DC Electric micro -motor
*DC Brushless motor
Diameter Ø 1.5 mm to 22mm
Voltage : 3 to 24 v
Driver is available.
Spur gearbox or Planetry gearbox and feedback device are available
-Applicaion
Endscope
catheter
Medical robot
Micro actuator
|
|
No cogging or preferred rotor position
No iron losses
Extremely low current consumption
Low audible and electrical noise
Extremely light and compact
Smooth and accurate speed, position, and torque control
Low vibration
Speeds up to 100,000 rpm
Electronic commutation for extremely long operational lifetime
High precision gearboxes available in all sizes
Feedback components available in all sizes
Control electronics available for all motor series
Custom systems available from design to production
|
|
No cogging or preferred rotor position
No iron losses
Extremely low current consumption
Extremely light and compact
Smooth and accurate speed, position, and torque control
Electronic commutation for extremely long operational lifetime
High precision gearboxes available in all sizes
Control electronics available for all motor series
Available as linear actuator
Custom systems available from design to production
|
|
No cogging or preferred rotor position
No hysteresis or eddy current losses
Extremely low current consumption
Ultra flat dimensions
Extremely light and compact
Smooth and accurate speed control
Speeds up to 60,000 rpm
High power rare earth magnets
Electronic commutation for extremely long operational lifetime
High precision gearboxes available
Control electronics available for all motor series
Custom systems available from design to production
Autoclavable and vacuum rated motors available
|
|
• Fast speed up to 50,000 rpm and up to 30W of continuous output power
• Ultra compact. At 32 mm (1.26”) diameter by 11.7 mm (0.46”) length, the nuvoDisc is over 75% shorter and over 90% lighter than typical competitor motors.
• With a weight of only 26g, applications benefit from being lightweight.
• High efficiency. Reduces power supply requirements by drawing less current,
resulting in less generated heat.
• Low vibration. High speed slotless design provides characteristic smooth operation.
*A slotted design is also available on request when detent torque is needed, for applications such as Damper Control.
|
|
|
Canon Precision's brushless motors are compact in size and provide high output power. Two types are offered; an outer rotor type with high rotational stability and an inner rotor type with quick response. Inner rotor types can be equipped with reduction gears and encoders. Various custom options can be incorporated to fit your applications.
|
|
|
Brushless DC motors provide high power density and long life for applications requiring speed control. NMB’s BLDC motors are available in 0.1W up to 1kW.
|
|
|
These motors are a marvel of modern engineering! They combine rare earth magnets with a coreless design to produce high torque motor with diameters ranging from 4mm to 36mm. They feature a sintered bronze bearing to support the output shaft. Originally designed for vibration functions in mobile phones, these come without the weight and are finding increasing applications in models, miniature toys, medical instruments and many miniaturised consumer applications.
|
|
|
Nanomotion's EDGE motor is the smallest industrial motor of its kind available in the marketplace today. Providing unlimited linear or rotary motion, the EDGE motor offers extensive opportunities in applications that suit a wide range of industries. The EDGE motor works with a uniquely designed, compact ASIC-based driver, and can be operated with any servo controller. The EDGE motor can be easily integrated into most bearing structures, and is ideal for mass production opportunities.
|
|
Ultra flat dimensions
No cogging or preferred rotor position
No iron losses
Extremely low current consumption
Low starting voltage
Low rotor inertia for extremely fast acceleration and braking
Extremely light and compact
Custom systems available from design to production
Very cost effective
Precision gearboxes available in all sizes
|
|
MODEL SERIES - DC33
PMDC GEARED MOTOR
Design - Motor DC33 is a carbon brush DC motor which is used in combination
with many Mech Tex gearheads. The standard gearheads used in conjunction with this motor are GB2, GB5P, GB5H, GB38OCP, GB3, GB4, GB7, GB8 & GBW. Depending on the application, output speed, load applied, etc. the type of gearhead can
be selected. Various types of gears i.e. poly acetal, sintered iron, brass or steel gears can be used based on the requirement. Poly acetal or sintered
gears damp the noise. Case hardened steel gears are always on the output
for load considerations. Complete poly acetal gears are used when the output
torque required is low. Linear drive is possible with gearhead GB4,GB7,GBW
with M6 x 1 mm pitch screw. The linear guide & screw arrangement can be
done only on special request.
|
|
MODEL SERIES - DC28
PMDC GEARED MOTOR
Design - Motor DC28 is a carbon brush DC motor which is used in combination with many Mech Tex gearheads. The standard gearheads used in combination with this motor are GB2, GB5P, GB5H, GB38OCP, GB3, GB4, GB7, GB8 & GBW. Depending on the application, output speed, load applied, etc. the type of gearhead
can be selected. Various types of gears i.e. poly acetal, sintered iron, brass or steel gears can be used based on the requirement. Poly acetal or sintered gears damp the noise. Case hardened steel gears are always on the output for load considerations. Complete poly acetal gears are used when the output
torque required is low in an economical model (GB7P). Linear drive is possible with gearhead GB4, GB7, GBW with M6 x 1 mm pitch screw. The linear guide & screw arrangement can be done on special request.
