The J5 provides measurement of melt pressure and other process variables. The J5 features a large 5 digit display that can operate in either green or red or change color in case of alarm. The J5 is configurable from the front, or from a PC with a software tool. The main input is for Strain Gauge or linear DC voltage/current with square root extraction or with a 16 segment linearizer. The second input with DC voltage or current is suited to temperature indication and signal conditioning (min, max, average, ratio, etc.) when combined with the main input. The J5 has 3 digital inputs independently configurable for alarms, display and calibration handling. Up to four alarms with ISA-A acknowledge are available as well as a retransmission output and Modbus RS485 comms. The J5 has three levels of password protection and the front panel is IP65. The strain gauge bridge of the melt pressure or load cell transducer can be powered by an internally regulated 5 or 10Vdc. The reliability of the strain gauge is monitored continuously. A front panel calibration routine is provided to automatically remove zero and span offsets. The automatic calibration can also be activated by using front keys, one of the three digital inputs, or over serial comms. Tare function for load cells is provided.
|
|
The JOFRA range of IPI Industrial Pressure Indicators is ATEX and CSA certified for use in potentially explosive environments in the field or in calibration laboratories. ATEX is the primary intrinsically safe standard in the European Union, while CSA refers to relevant Canadian and USA standards.
Accurate to ± 0.05% FS, the IPI can be used as a calibration reference or in applications where high accuracy pressure measurement is required from safety valve checks to system pressure verification. This Ex certification will allow the IPI to be used in any industry where there is a risk of flammable gases. These include oil refineries, off-shore platforms, chemical plants, gas production plants, oil and gas shipping, pharmaceuticals and in whisky distilleries.
|
|
HVAC measurement device PascalMaxx for monitoring & control
Differential pressure instrument with membrane measurement technology for monitoring and control of differential pressures and air flows in HVAC applications. Suitable for rooms and ducts.
By the integrated switch the pressure conditions can be monitored and an alarm set in case of need. The also integrated analogue outputs (V and mA) can be used for a system control. The automatic Zero-Point calibration assures an accurate and reproducible measurement at any time and avoids any influence of the mounting position on the measurement results.
|
|
Digital Pressure Controller/Calibrator - Model 7250
The Model 7250 Digital Pressure calibrator is available in a variety of pressure ranges from 0-5 psi to 0-3000 psi, and is an economical alternative to the Model 7250xi and 7250i. The Model 7250 provides 0.003% of full scale precision and can control to the set point in 15 seconds with no overshoot. When a higher level of performance is required, please refer to the 7250i and 7250xi Digital Pressure Controllers.
|
|
Pressure Indicators
The Vista-Gage is a unique piston-type pressure indicator, specifically designed to withstand machine vibration, shock, pulsation, pressure surges and other rigorous conditions that create problems for conventional pressure gauges, with fragile bourdon tube mechanisms. Available in Vista-Gage for High-pressure, Lo-pressure and Vacuum indicators, Vista-Cator for GO/NO-GO indicators, and Vista-Monitor for Accumulators.
|
|
|
The series A2 digital differential pressure gage is a patent pending microprocessor based digital pressure gauge for positive, negative, and differential measurement designed to be a direct replacement for mechanical gauges. The Series A2 differential pressure gauges utilize an extremely stable piezoresistive sensing technology to give a standard full scale accuracy of 1%. For applications requiring better accuracy, the A2 is also available with 0.5% accuracy. The A2 pressure gauge also has an optional 4-20 mA output for applications requiring an output signal. The A2 features a bright ½" LED display and process arch, which gives the gauge improved readability and precision. The A2 digital differential pressure gauges also feature 5 user selectable engineering units including in. w.c., mm w.c., cm w.c., kPa, and Pa. The Series A2 offers an improved look, and performance compare to mechanical gauges.
|
|
MICO Digital Pressure Gauges are the versatile and economical choice for a wide variety of applications. These are 10,000 PSI gauges with terminal point accuracy, which allows re-zeroing to eliminate sensor offset. Full scale .5% terminal point accuracy includes linearity, hysteresis, and repeatability.
