crystal oscillator / electronic / programmable / silicon
crystal oscillator
LTC69xx series

Frequency: 0 MHz - 96 MHz

Clocks that operate from 1kHz to 170MHz are solid state, silicon-based oscillators. Each oscillator, with linear technology, is programmable according to frequency through the pin-strapping, serial interface ...

crystal oscillator / electronic / voltage-controlled / programmable
crystal oscillator
LTC699x series

Frequency: 3.8 Hz - 2000000 Hz

... operations including low frequency clocking, voltage-controlled oscillation, pulse width modulation, signal delay and one shot generation. These timer boxes come with an accurate programmable oscillator ...

TCXO oscillator / electronic / voltage-controlled
TCXO oscillator

Frequency: 10 MHz - 11000 MHz

Our lines of voltage controlled oscillators, commonly referred to as VCOs, cover select bands from 10 MHz to 11 GHz in a variety of package options. This line of voltage controlled oscillators is most ...

TCXO oscillator / electronic / surface-mount / impact-resistant
TCXO oscillator
T1250

Frequency: 10 MHz - 50 MHz

T1250 TCXO Overview Greenray Industries' T1250 TCXO offers excellent temperature stability performance for optimum holdover in a small, SMT package. In addition, the T1250 has been designed for reliable performance in high shock and ...

See the other products
Greenray Industries
TCXO oscillator / electronic / surface-mount
TCXO oscillator
T1265

Frequency: 50 MHz - 125 MHz

Greenray’s new T1265 TCXO (temperature compensated crystal oscillator) is available from 50 to 125MHz, with squarewave CMOS output to drive a 15pf load. With very low phase noise down to a floor of -165dBc/Hz, the ...

See the other products
Greenray Industries
OCXO oscillator / electronic / plug-in
OCXO oscillator
YH1518

Frequency: 110 MHz - 250 MHz

The Greenray Industries' YH1518 series is an array of oven-controlled crystal oscillator (OCXO) constructed in a 1.06in. (L) x 1.42in. (W) x 0.5in. (H) hermetic package. They can exhibit 110MHz up to 250MHz of frequencies ...

See the other products
Greenray Industries
OCXO oscillator / electronic / plug-in
OCXO oscillator
YH1320, YH1321

Frequency: 10 MHz - 120 MHz

The YH1320 OCXO is an ovenized crystal oscillator that delivers low phase noise and is available in HCMOS or sinewave outputs. This oscillator are constructed to be suited for base stations or test equipment ...

See the other products
Greenray Industries
OCXO oscillator / electronic / with connector
OCXO oscillator
YH1322

Frequency: 10 MHz - 120 MHz

Greenray Industries' YH1322 Series OCXO offers ovenized crystal oscillator for tight phase noise and is available in a 2 in. square package. The typical phase noise is 150 dBc (@ 100 Hz offset). Available dimensions are ...

See the other products
Greenray Industries
oven-controlled SAW oscillator / electronic / low-noise / low-noise
oven-controlled SAW oscillator
LNO1000E OCSO

Frequency: 1 GHz

LNO1000E is a low noise and low power OCVCSO (Oven Controlled, Voltage controlled, SAW Oscillator) at 1GHz, powered by a low voltage +5V power supply. It is designed for test equipment, ground based and shipboard radars ...

See the other products
Rakon
OCSO oscillator / electronic / low-noise
OCSO oscillator
LNO800E1 OCSO 800MHz

Frequency: 800 MHz

LNO800E1 is a low noise and low power OCVCSO (Oven Controlled, Voltage controlled, SAW Oscillator) at 800 MHz, powered by a low voltage +5V power supply. It is designed for test equipment, ground based and shipboard radars ...

See the other products
Rakon
OCXO oscillator / crystal / electromechanical / with connector
OCXO oscillator
RK409

Frequency: 10 MHz - 40 MHz

This stable oscillator is designed for Space Clocks, Navigation and Positioning Systems and is used in such applications as GPS receivers, digital cards, board calculators, down and up converters, synthesizers. The AV ...

See the other products
Rakon
OCXO oscillator / electronic / high-stability / with connector
OCXO oscillator
HSO14

Frequency: 10000000, 5000000 Hz

... laboratories that have high stability frequency standards but also the applications that require high performance reference oscillators.