|
|
MODEL SERIES - DC32
PMDC GEARED MOTOR
Design - Motor DC32 is a carbon brush DC motor which is used in combination with many Mech Tex gearheads. The standard gearheads used in conjunction with this motor are GB2, GB5P, GB5H, GB38OCP, GB3, GB4, GB7,GB8 & GBW. Depending on the application, output speed, load applied, etc. the type of gearhead can be selected. Various types of gears i.e. poly acetal, sintered iron, brass or
steel gears can be used based on the requirement. Poly acetal or sintered gears damp the noise. Case hardened steel gears are always on the output for load considerations. Complete poly acetal gears are used when the output torque
required is low. Linear drive is possible with gearhead GB4,GB7,GBW with M6 x 1
mm pitch screw. The linear guide & screw arrangement can be done only on special request.
|
|
MODEL SERIES - DC30
PMDC GEARED MOTOR
Design - Motor DC30 is a carbon brush DC motor which is used in combination with many MechTex gearheads. The standard gearheads used in conjunction with this motor are GB2,GB5P, GB5H, GB38OCP, GB3, GB4, GB7,GB8 & GBW. Depending on the application, output speed, load applied, etc. the type of gearhead can be selected. Various types of gears i.e. poly acetal, sintered iron, brass or
steel gears can be used based on the requirement. Poly acetal or sintered gears damp the noise. Case hardened steel gears are always on the output for load considerations. Complete poly acetal gears are used when the output torque
required is low. Linear drive is possible with gearhead GB4, GB7, GBW with M6 x 1 mm pitch screw. The linear guide & screw arrangement can be done only on special request.
|
|
Miniature DC Coreless motor
Miniature DC Brushless motor
* Coreless Motor Characteristics
-Diameter Ø 4 to 18
-Voltage 3 to 12 V
Spur or Planetary gear box and Feedback device are available.
* Brushless Motor Characteristics
-Diameter Ø 1.5 to 30
- Voltage 3 to 24 v
Spur or Planetary gear box , feedback device are availabe.
Application :
* Optical and Measuring instruments
* Medical instruments and apparatus
* Factory Automation and instrumentation
* Servo system for Remote control
|
|
Key Attributes and Characteristics:
- Frame sizes from 8mm (0.31 in.) to 35mm (1.38 in.)
- Speeds up to 12,000rpm
- Torque range of 0.64 mNM (0.09 oz. in.) to 115 mNm (16.3 oz. in.)
- Low power consumption ratings
- Ironless rotor
- Central stator magnet
- Compact bearings
- Precious metal commutation system
- Copper-graphite commutation
Advantages
- High acceleration
- High efficiency
- Low losses and low electromagnetic interference
Portescap Brush DC motors can be customized with options such as gearboxes, connectors and cables, custom coil designs and more.
|
|
Johnson Motor Permanent DC (PMDC) flat motors Ø 15.0 ~ 19.9 mm
Dimensions: Ø 15.5 x 18.6, flat 12, shaft Ø 1.505 mm
Supply nominal: 5 VDC
Torque:
@ stall 1.871 mNm
@ max. efficiency 0.381 mNm
@ max. power 0.649 mNm
@ constant 3.267 mNm/A
Speed:
@ no load 10500 rpm
@ max. efficiency 8363 rpm
@ max. power 5250 rpm
Max. current:
@ no load 0.04 A
@ stall 0.613 A
@ max. efficiency 0.157 A
@ max. power 0.326 A
|
|
No cogging or preferred rotor position
No iron losses
Extremely low current consumption
Extremely light and compact
Smooth and accurate speed, position, and torque control
Electronic commutation for extremely long operational lifetime
High precision gearboxes available in all sizes
Control electronics available for all motor series
Available as linear actuator
Custom systems available from design to production
|
|
We are pleased to introduce the new BLDC brushless micro gearmotors. This new series completes Intecnos range of DC micro gearmotors and offers ideal solutions for sectors such as industrial automation, automatic doors and windows, vending and many others.
The BLDC motors from the BL series are available in 3 sizes (torque from 0,05 Nm to 0,43 Nm) and they can be supplied with an integrated (IE version) or external drive. They are compact and low-cost being equipped with Hall sensors. These motors have a low voltage 24V, which optmises safety in the workplace, particularly in applications where the worker can be in direct contact with the motor.
To complete the gearmotor, we would use the reliable micro planetary gearbox from our standard series.
Gearmotors made up of BL motors and LN (low noise) gearboxes are particularly suitable for applications in the medical field and for applications that require a controlled movement.
|
|
|
|
|
|
The new Intecno micro gearmotors series characteristics:
- Coaxial arrangement of the input and output
- Compact design
- Advantageous torque with minimum space requirements
- Low moments of inertia
- Suitable for continuous, reversing and intermittent operation
- Can be installed in any mounting position
Planetary gearboxes stand out for having a wide range of reduction ratios, It’s possible to obtain a total of 72 reduction ratios from i=3.7: 1 (1 stage) to i= 2076:1 (4 stages). Planetary gearboxes are lubricated with grease and are therefore maintenance-free.
