Heating ovens with forced convection
BINDER FED series:
The FED series is a true all-rounder. It has a virtually unlimited capacity and is at the same time particularly adaptable to the specific requirements of a large variety of testing applications. The enhanced time functions and the digitally controlled air turbine can be used to adjust ideal temperature parameters and recirculation air conditions.
|
|
Internal dimensions :
4.5 m x 2.5 m x 2.0 m
Working temperature : 160°C
Control system :
Scheduler, regulator and recorder
|
|
|
Developed in response to the paper industry’s requirement for a high performance drying system with a small footprint, the HPC dryer combines web handling and the mass transfer capabilities of a conventional flotation system to achieve the heat transfer capabilities and compactness of a typical Infra Red system.
|
|
|
|
|
|
Spooner baking ovens are based on forced convection technology. This ensures flexible, reliable operation and ease of control. Radiant effect heating can be included for enhanced machine flexibility, enabling a wide range of products to be processed on a single oven and ensuring the optimum colour, texture and dryness are achieved.
Features of the Spooner baking oven include:
-Optimised heat transfer rates and nozzle designs
-Energy efficient designs
-Integral heat recovery to minimise running costs
-Even tempertures across the oven result in an even bake
-Rapid warm-up and quick temperature changes with direct-fired ovens
-No flash heat when there are gaps in production
-Fan location to suit space available - top or side mounted
-Designed for ease of cleaning and maintenance, ensuring a hygienic, food safe environment
-Innovative access designs are available giving complete oven access
Spooner baking oven types include:
-Direct fired
-Indirect fired
-Hybrid
-Solid band or stone bake type conveyor
-Ladder design
|
|
|
|
|
|
PERFORMANCES:
The industrial ovens are easy to use, having both functional and practical equipment, at very reasonable prices. All industrial ovens are strongly ventilated for the accuracy and homogeneity of the temperature in the volume.
Designed to operate up to 200°C or 300°C as an option.
- Why choose our XL industrial ovens ? Rapid heating-up: 8°C/minute
- Temperature fluctuation: less than ±0,2°C
- Temperature spatial variation: less than ±1,2°C at 105°C and less than ±2,5°C at 200°C
- Glasswool safe for user (no carcinogenic)
- High Insulation: 110mm, for the best heating quality
CONSTRUCTION:
- Eight sizes from 125 to 2520 liters.
- Control panels are on the left hand side.
- The inner casing is made of corrosion resistant stainless steel, bright polished.
- The outer casing is made of sheet steel, finished in a tough stoved epoxy paint (color light grey RAL7035).
- No contact between inner and outer casing and an optimised insulation minimises heat dissipation.
- The walls and the door are insulated with glasswool, safe for users. The insulation is 110mm thick, ensuring efficient operation, low external temperatures and excellet thermal stability.
- The sillicone rubber gasket provides a good seal between the door and the oven body, aiding insulation.
- The insulation and the gasket are asbestos-free.
- The door is hinged on the right hand side and closed with a robust 2 points fastener.
|
|
Temperature test chambers with forced convection and individual programming
BINDER M series:
Because of its individual programming options and ability to operate at maximum temperatures up to 300 °C, the M series is ideally suited for materials testing and aging tests. The heavy-duty air turbine and a programmable exhaust ventilation flap provide rapid heating-up and ensure that the test temperature is maintained absolutely precise at all levels, with minimal spatial fluctuations; performance as never before.
|
|
|
|
|
|
All our laboratory ovens are fan circulated models, for accuracy and minimum temperature spatial deviation.
Two temperatures: 200°C or 300°C as an option (with an optimised thermal insulation and higher power rating).
- Why choose our XU laboratory ovens ? Rapid heating-up
- Temperature fluctuation: less than ±0,2°C
- Temperature spatial variation: less than ±1,2°C at 105°C
- Our own C3000 Controller for the best homogeneity
- Glasswool safe for user (no carcinogenic)
- High Insulation: 80mm, for the best heating quality
Designed up to operate from room temperature +10°C up to 200°C (300°C in option).
