) depth for high volumes of chips.
Chip & Parts Conveyors - Model 21
21-1/4 in. (540mm) working width for high volume conveying.
|
|
The conveyor Turbo Magnetic is specially designed for Multi-tasking machines producing fine chips of ferrous material. The Turbo Magnetic features a heavy gauge stainless steel slider face for a long life in extreme wear conditions. All moving parts are contained inside the conveyor’s viton sealed frame so they are never exposed to machining contaminates. The conveyor belt is automatically tensioned.
Self-lubricated Track
No lubrication oil inside the conveyor to leak and contaminate the coolant.
Reduced Coolant Carry-out
A variable speed drive (AC Inverter) is standard on all units to maximize chip removal and minimize coolant loss.
Easily-Replaceable Magnets
Turbo components, including individual magnet segments, are easily and economically replaced if the conveyor is accidentally damaged.
|
|
Magnetic conveyor M
Areas of application
Transportation of short ferromagnetic, emulsion-afflicted shavings and small parts, e.g. stampings. Installation possible as individual conveyor or interlinked system.
Function
A continuous magnetic band conveyor, consisting of two chain strands which have been connected by means of carrying strips and permanent magnets, continuously conveys the material to be conveyed on the conveyor plate to the discharge station. Pre-cleaning of the cooling lubricant without additional cleaning elements. The magnetic band drive occurs via a three-phase geared motor. The magnetic band has been installed self-tight eningly.
|
|
|
|
|
|
Heavy-Duty Magnetic Conveyors - For dependable, maintenance-free, positive transfer of ferrous metal scrap and parts with no carryover.
Features, Benefits, & Options:
- Conveys wet or dry ferrous chips, stamping slugs, stamping scrap, or parts
- Rugged, long life stainless steel slider bed
- Available in straight, L-style, or Z-style configurations
- Alloy steel bar tracks, precisely guide chain and magnetic assemblies
- Self adjusting drive chain take-ups
- Completely sealed, oil tight construction for quiet self-lubricating performance
- Available with permanent ceramic or optional rare earth magnets
- Extended height elevation and pivoting conveyors (to be inserted into your press) are also available
--------------------------------------------------------------------------------
Standard Duty Magnetic Conveyors - Low profile - Only 3 3/8 inch high! An economical alternative for less demanding applications. For dependable, maintenance free, positive transfer of ferrous scrap and parts with no carryover.
Features, Benefits, & Options:
- Conveys wet or dry ferrous chips, stamping slugs, stamping scrap, or parts
- Rugged, long life stainless steel slider bed
- Available in straight, L-style, or Z-style configurations
- Features a steel encased UHMW low friction track
- Quiet, self lubricating performance
- Supplied with permanent ceramic magnets
|
|
|
|
|
|
Bunting MagSlide® Magnetic Slide Chip and Parts Conveyors are built to handle the tough jobs. Dirty, oily parts, jagged, abrasive scrap, and other punishing materials that could damage or jam conventional conveyors are no challenge for Bunting's 3-D CAD-designed, ruggedly constructed slide plate conveyors. They are ideal for use anywhere you need to transfer ferrous chips, turnings, and small parts from lathes, mills, or stamping presses or from slitting, forming, and other metalworking operations. Chain-driven, permanently charged high-energy Ceramic magnets inside the conveyor housing attract and move ferrous material along the conveyor's stainless steel faceplate. Optional water-tight housings can be submerged into almost any type of hot or cold liquid.
MagSlide Conveyors are engineered for trouble-free, virtually maintenance-free operation. There's no external belt to jam, tear, or wear out from carrying sharp, abrasive parts and scrap.
Get Outstanding Performance and Value
- Rugged construction
- Continuous chain lubrication with oil-impregnated UHMWPE SlideTrack™
- Oil ports to allow extended chain service
- High-energy Ceramic or Rare Earth Magnets matched to your application
- Durable stainless steel slider beds
- Sealed precision drive and take-up bearings
- Designed with 3-D solid-model technology
- Precision manufactured on CNC machines
- Optional submersible housings
|
|
MAGNETIC RAILS AND ROLLS
Goudsmit manufactures a wide selection of magnetic components with which magnetic transport systems can be built. The standard range of magnetic components is applied in many industries, among which the tin production industry for the transport of outer shells, covers, drums, aerosols, crown caps and screw caps.
|
|
| ... products without technical information |
| |
