• Effortless and fast rewinding, wrapping, guiding of hose.
• Chain and sprocket drive powered by electric, hydraulic, or
compressed air motor.
• Auxiliary crank rewind, optional.
• 12 volt rewind, comet brake, reduction unit standard.
• Air brake optional.
• Inlet, hub assembly is aluminum and/or stainless steel for jet fuel.
• Consult factory for other pressures & temps.
|
|
Heavy duty hose reels ideal for Transport / Refueling / Fire Fighting / Industrial. Pressures up to 10,000psi
Hose id (diameter): 12mm, 19mm, 25mm, 32mm, 38mm, 50mm
Hose length: 15m, 20m, 25m, 30m, 40m, 50m, 60m, 70m, 80m, 90m, 100m, 110m, 120m, 130m, 140m, 150m, 160m, 170m, 180m, 190m, 200m
Rewind Method: Motor driven
|
|
T series 12 / 24VDC Electric motor driven hose reels
Heavy duty hose reels ideal for Transport / Refueling / Fire Fighting / Industrial. Pressures up to 10,000psi
Hose id (diameter): 12mm, 19mm, 25mm, 32mm, 38mm, 50mm
Hose length: 15m, 20m, 25m, 30m, 40m, 50m, 60m, 70m, 80m, 90m, 100m, 110m, 120m, 130m, 140m, 150m, 160m, 170m, 180m, 190m, 200m
Rewind Method: Motor driven
|
|
For mobile food: hoist, grab, overhead crane, machine & cart mobiles, lifting beam, control on the ground, conveyer, mast, mobile distribution.
Engine with magnetic coupling, high quality.
|
|
|
Coxreel hand crank and motor driven reels feature industry preferred design with a sturdy one piece all welded "A" frame base, low profile outlet riser and open drum slot for non-crimping, flat smooth hose wrap. Operator efficiency is also enhanced with a longer drum lock pin, a round tapered crank handle, and a long wearing corrosion-resistant adjustable tension brake. These reels, like all Coxreels, are built of heavy gauge steel and sealed with a Coxreels’ “CPC” proprietary powder-coated corrosion and scratch resistant finish.
|
|
- MX chain drive crank rewind or powered by a compressed air
or hydraulic motor.
- MX rewind reels supplied with a Pinion brake.
- Power reels not supplied with a brake.
- Standard inlets 90° ball bearing swivel joints with 1/2" female
NPT threads.
- Standard outlets are male 9/16"-18 threads. Right hand for
oxygen, left hand for gas.
-Rollers may be purchased. Specify roller position (mounting
brackets are necessary).
- Pressures to 300 psi (21 bar).
- Temperatures fr om -40° F to +200° F (-40° C to +93° C).
- Type of gas used MUST be specified .
|
|
Reelcraft’s Series 30000 reels are designed for heavy duty applications requiring long lengths of hose and will adapt to plant or field use. Contemporary design and unitized construction assure trouble-free performance and long product life. Its reel frame, spool, and drum are fabricated of heavy gauge steel.The 30000 Series also features a nickel-plated swivel, vibration-proof self-locking fasteners ad Vitan “O” ring as standard. Adjustable spool rotation drag eliminates hose backlash when de-reeling and permanently lubricated dual main bearings allow for easy, maintenance free operation. There are motor mounts on either end of reel and the 30000 is easily converted from manual to power-driven.
|
|
- Motorized cable reels -
Conductix-Wampfler engineers were from the very beginning convinced that permanent magnetic couplings offered a host of advantages. As a result, they developed a complete series of motorized cable reels that make it possible to configure efficient, economical standardized systems to meet all power requirements and cover virtually all applications. In addition, customers can choose from various drive options.
|
|
For more than 35 years Cavotec Specimas has been involved in the development and manufactoring of motorised cable reels for horizontal and vertical applications, both for continuous and intermittent duty. Cavotec Specimas uses different driving systems for different applications and sizes. The range includes the Hydrodynamic system, the Torque motor, the Permanent Magnet Clutches, the Electromagnetic Clutches and, for the largest reels, the Direct Torque Control. In 1977 Cavotec Specimas introduced the "Pull and Store" system to solve the problem of cable overtension in high installations, adopted in thousands of installations.
|
|
- Hose reels for oil pressure, hydraulics, gas, and pneumatics;
- Electrical cable reels for power, auxiliary, and signal machines;
- Combined electrical-fluid reels, measurement, angle and length transducers;
- Reels with an electronic traction control;
- Automatic spring operated cable and hose reels for feeding moving machines;
- EExd anti-deflagration reels for use in potentially explosive environments;
- Manual reels of small, medium, and large dimensions;
|
|
The cable coiler is suitable for reeling cable coils.
It is equipped with a calibratable meter counter ME-01 (measuring range 0- 9999,99 m) for cable dia. 5- 100 mm and a quick action release device for winding basket.
Cable guiding is done manually.
Drive of cable coiler is effected through an electric geared engine with an infinitely speed adjustment from 0- 40 m/min.
|
|
VAHLE motor-driven cable reels are used to supply power to movable equipment for automatic winding of flexible power or control cables and correspond to VDE and accident prevention regulations.
The reels can have a spiral or cylindrical winding configuration.
The cable is pulled out horizontally or vertically.
|
|
|
|
|
|
ELYTRA develops and industrializes systems of power supply for used movable talents in the iron and steel, metallurgical, agro-alimentary industry, wastebaskets, ports, terminals, mines, theaters, etc.
ELYTRA designs and makes coilers from 1963 with a range of coilers manuals, to motorized means and with system of magnetic coupling. Within the manufacture range coilers for power supply, pneumatic, hydraulic are constructed and of data transmission through optical fiber. This range of manufacture goes from the smallest model with drum of 200mm of diameter, to the greatest drum with 7 ms of diameter.
The cables and hoses used for the manufacture of our coilers are specific for each one of the applications that they ask for to us, as much for high speeds, minimum radios of curvature and great tractions, with a reduced outer diameter.
For the transmission of energy of the fixed part to the moving body specific collectors for each type of transmission are used. A all this accompanied by the suitable accessories for each type of application, obtaining major and better durability of the equipment.
|
|
-Incorporated cable measurer (mod. CM-15) for cable max diam. 35 mm with incorporated shears.
- Coiling head Ø 800mm ; adjustable core 320-600mm
- Available also with motor
|
|
TR Drum series
Available as take-up or pay-off station for metal, wooden or plastic drums
Highly versatile, this machine can help the most different needs: it is available as single or double versions and may be used as a take-up with pipe guides and cutting device or as a pay-off, with fixed or variable drum sizes. The users can also choose the most suitable version: automatic or semiautomatic pipe clamping. The selection includes recoiling lines to increase the efficiency of the final pipe packing. These systems can be used with steel, wooden or plastic drums.
|
|
MOTORIZED COILER
ART. OE-VE
Mobile handy cable coiler , CE marked, for coils Ø up to 1000mm. Complete with metercounter for cables Ø up to 60mm, electronically controlled variable speed single or three-phase motor , available for delivery with optional extras on demand to get a best performance.
|
|
| ... products without technical information |
| |
Designed to retract the hose with the assistant of an electrical high-torque motor.
We recommend this reel for truck service shop applications where hose and nozzles can be heavy and overhead cranes have to move.
|
|
|
Exhaust Gas Extraction Units: Wall-hanger units, Mobile units, Roller Units, Exhaust gas spiral hoses, Hose holders, Spiral hose clamps, Exhaust nozzles, Exhaust smoke aspirators.
|
|
|
|