CONSTRUCTION:
- Eight sizes from 27 to 980 liters.
- The inner casing is made of corrosion resistant stainless steel, bright polished.
- The outer casing is made of sheet steel, finished in a tough stoved epoxy paint (colour white RAL9002).
- No contact between inner and outer casing and an optimised insulation minimises heat dissipation and allow a best heating quality.
- The walls and the door are insulated with glasswool, safe for users. The insulation is 70mm of glasswool and 10mm of empty space, ensuring efficient operation, low external temperatures and excellent thermal stability.
- The silicone rubber gasket provides a good seal between the door and the oven body.
- The door is hinged on the right hand side.
|
|
|
|
|
|
Carbolite’s LGP range of industrial batch ovens sets the standard for a wide range of industrial processing applications
The ovens provide excellent performance and reliability
Standard chamber capacities range from 500 – 14,000 litres, at temperatures up to 250°C, 425°C and 625°C
A long working oven life is ensured by a ferritic stainless steel interior
The external construction is of mild steel section clad with zinc coated steel sheet
High thermal efficiency is achieved through the use of low thermal mass insulation
Air circulation is critical for efficient and uniform heating and horizontal air flow is achieved via heavy duty impellers at 1400rpm driven by three phase electric motors (vertical airflow is available on selected models if required)
A temperature uniformity of +5°C to within 100mm of the walls and roof and 150mm of the doors and floor is achieved
Most models are fitted with side hinged doors, either single or double, depending on the size of the oven
Vertically rising doors are fitted as standard on large volume 600°C ovens (over 1m3) and are optional on other models
|
|
|
|
|
|
PERFORMANCES:
The high temperature ovens are easy to use, having both functional and practical equipments, at very reasonable prices compared with furnaces.
All high temperature ovens are strongly ventilated for the accuracy and homogeneity of temperature in the volume.
Low thermal mass insulation materials and strong power rating have been used to achieve rapid heating.
* Why choose our XHT high temperature ovens ? Rapid heating-up
* Tempetaure up to 500°C
* Temperature fluctuation: less than ±0,2°C
* Temperature spatial variation: less than ±2,5°C at 200°C
They are suitable for a large number of applications: burning, degassing, pre-heating, hardening, hot air sterilization, tests... in many branches of industry.
CONSTRUCTION:
* Five sizes from 75 to 686 liters.
* The inner casing is made of corrosion and heating resistant stainless steel.
* The outer casing is made of sheet steel, finished in a tough stoved epoxy paint (white colour RAL7035).
* No contact between inner and outer casing and an optimised insulation minimises heat dissipation and allow a best heating quality.
* The walls and the door are insulated with glasswool, safe for users. The insulation is 150mm thick, ensuring efficient operation, low external temperatures and excellent thermal stability. A special gasket provides a good seal between the door and the oven body, aiding insulation.
* The insulation and the gasket are asbestos-free.
* The door is hinged on the right hand side and closed with a 2 robusts point fastener.
|
|
Drying ovens with natural convection
BINDER ED series:
Routine drying and sterilization applications up to 300° C and storage at precisely controlled elevated temperatures are the strengths of ED drying ovens. Because of the natural air circulation with a high rate of air exchange, thermal processes run with significantly increased efficiency.
|
|
Maximum operating temperatures of 400°C, 500°C & 600°C
Chamber capacities of 30, 60 & 120 litres
Good temperature uniformity
Fast heat up and recovery times
Polished stainless steel interior
Stainless steel shelves with multi position settings
Choice of controllers & programmers
|
|
Our U Universal ovens are so varied that almost every customer application can be covered by them. Choose from: 8 model sizes (14l to 749l); 3 performance classes Basic/Excellent/Perfect; Natural convection or forced air circulation N/F.