The standard MICO gauge has a chemical resistant Noryl® case and comes with a protective boot, which has an IP54 rating. They are also available with 12" or 36" hoses and a 16-piece fitting kit. MICO gauges meet ASME B40.7 standard and comes with a CE approval.
Other standard features of these gauges include nine engineering units of measure, 5 digit display with 1/2" character size, backlight, minimum and maximum pressure indication, and a welded stainless steel 1/4" pipe socket and sensor. Their proof pressure is 120% of the range and their burst pressure is 150% of the range.
|
|
|
|
|
|
ServiceJunior without yarn.
Little genius of the diagnosis
Description:
- Transmission without yarn of the data.
- Possibility of data acquisition on the long term.
- Digital display with lighting.
- Conceived for remote control.
- Kit containing the JuniorWin software for PC.
- Function selected of peak (posting with bars and function actuated needle).
- Measurement of the points of pressure at rate of 10 ms reading (function max. min/).
- Range 50 m minimum.
- Whole Posting of the scale.
- Simplicity of handling by 4 keys.
- Integrated Battery: lifespan 1.500 hours.
- Index of protector IP54.
- Beach of pressure: -1... 16 bar/0... 100 bar/0... 400 bar/0... 600 bar.
Advantages:
- "Intelligent" Management of the memory.
- Is based on technology without wire, no connection by cable towards the PC is not necessary.
- A faster transfer of the data Allows the PC.
- Direct and simple Connection of ServiceJunior on the hydraulic system.
- No other portable apparatus nor another sensor and cable are necessary.
- Simple Use with lower costs for better results.
- Robust Enclosure not dirtying.
Applications:
- Machine tools
- Mobile Machines
|
|
|
|
|
|
At any point with limited space, where the process pressure has to be indicated locally, and, at the same time, a signal is wanted to be transmitted to a central controller or remote control room, the model PGT23.063 INTELLiGauge can be used.
Through the combination of a mechanical measuring system and electronic signal processing, the process pressure can be read securely, even if the power supply is lost. The model PGT23.063 INTELLiGauge fulfils all safety-related requirements of the relevant standards and regulations for the on-site display of the operating pressure of pressure vessels. An additional measuring point for the mechanical pressure indication can thus be saved.
The model PGT23.063 is built upon a high-quality, stainless steel pressure gauge in safety pattern version model 23x.30 with nominal size of 63. The pressure gauge is manufactured in accordance with EN 837-1.
The durable, fully-welded Bourdon tube measuring system produces a pointer rotation proportional to the pressure. An electronic angle encoder, proven in safety-critical automotive applications, determines the position of the pointer shaft - it is a non-contact sensor and therefore completely free from wear and friction. From this, the pressure-proportional, 4 ... 20 mA electrical output signal is produced.
The electronic WIKA transmitter, integrated into the highquality mechanical pressure gauge, combines the advantages of electrical signal transmission with the advantages of a local mechanical display.
The measuring span (electrical output signal) is set automatically along with the mechanical display, i.e. the
scale over the full display range corresponds to 4 ... 20 mA.
|
|
The DiFFXP is a Ruggedized differential test set!
The DiFFXP is a ruggedized differential pressure test set with the accuracy and features of the XP2i gauges. The DiFFXP is rated at 0.14% of static line reading accuracy.
Valves, piping and sensors are all stainless steel
Enclosure is watertight, crushproof and dustproof
Enclosure is rated to NEMA IP67
|
|
|
|
|
|
Differential pressure measurement is a crucial parameter for determining pollutant pathways for IAQ and worker exposure applications. It is also a key HVAC parameter in commercial and institutional buildings and in manufacturing plants, among many other important applications.
Each Zephyr II instrument includes a built-in, auto-zeroing, micro-manometer and 'K'-type thermocouple input for measuring differential pressure, static pressure and temperature. The auto-zeroing feature allows for highly accurate differential pressure logging over time. With a pitot tube, the Zephyr provides direct air velocity readings. Zephyrs can also be fitted with a telescoping 3-function probe (model 2300 AHTS) to measure humidity, temperature and (hotwire) airspeed.
