| High-performance, low-noise preamplifier that is ideal for a wide variety of applications including low-temperature measurements, optical detection, and audio engineering. |
|
A low noise RF pre-amplifier with nominal 18dB gain covering the frequency range 5KHz to 1100MHz. This battery powered unit features low noise performance making it ideal for any application requiring wide band amplification of low level signals. The SA1020 is used in conjunction with the Log Periodic Professional antenna and the Line Impedance Stabilization Networks (LISNs).
|
|
| This section describes the amplifier circuits recommended for Judson detectors. The PA-5, PA-6, PA-7 and PA-9 series preamplifiers are current gain professional amplifiers recommended for photovoltaic detectors and applications. Voltage mode preamplifiers, for use with our photoconductive detectors, include the PA-101, PA-8200 and PA-300 series preamps. |
|
Preamplifiers for EMI / EMC testing from 100 Hz - 40 GHz
Broadband, high gain with minimum gain variation for accurate EMC measurements.
Com-Power broadband high gain preamplifiers were designed for electromagnetic interference (EMI) testing and certification. EMC test labs use preamplifiers to improve sensitivity of the professional test system during EMI radiated emissions measurements. Without a high gain preamplifier, signals picked by the professional antenna that have amplitudes below the noise floor of the test system cannot be measured. The preamplifier gain has minimum variations for the entire operating frequency range for accurate emissions measurements. The Com-Power preamplifiers were primarily intended for EMC applications. However, it can be used for other applications that require signal amplification. |
|
Preamplifiers for EMI / EMC testing from 100 Hz - 40 GHz
Broadband, high gain with minimum gain variation for accurate EMC measurements.
Com-Power broadband high gain preamplifiers were designed for electromagnetic interference (EMI) testing and certification. EMC test labs use preamplifiers to improve sensitivity of the professional test system during EMI radiated emissions measurements. Without a high gain preamplifier, signals picked by the professional antenna that have amplitudes below the noise floor of the test system cannot be measured. The preamplifier gain has minimum variations for the entire operating frequency range for accurate emissions measurements. The Com-Power preamplifiers were primarily intended for EMC applications. However, it can be used for other applications that require signal amplification. |
|
PCB Automotive Detection Debuts High Temperature Preamplifier
Operating to +120 °C for NVH Powertrain & Vehicle Underhood Testing
The Automotive Sensors division of PCB Piezotronics (PCB®) has announced release of a new high-temperature preamplifier, designed to overcome high temperature testing challenges associated with NVH powertrain and vehicle underhood testing applications, and to broaden options for NVH test engineers collecting acoustic data in high temperature areas.
Automotive engineers routinely perform NVH tests in areas around the powertrain, where elevated operating temperatures can present major measurement challenges. Underhood temperatures can peak at +125 0C under normal driving conditions, and can be significantly higher near turbochargers and exhaust system components, such as manifolds and diesel particulate professional filters. In the past, test engineers were limited by preamplifiers offering temperature ranges to + 70 °C. Model HT426E01 is a 1/2" preamplifier operating from ICP sensor power, terminating with BNC professional connector and utilizing standard in line cables. The model features a low attenuation factor (-0.06 dB) and low noise characteristics, 4.9 µV, based on an A-weight professional scale.
Common applications include underhood measurements for benchmarking and issue professional identification, including professional engine radiated, induction, ancillary and turbocharger noise; near-field measurements on manifolds; mufflers; exhaust after treatment components; and tailpipe noise. NVH groups within OEMs and Tier 1 suppliers involved with testing of powertrain components will benefit most from this product. |
|
Low noise and wide bandwidth transimpedance preamplifier (10kHz to 1 GHz, in dependence on detector capacitance). The devices enforces DC bias that is required for optimized operation of a given type of infrared detector. Integrated with detectors packages are available.
Applications:
- Quantum cascade professional laser detection
- Laser technology
- Fast laser pulse measurement
- Telemetry
- Sighting systems
- Free space optics (l=10µm, transfer Gb/s)
The detector is followed by the high performance preamplifier specially designed to obtain the best performance from the VIGO System's detector. Each preamplifier is carefully optimized to work with particular type of detector. The preamplifier ensures stable work in all conditions and the highest signal to noise ratio of the whole system.
|
|
The integrated IR detector and preamplifier module has been designed especially for various OEM applications, eg. contactless temperature measurement, pyrometers, professional scanners, free space optical communication, professional laser detection, gas analysis, Fourier spectroscopy, fire and human body detection and nondestructive material testing.
SIPAC series is characterized by high signal to noise ratio, bandwidth up to 250 MHz and very small dimensions. The infrared TE cooled detector is integrated with AC or DC coupled transimpedance or voltage preamplifier. High performace is achieved with individual matching of the IR detector to the preamplifier and good heat dissipation management. The device can be easily adjusted to the customer's specific requirements. |
|
|
|