In accordance with the Law on Medical Products (Directive 93/42/EEC), the UFE / UFP appliances can be used to warm up non-sterile cloths and covers.
|
|
Vacuum drying oven for non-flammable solvents
BINDER VD series:
The VD series offers safe drying with homogenous temperature distribution, thanks to its APT.line™ air jacket system. Optimum heat transfer through patented expansion rack technology; the racks can be positioned as needed and are easy to clean. In addition to these many features, the units have an individually programmable controller.
Find out more: www.vacuum-drying.com
|
|
With short heating up times, high precision temperature control and turbo drying, the VO vacuum ovens show off all their power - at the same time they treat heat- and oxygen-sensitive substances and materials with incomparable care. The direct contact between the load and the heatable and removable thermoshelves ensures rapid and equal heating up without thermal loss. Your decision criteria: 3 model sizes (29l, 49l and 101l); State-of-the-art control technology based on the P performance class for all models; Anti-splinter, VDE-tested door construction for all models.
Each of the maximum four (model size 29l: maximum three) insertable thermoshelves is equipped with a separate large area heating and its own sensors. The control circuits react precisely to differences in load and humidity. In this way all levels used remain equally at the predefined set temperature.
|
|
|
|
|
|
PERFORMANCES:
The industrial ovens are easy to use, having both functional and practical equipment, at very reasonable prices. All industrial ovens are strongly ventilated for the accuracy and homogeneity of the temperature in the volume.
Designed to operate up to 200°C or 300°C as an option.
- Why choose our XXL industrial ovens ? Rapid heating-up: 8°C/minute
- Temperature fluctuation: less than ±0,2°C
- Temperature spatial variation: less than ±1,2°C at 105°C and less than ±2,5°C at 200°C
- Glasswool safe for user (no carcinogenic)
- High Insulation: 110mm, for the best heating quality
CONSTRUCTION:
- Seven sizes from 3m3 to 12m3.
- Control panels are on the left hand side.
- The inner casing is made of corrosion resistant stainless steel, bright polished.
- The outer casing is made of sheet steel, finished in a tough stoved epoxy paint (color light grey RAL7035).
- No contact between inner and outer casing and an optimised insulation minimises heat dissipation.
- The walls and the door are insulated with glasswool, safe for users. The insulation is 110mm thick, ensuring efficient operation, low external temperatures and excellet thermal stability.
- The sillicone rubber gasket provides a good seal between the door and the oven body, aiding insulation.
- The insulation and the gasket are asbestos-free.
- The door is hinged on the right hand side and closed with a robust 2 points fastener.
|
|
300°C General purpose horizontal & vertical industrial ovens (GP)
A standard range of industrial ovens
Maximum operating temperature 300°C
Volumes of 220, 330 and 450 litres
Heating by mineral insulated metal sheathed elements
Good temperature uniformity
Polished stainless steel inner chamber
|
|
|
|
|
|
PERFORMANCES:
A highly versatile range of compact vacuum ovens. These vacuum ovens enable heat sensitive materials to be dried at low temperature.
More stable samples can be dried at higher temperature up to 200°C or 300/400°C as an option.
You can use our vacuum ovens for any laboratory or industrial application.
Designed to operate from room temperature +20°C up to 200°C (300/400°C in option).
Final vacuum of 10-2 mBar, depending on the vacuum pump used.
Temperature time fluctuation: less than ±0,2°C.
CONSTRUCTION:
* Four sizes from 20 to 240 liters.
* The inner casing is made of corrosion resistant stainless steel, with rounded corners.
* The outer casing is made of sheet steel, finished in a tough stoved epoxy paint (colour light grey RAL7035).
* No contact between inner and outer casing and an optimised insulation minimises heat dissipation.
* The walls are insulated with glasswool, low external temperatures and excellent thermal stability.
* The door is a thick toughened glass plate.
* The sillicone rubber gasket provides a good seal between the door and the oven body.
* The insulation and the gasket are asbestos-free.
* The door is hinged on the right hand side.