The Zephyr II range has been designed with the user in mind. The large rubber grip and simple membrane switch pad ensure the unit is comfortable to use allowing pushbutton operation even with gloves on. The 2300 AHTS probe attaches to the side of the instrument for single-handed operation.
The display and menu system provide step-by-step guides for each operation. This ensures minimal user training is required. Data capture is included as standard to allow duct traversing. Volumetric flow is calculated by simply entering the size of the duct and the instrument performs the necessary calculation.
The Zephyr II is a stand-alone instrument. However, with all of it's available parameters, it may be interfaced to any GrayWolf WolfSense PPC or LAP mobile PC based system via a CF serial card (model ACC-SCDPC); opening the door to the full extent of GrayWolf's DirectSense product features.
|
|
DPG - Differential Pressure Gauge
The DPG is ideal for measuring differential pressure, air flow, under and over pressure of air and non-aggressive gasses.
The applications of DPG include monitoring air filters and controlling fans, measuring over- and underpressure in air ducts, air handling units, clean rooms and laminar flow cabinets as well as differential pressures between different spaces.
|
|
These differential pressure gauges are made of highly corrosion-resistant stainless steel and feature an all-metal, all-welded media chamber to ensure long-term leaktightness (no elastomer sealing elements).
A high overpressure safety is achieved by the all-metal construction and the close-fitting design of the pressuremeasuring diaphragm.
With its high-grade stainless steel construction and robust design this pressure gauge is geared to chemical and process engineering applications. It is suitable for gaseous or liquid media and also for corrosive environments.
Scale ranges from 0 ... 16 mbar to 0 ... 25 bar are available to meet the requirements of a wide variety of applications.
|
|
|
The Series P2000 differential pressure gauges are low cost, diaphragm operated, mechanical pressure gauges in an ABS housing. The P2000 gage can be used in applications for measuring positive, negative, or differential pressure with an accuracy of 2%. Standard applications include monitoring filter status, duct static pressure, room pressure, fan or blower pressure, paint booths, dust collectors, and cabinet purging along with many others.
|
|
Aluminum Housing
The Series S2000 differential pressure gauges are low cost, diaphragm operated, mechanical pressure gauges. The S2000 gage can be used in applications for measuring positive, negative, or differential pressure with an accuracy of 2%. Standard applications include monitoring filter status, duct static pressure, room pressure, fan or blower pressure, paint booths, dust collectors, and cabinet purging along with many others.
|
|
|
The Series S2000 differential pressure gauges are low cost, diaphragm operated, mechanical pressure gauges. The S2000 displayed has an aluminum housing with a stainless steel front ring and can be used in applications for measuring positive, negative, or differential pressure with an accuracy of 2%. Standard applications include monitoring filter status, duct static pressure, room pressure, fan or blower pressure, paint booths, dust collectors, and cabinet purging along with many others.
|
|
|
The series A1 digital differential pressure gage is a patent pending microprocessor based digital pressure gauge for positive, negative, and differential measurement designed to be a direct replacement for mechanical gauges. The Series A1 differential pressure gauges utilize an extremely stable piezoresistive sensing technology to give a standard full scale accuracy of 1%. For applications requiring better accuracy, the A1 is also available with 0.5% accuracy. The A1 pressure gauge also has an optional 4-20 mA output for applications requiring an output signal. The A1 features a bright ½" LED display, which gives the gauge improved readability and precision. The A1 digital differential pressure gauges also feature 5 user selectable engineering units including in. w.c., mm w.c., cm w.c., kPa, and Pa. The Series A1 offers an improved look, and performance compare to mechanical gauges for a similar price.
|
|
One M1 digital pressure gauge can replace three or more mechanical gauges
Unlike Mechanical Gauges:
- Dropping can’t affect accuracy. The housing and boot are compatible with many industrial fluids including Skydrol®
- Overpressure doesn’t affect accuracy
- Repeatable readings
- No temperature or gravity effect
Unlike Other Digital Gauges:
- More resolution
- Shock mounted electronics
- Protected LCD
- Uniform backlight
- Very easy to use, no manuals, no menus, no problem!