See the other products
Rakon
OCSO oscillator / electronic
OCSO oscillator
LNO500B2

Frequency: 500 MHz

Low Noise OCSO (Oven Controlled SAW Oscillator) - Low profile package 47.5 x 59.5 x12.7 mm - Output frequency: 500 MHz - Noise floor: -178 dBc/Hz - for Defense and Instrumentation

See the other products
Rakon
crystal oscillator / electromechanical / miniature / for extended temperature range
crystal oscillator
XO-25000E

Frequency: 1.25 MHz - 100 MHz

... product series XO-25000E offers an extended industrial temperature range with very small dimensions. For these crystal clock oscillators (XO) 3 different temperature ranges are available, which are not covered through ...

See the other products
KVG Quartz Crystal Technology GmbH
VCXO oscillator / crystal / electromechanical / surface-mount
VCXO oscillator
V-90000-LF True sine 5V

Frequency: 50 MHz - 125 MHz

... 40 ppm, i.e. there is an Absolute Pulling Range (APR) of more than ±10 ppm under all conditions what guarantees that the oscillator will kept locked to nominal frequency under all conditions and all over life time even ...

See the other products
KVG Quartz Crystal Technology GmbH
VCXO oscillator / crystal / electromechanical / surface-mount
VCXO oscillator
V-90000-LF True sine 12 V

Frequency: 50 MHz - 125 MHz

... 40 ppm, i.e. there is an Absolute Pulling Range (APR) of more than ±10 ppm under all conditions what guarantees that the oscillator will kept locked to nominal frequency under all conditions and all over life time even ...

See the other products
KVG Quartz Crystal Technology GmbH
VCXO oscillator / crystal / electromechanical / surface-mount
VCXO oscillator
V-7000-LF

Frequency: 100 MHz

... 40 ppm, i.e. there is an Absolute Pulling Range (APR) of more than ±10 ppm under all conditions what guarantees that the oscillator will kept locked to nominal frequency under all conditions and all over life time even ...

See the other products
KVG Quartz Crystal Technology GmbH
TCXO oscillator / VCXO / electromechanical / surface-mount
TCXO oscillator
TO-900-LF

Frequency: 12.8 MHz

The new VCXO/TCXO TO-900 series in the small 14x9 mm SMD package fulfills also the holdover stability requirements according to ANSI clock specifications Stratum 3 Telcordia (Bellcore) 1244-CORE, i.e. frequency dependency from temperature ...

See the other products
KVG Quartz Crystal Technology GmbH
temperature-compensated crystal oscillator / electronic / SMD / clock
temperature-compensated crystal oscillator
EQTB3A, EQTB30 series

Frequency: 32.76 kHz

Each Series Homepage provides immediate and complete details on the electrical, mechanical, and environmental specifications that define the series, as well as compliance status, guides to marking and part numbering, and more.

See the other products
Ecliptek Corporation
crystal oscillator / MEMS / SMD / clock
crystal oscillator
EMRA series

Frequency: 1 MHz - 137 MHz

Each Series Homepage provides immediate and complete details on the electrical, mechanical, and environmental specifications that define the series, as well as compliance status, guides to marking and part numbering, and more.

See the other products
Ecliptek Corporation
crystal oscillator / MEMS / SMD / clock
crystal oscillator
EMRB series

Frequency: 32.77 kHz

Each Series Homepage provides immediate and complete details on the electrical, mechanical, and environmental specifications that define the series, as well as compliance status, guides to marking and part numbering, and more.

See the other products
Ecliptek Corporation
XO oscillator / electronic / SMD / clock
XO oscillator
E13C5, E15C5 series

Frequency: 62.5 MHz - 161.13 MHz

Each Series Homepage provides immediate and complete details on the electrical, mechanical, and environmental specifications that define the series, as well as compliance status, guides to marking and part numbering, and more.

See the other products
Ecliptek Corporation
XO oscillator / electronic / SMD / clock
XO oscillator
E13C7, E15C7 series

Frequency: 62.5 MHz - 250 MHz

Each Series Homepage provides immediate and complete details on the electrical, mechanical, and environmental specifications that define the series, as well as compliance status, guides to marking and part numbering, and more.

See the other products
Ecliptek Corporation
crystal oscillator / electronic / with connector / rubidium crystal
crystal oscillator
PRS10

Frequency: 10 MHz

The SRS PRS10 Rubidium Oscillator boasts an ultra-low phase noise feature and a 10 MHz rubidium-disciplined crystal oscillator which is low enough to be used as the reference source for synthesizers. ...

crystal oscillator / electronic / plug-in
crystal oscillator
SC10

Frequency: 10 MHz

This product is an ovenized 10Mhz quartz oscillator which is highly stable combined with flawless phase noise, Allan variance and aging characteristics. The SC10 features an SC-cut crystal to produce the lowest phase ...