HEATING QUALITY:
The chamber is heated by large area heaters strapped to its outer surface.
No-wear switching (solid state relay) is used for activating and desactivating the heating elements.
As an option, internal heating plates can be installed instead of the external heating elements.
|
|
GBC FE oven for welding electrodes drying & storage.
Temperature range from 0° C to 400° C, with completely automatic programmable drying or heating cycles, power from 1700 W to 6000 W.
Load capacity up to 300 Kg.
High insulation and safety grade guaranteed by door latch avoiding any accidental door opening while temperature is in danger range for operator.
Supplied with internal separate shelves for accommodation of different welding electrodes size and compound.
|
|
|
Most widely used heat aging tester of rubber and plastic. Unlike ordinary heating ovens, the testers satisfy specifications indispensable to aging test such as closed mechanism, uniform air velocity in the oven, ventilation rate measurement, rotating soecimen rack, offering excellent reproductibility and reliability.
|
|
|
The LAC bench-top oven features horizontal recirculating airflow and exceptional temperature uniformity. The LAC has proven reliability in demanding production and laboratory applications such as curing, drying, sterilizing, aging and other process-critical procedures. The high-performance oven delivers temperatures up to 260ºC (500ºF). Controls allow up to eight programs each with eight ramp and soak segments. Standard features include LED temperature display, stainless steel interior and 3” of glass fiber insulation. All models are UL & C-UL listed and the heating elements carry a five-year warranty.
|
|
Despatch RA and RF Series Reach-In Ovens feature uniform airflow and temperature consistency, ergonomic design, and smaller footprint
The Despatch RA Series and RF Series Reach-In High Performance Production Ovens have been used throughout the world for industrial production environments. These ovens are designed to provide process versatility, reliability and consistency in drying, curing, bonding and heat-treating applications. Ideal for use in industrial production environments, these ovens operate up to 650º F. The RA Series is designed for use in standard environments, and the RF Series is designed for Class A environments where flammable solvents are used. Despatch provides the design integrity, manufacturing experience and emphasis on quality necessary for dependable operation and excellent process control. To learn more please visit us at www.despatch.com or call our Product Specialists at 1-800-828-9903 Int'l 1-952-469-5424
|
|
|
|
|
|
The Qmax Series High Performance Reach-in forced-convection oven is specifically designed to meet the frequent air changes and tight temperature uniformity required of the ASTM 5423 Type I & Type II oven specification. A high-volume fan circulates air through perforated, stainless steel walls to create a constant horizontal airflow across all sections of the oven. The result is highly uniform airflow to easily meet ASTM 5423 Type I and II specification while tested according to ASTM 5374.
The Qmax Series High Performance Reach-in oven exceeds the ASTM 5423 Type II performance requirement a temperature variation of less than 6°C at 300°C while maintaining 100-200 air changes per hour. In addition, the brass bar thermal lag time showed superior oven temperature recovery. These ovens can be used for applications such as thermal evaluation of electrical insulating materials, testing, aging, curing, drying, sterilizing and other thermal applications where tight temperature uniformity is required.
|
|
Defining the standard in high temperature clean process ovens for the production environment, Despatch's LCD2-14 clean process oven offers the ultimate in HEPA filtration for processes where minimal contamination is essential. The LCD2-14 maintains Class 100 through the process cycle with ramp rates up to 5°C per minute. It is available in three different atmosphere configurations:
Inert Atmosphere - Allows nitrogen (or other inert gas) to be injected into the chamber to lower the oxygen level to prevent oxidation of products. A water cooling coil is provided for rapid cooling. Control of nitrogen flow and water cooling is programmable through the Protocol PlusTM Controller.
Class A Atmosphere - Meets NFPA requirements for processing flammable solvents, including a pressure relief panel (rear of oven), purge timer, and forced exhaust.
