Magnetic belt conveyor (FH）SGPC-D
horizontaltransportdrum motor

Magnetic belt conveyor - (FH）SGPC-D - Chongqing Machine Tool (GROUP) Co., Ltd. - horizontal / transport / drum motor

Magnetic belt conveyor - (FH）SGPC-D - Chongqing Machine Tool (GROUP) Co., Ltd. - horizontal / transport / drum motor - image - 2

Add to favorites

Compare this product

Characteristics

Technology: magnetic belt
Form: horizontal
Function: transport
Drive mechanism: drum motor, with magnetic drive
Transported product: chip
Other characteristics: custom-made
Bulk throughput: 12 kg/min
(26.455 lb/min)

Description

Product overview
The unit is a drum-type magnetic chip conveyor designed for automatic chip removal from milling machines, such as gear-hobbing or gear-milling equipment. It conveys flake, strip and granular iron chips from various materials.

Details

The conveyor is driven by a reduction motor with sprocket-and-chain transmission; the drum serves as the conveying element and receives chips from the machine discharge outlet.
Designed for smooth chip evacuation, compact footprint, stable transport and low-noise operation.
Main specifications and technical parameters are listed below.

Parameters
Model: (FH) SGPC-D
Dimensions (L×W×H): customizable
Motor power: 0.1 (0.2) kW
Reduction ratio: 1:160
Chip removal capacity: approx. 12 kg/min

Technical characteristics

Reference: (FH) SGPC-D
Applicable machines: milling machines (e.g., gear-hobbing / gear-milling machines)
Chip type: flake, strip and granular iron chips
Drive type: reduction motor driving sprocket-and-chain transmission; drum as conveyor
Motor power: 0.1 (0.2) kW
Reduction ratio: 1:160
Chip removal capacity: approx. 12 kg/min
Dimensions: length × width × height customizable to customer requirements