VCXO oscillator / electronic / surface-mount / PLL
VCXO oscillator
ADFxxxx, ADxxxx series

Frequency: 0 GHz - 13.6 GHz

ADI uses PLL synthesizers with single and dual bodies and with integer and fractional-N standards with sturdy PLLs and VCOs. These are useful and work without much noise.

TCXO oscillator / crystal / electromechanical / surface-mount
TCXO oscillator
XN, XT series

Frequency: 10 MHz - 52 MHz

TCXO (Temperature compensated crystal oscillator) is a kind of crystal oscillator. TCXO provide a stable clock signal with temperature compensated circuit and good performance Crystal unit over wide temperature ...

SAW oscillator / electromechanical / surface-mount / low phase noise
SAW oscillator
HX, HO series

Frequency: 400 MHz - 1090 MHz

Murata Frequency Control products feature SAW-stabilized Optical Timing Clocks plus Diff-Sine Wave Clocks and Oscillators. Available in 200 MHz to 1.1 GHz operating frequencies. They provide extremely ...

OCXO oscillator / electronic / surface-mount
OCXO oscillator
OX-407

Frequency: 10 MHz - 50 MHz

The OX–407 Low g–sensitivity Oven Controlled Crystal Oscillator is housed in a compact 14x20mm dual inline package with g–sensitivity performance as low as 0.07ppb/g. Covering the frequency range of 10MHz to 50MHz and ...

See the other products
Vectron International
OCXO oscillator / electronic / with connector / ultra-low-noise
OCXO oscillator
OX-990

Frequency: 60 MHz - 120 MHz

Featuring Vectron's unique SR–45 crystal technology, the OX–990 is capable of meeting –135 dBc/Hz at a 100 Hz offset at 120 MHz, in addition to an ultra–low phase noise floor below –174 dBc/Hz. OX–990's standard ruggedized enclosure ...

See the other products
Vectron International
crystal oscillator / MEMS / SMD
crystal oscillator

Frequency: 50000 MHz - 80000 MHz

Compact low-jitter SPXO The SG-210S*D is a low-jitter SPXO using a QMEMS-based AT-crystal packed into an ultra compact 2.5x2.0mm2 SMD package. The SG-210S*D series is available with supply voltages of typ. 1.8V, 2.5V and 3.3V and with ...

See the other products
Epson Europe Electronics
crystal oscillator / MEMS / SMD
crystal oscillator
SG-210STF

Frequency: 1 MHz - 75 MHz

Very compact & low power SPXO The SG-210STF is a low power, cost competitive SPXO using a QMEMS-based AT-crystal packed into an ultra compact 2.5x2.0mm2 SMD package. The SG-210STF series is available with supply voltages of typ. 1.8V, ...

See the other products
Epson Europe Electronics
crystal oscillator / TCXO / electronic / surface-mount
crystal oscillator
JCO8 / JCO14

Frequency: 1 MHz - 160 MHz

Pin Type Oscillator ■ soldering temperature: 260 °C max. ■ metal package

See the other products
Jauch
XO oscillator / crystal / electronic / surface-mount
XO oscillator
VX3 series

Frequency: 0.5 MHz - 107 MHz

The SMU4 is a full metal crystal oscillator manufactured by Jauch Quartz. It features a tristate function, and is enclosed in a full ceramic package. SMU4 has a frequency range of 0.5MHz to 107.0MHz. It has a maximum ...

See the other products
Jauch
electronic oscillator / surface-mount / silicon
electronic oscillator
CMPT5179

... planar process, epoxy molded in a surface mount package, designed for low noise, high frequency amplifier and high output oscillator applications.

VCXO oscillator / electronic / surface-mount / VCO
VCXO oscillator
18.5 - 19.5 GHz | TGV2204-FC

Frequency: 18.5 GHz - 19.5 GHz

The TriQuint TGV2204-FC is a flip-chip voltage controlled oscillator (VCO) designed to operate at frequencies that target the automotive radar market. The TGV2204-FC is designed using TriQuint's proven HBT3 process and ...