Air Atmosphere - A forced exhaust fan is included on the air atmosphere unit for rapid cooling.
|
|
Clean room heating and drying ovens,
series VTF for clean room class DIN ISO 5
Cleanroom heating and drying ovens
with working chamber volume of 63 ltr,
for heat treatment until 350 °C under
cleanroom conditions of class 100
Working chamber volume 63 – 3.125 litres
Nominal temperature 230 °C, 300 °C and 350 °C
Cleanroom class 100
|
|
Batch Drying curing Oven
Industrial tailor-made ovens from 1m³ to 200m³ designed to meet your process needs of insulation, temperature and power.
With a temperature range of 20°C up to 500°C these industrial ovens are suitable for all applications of preheating, drying, cooking, polymerization, curing, tempering, stabilization, cooling.
|
|
|
|
|
|
New line of electric ovens are designed for thermal treatment such as drying, heating, thermal testing in an air-flow environment.
Forced convection makes more effective drying and quicker heating, homogeneity of temperature. Good technical parameters ensure to high-quality results. This line allows choices of oven chamber from mild steel LFP or stainless steel (LFN). Available is 5 sizes at temperature ranges up to 300 ºC.
• Micro processor temperature controller with autotuning function
• Double over heat protection system
• Digital setting of temperature
• SSR relay
• High quality thermoinsulation material
• Chamber made of mild steel or stainless steel
• 3 shelves
• Horizontal air flow
• Air outlet control by valves operated manually
• Regulation of fan speed (0-100%)
• Acoustical signalization
• Short heating time
• Heating is from four sides
• Hermetic closing door
• Low power consumption
• High precision level
• Interface RS 232 and software for E5CK 2008
• Interface RS 485 and software for TCViews
• Limited warranty up to two years and later service
|
|
Explosion-proof heating oven
and drying oven VFT 60/90
The VFT 60/90 is an ex-proof fresh air heating and drying oven. The oven is electrically heated and designed according to the fresh-air-principle. Due to the small floor space required it is also suitable for installation in laboratories and in production departments. The advantages, e.g. no restriction on the volume of combustible solvents, suitable for solvents with the temperature classes T1, T2, T3, T4 in the explosion groups IIA and IIB, precise temperature uniformity in the whole working chamber.
Working chamber volume 300 liters
Temperature 200 °C
Temperature classes T1, T2, T3, T4
Installation Zone 2
|
|
|
The Despatch LBB oven features a combination of horizontal and vertical airflow that offers excellent temperature uniformity at a moderate price. It is recommended for a variety of laboratory and production applications including drying, curing, annealing and materials testing.Every LBB oven is UL and C-UL listed, and receives a thorough performance test before shipping.
|
|
· Definition : forced convection electric oven for all applications.
· Construction : stainless steel interior, height-adjustable shelf supports.
· Insulation : rock wool insulation of all surfaces, including door.
· Ventilation : stainless steel motor ventilator with adjustable ventilation device.
· Heating : battery of shielded electrical resistors.
· Electricity : Single-phase 230V, 50Hz.
· Regulation : 1 thermocouple with digital temperature controller, programmable timer, RS232 port, safety thermostat.
· Documentation : certification CE and operating instructions in English.
· Delivered with : 2 shelves.
· Versions : *-V models with glass window, otherwise metal door.
|
|
· Definition : forced convection electric oven for all applications.
· Construction : stainless steel interior, height-adjustable shelf supports, epoxy-coated exterior.
· Insulation : rock wool insulation of all surfaces, including door.
· Ventilation : stainless steel motor ventilator with adjustable ventilation device.
· Heating : battery of shielded electrical resistors
· Electricity : 3 x 400V, certain models are also available in single-phase 230V-50Hz frequency version.
· Regulation : 1 thermocouple with digital temperature controller, programmable timer, RS-232 port, safety thermostat.
· Documentation : certification CE and operating instructions in English.
· Delivered with : 2 shelves
· Versions : *-M models with single-phase 230V, 400 l volume and up include double door.
|
|
... see all the products in the category
Ovens
|
|
|