This product can be personalized due to the possibility of using metal, plastic or material mix versions. The LN (low noise) version is also available: It significantly lowers the gearbox noise.
The distinguishing features of D.C. motors in general are their high start torque as well as a torque/speed ratio suitable for high work loads. Another important characteristic of the D.C. motor is its density.
Features:
- Magnetic field generated by permanent magnets
- Available in 5 sizes: diameter 35,42, 52, 65, 80 mm
- Low voltage power supply, 12 or 24 Vdc
- Power ratings available from 8 to 140 W S2
Intecno micro gearmotors are perfect for many applications, in any sector where both small dimensions and good performances are required. These characteristics are important in the medical sector, robotics and also in electric vehicles. Other important fields are shutters for windows/doors where the movement required can be obtained by Intecno’s small DC motors and planetary gears. Options such as a bearing mounted input shafts and DC motor controls are also available to complete the product.
|
|
DC Electric Micro Gearmotor
* Gear Coreless motor
Diameter : Ø7 to 18 mm
Voltage 3 v to 12v
Gear type: Spur gear :Planeteary gear
Several gear ratio are available
* Gear Brushless motor
Diameter Ø1.5 to 30 mm
Voltage 3 to 24 v
Gear type : Spur gear , Planetary gear
Several gear ratio are available
|
|
DC Planetary Electric micro gearmotor
Diameter : Ø2mm to 18mm
Voltage : 3 v to 12v
Planetary gear ratio: 6:1 ,4.7:1,13.1:1,22,1:1,61.1:1,105.1:1,288:1,494:1
Motor type : Coreless motor or Brushless motor
Feed back device are available.
Application
- Medical equipment
- CCTV
- Robot
- Chip Mounter
- Measuring Equipment
|
|
No cogging or preferred rotor position
No hysteresis or eddy current losses
Extremely low current consumption
Ultra flat dimensions
Extremely light and compact
Smooth and accurate speed control
Speeds up to 60,000 rpm
High power rare earth magnets
Electronic commutation for extremely long operational lifetime
High precision gearboxes available
Control electronics available for all motor series
Custom systems available from design to production
Autoclavable and vacuum rated motors available
|
|
Single-phase capacitor motors Series KD.1 and three-phase motors Series DR.1
The motors are solidly designed and are maintenancefree for life.The multi-grooved stator contains a threefold winding which, together with the phase-shifting capacitor, creates a symmetrical rotating field at the rated working point of the motor.The rotor is of the squirrel-cage type. Two- or four-pole motors with a variety of design Iengths and diameters provide rated torques from 0.75 to 12.6 Ncm. Can be combined with reduction gear units, brakes, and tachogenerator systems.
|
|
|
The DC-motors can be combined with control electronics, gearboxes, brakes and encoders in a modular system to provide a flexible, adaptable, market-oriented solution.
|
|
Small Coreless motor
Small Brushless motor
* Coreless motor
- Outer diameter : Ø7 to 18
=Voltage 3 to 12v
- Output power : 0.19 to 3.5 W
- No load speed : 9,000 to 17,500 rpm
- Starting torque : 0.43 to 3.5 mNm
Spur or Planetary gearbox and feedback device are available.
* Brushless motor
- Outer diameter Ø 1.5 to 30
- Voltage 3 to 24 v
Spur or Planetary gearbox and feedback device are available
* Applicatition
- Optical and Measuring instruments
- Medical instruments and apparatus
- Factory Automation and instrumentation
- Servo system for remote control
|
|
|
High quality 3 pole 12mm ferrite motor with a spur gear open gearbox, steel geartrain and sintered bronze bearings. The double shaft unit features an ungeared extended shaft protruding from the motor case. This is suitable for mounting encoders or other drive components for feedback control or actuation. Used by modellers for animating static displays, robotics enthusiasts, and industrial actuators (e.g. locking mechanisms). Originally designed for focusing rings on professional video cameras.
|
|
GM Series
GM12
10mm x 12mm 6V or 12V DC gearmotor, available in five gear reduction ratios. 30:1, 63:1, 100:1, 210:1 and 298:1
|
|
|
High precision planetary (epicyclic) gearbox coupled to a 3 pole 12mm ferrite motor. The unit features a lightweight injection-moulded gearbox assembly and is manufactured to an extremely high quality. The unit was developed for generating the accurate motion required in miniature desktop printers. The planetary geared motor has a unique cross-shaped output shaft which is ideal for zero slip transmission.
|
|
Since more than 25 years Giem is a leader in the field of induction motors characterized by high electromagnetic efficiency. Available in a rich variety of versions, they represent the most reliable solution for different applications in the thermal ventilation field.
Induction motor Ø 58
Long duration version available (ball-bearing)
Double speed version available
Thermal protection based on the motor impedance or by means of a thermostat or a fuse
Voltage: 12 -110 - 240 VAC
H class available
VDE and UL approvals on request
|
|
|
|