See the other products
Triquint Semiconductor
VCXO oscillator / electronic / surface-mount / voltage-controlled
VCXO oscillator
TGV2529-SM

Frequency: 12.5 GHz - 13.5 GHz

The TriQuint TGV2529-SM is a monolithic voltage controlled oscillator (VCO) designed to operate at frequencies that target the Point-to-Point, VSAT, and millimeter wave communication markets. The TGV2529-SM ...

See the other products
Triquint Semiconductor
VCXO oscillator / electronic / surface-mount / PLL
VCXO oscillator
74HC, HEF4046 series

Frequency: 0 MHz - 17 MHz

... loop (PLL) is a feedback system that synchronizes an oscillator to the phase and frequency of an incoming signal. The PLL consists of a phase comparator, loop filter and voltage controlled oscillator ...

VCXO oscillator / electronic / surface-mount / VCO
VCXO oscillator
TFF10xx series

Frequency: 12.8 GHz - 13.05 GHz

Better RF performance Highly integrated, NXPs LO generators save board space and make design-in easier, for lower overall cost and faster development. We offer two series of LO generators: the TFF100xHN are optimized for VSAT applications, ...

crystal oscillator / MEMS / surface-mount / silicon
crystal oscillator
Si500D, Si500S​

Frequency: 0.9 MHz - 200 MHz

Silicon oscillators manufactured by Silicon Labs provide comparable performance to crystal oscillators. By leveraging innovative stabilization circuitry, silicon oscillators eliminate ...

See the other products
Silicon Laboratories
XO oscillator / electromechanical / surface-mount
XO oscillator
Si5xx series

Frequency: 10 MHz - 1417 MHz

Silicon Labs' crystal oscillator (XO) family offers the industrys shortest lead times, highest reliability and unmatched performance, making these crystal oscillator devices ideal for applications such ...

See the other products
Silicon Laboratories
electromechanical oscillator
electromechanical oscillator
Cyclomatic

Frequency: 60, 50 Hz

... probe position, oscillate, or stabilize the arc without torch movement. The probe mounts to the torch to provide precise control and repeatability via the application of magnetic forces around the arc. Stabilizes or ...

VCXO oscillator / electromechanical / surface-mount
VCXO oscillator
NBX series

Frequency: 75 MHz - 312 MHz

Silicon-based crystal oscillator and voltage controlled crystal oscillator clock modules.

VCXO oscillator / electronic / surface-mount / PLL
VCXO oscillator
MC series

Frequency: 0 MHz - 1100 MHz

TCXO oscillator / crystal / electronic / surface-mount
TCXO oscillator
6.4 - 38.4 MHz

Shoulder SMD TCXO crystal oscillator series is an assembly of electrical accessory that allows operation within frequency tolerance of -1.5 tp 1.5 ppm, and operating temperature range of -30 to 75°C. It requires supply ...

XO oscillator / crystal / electronic / surface-mount
XO oscillator
1 - 156.2500 MHz

This device has a frequency ranges from 1.0000 MHz to 156.2500 MHz. It also has stable frequencies of ±25 ppm, ±50 ppm, and ±100 ppm. It can operate in temperatures ranging from - 40'C to 85 "C or 20'C to 70'C or 0'C to 70 "C. It also ...

XO oscillator / electronic / surface-mount
XO oscillator
XOSM Series

Frequency: 1 MHz - 100 MHz

Vishay’s frequency control product line offers a complete range of crystals and oscillators. These cost-effective commercial products are available in the standard packages as well as the latest in ceramic surface mount technology.

How to choose this product

oscillator

An oscillator emits a periodic signal at a precise frequency. The frequency is generally fixed if the device is a component soldered to a circuit. Independent units offer a range of frequencies.

Applications

These devices are used in electronics to generate clock signals, for GPS positioning and in radar and aerospace systems. They also provide data exchange synchronization in communications networks. Femtosecond oscillators are used in pulse lasers.

Technologies

An oscillator consists of a resonator and an exciter. Quartz's piezoelectric effect produces very stable clock signal frequencies between one and 100 MHz. The quartz is housed along with the necessary electronic circuitry. It can be temperature compensated (TCXO) or thermostatic (OCXO). Crystal-free pMEMS™ oscillators now offer competition to quartz models.

The VCO oscillator emits a variable and controllable signal. Ceramic resonators can operate at lower frequencies than quartz versions. Surface acoustic wave (SAW) resonators operate beyond 100 MHz, while Gunn diode and cavity hyper-frequency devices go above 10 GHz.

How to choose

Choice will depend on output signal frequency, thermal phase noise, frequency precision and stability, signal shape and treatment.