Unlike Anything Else:
- 0.2% of reading! Like a deadweight tester!
- Calibration report with data at five temperature
- Replace three or more 0.25% standard gauges
- CE certified and manufactured under a ISO 9001 registered quality system
- Runs on 2 AA alkaline batteries providing up to 30,000 hours of service
- Precision and performance at an affordable price
Pressure is Our Business!
|
|
Battery operated digital reference pressure gauges:
Type TLDMM: Accuracy ±0.05% f.s.
Type TLDMM-A01: Accuracy ±0.1% f.s.
Type TLDMM-A02: Accuracy ±0.2% f.s.
Type LDM 70-E25: Accuracy ±0.25% f.s.
Type LDM 70-K50: Accuracy ±0.5% f.s.
A lot of different pressure ranges between 0/100 mbar and 0/2000 bar available.
The pressure unit is switchable to psi, MPa, and other units.
Robust contruction, wetted parts in stainless steel.
Precise measurement of pressure and pressure peaks.
Optional with RS232-interface (TLDMM-types)
Optional in build-in case for panel mounting (TLDMM-types).
Pressure port: 1/2" BSP male, stainless steel
|
|
The HPM110 digital pressure gauge is designed for continuous monitoring of oil, gas, water, hydraulic and other pressure media in mobile equipment, industrial hydraulics, compressors and process control equipment.
The HPM110 offers an economical solution to monitoring pressure and peak pressure with a simple visual display. The hand-held unit can be installed when required using a standard test point, or left permanently connected in a system. Since the HPM110 is battery powered it requires no external wiring.
The HPM110 simultaneously displays actual pressure, peak pressure, battery level and the engineering units selected. The back light can be switched on at the press of a button. Using the
buttons on the front panel the user can clear the peak value, display min, max and actual pressure, reset the zero point and change the engineering units. The unit is available in four models, please see reverse for details.
|
|
|
|
|
|
XP2i-DP Wet Wet Differential
XP2i-DP Features:
- High accuracy, long term vacuum measurement
- 0.1% of reading wet/wet differential transducer
- 15 and 100 PSI versions rated to 100 PSI static pressures
- Transform your XP2i-DP into an indicator for Torque, Force, Level, or any other unit using the Custom Units Wizard using the free ConFigXP software
- Add special features such as Pressure Safety Valve (PSV) mode to capture valve open/close pressure
- Customizable for panel mounting or portable configurations
- ATEX / IECEx / CSA intrinsically safe
- Optional datalogging capability
- LCD backlit display
- Easy to use buttons
Applications
- Gas filter testing
- Level measurement
- Rotary gas meter testing
- Autoclave vacuum monitor / calibration
Included with every new XP2i-DP Differential Digital Pressure Gauge is an A2LA accredited calibration certificate with test data recorded at 5 different temperatures - proving that it meets published specifications over the entire operating range. You won't get this kind of detailed report anywhere else!
|
|
|
|
|
|
The Best Digital Gauge on the Market, Just Got Better!
The 2nd generation XP2i is a very rugged, intrinsically safe, digital pressure gauge that fits in your palm with 0.1% of reading accuracy.
Unlike Other Digital Gauges:
- New nickel plated aluminum enclosure is sealed to IP67 (waterproof to 1 meter)
- Backlight is twice as bright, but batteries last just as long
- 10% larger LCD window for a larger viewing angle
- Internal pressure is equalized by a GORE-TEX® filter
- All XP2i gauges are now CSA, IECEx and ATEX certified intrinsically safe
- Captures open and reseat values for Pressure Safety Valve (PSV) testing
- Optional pressure datalogging capability
- Torque and force measurement capable
- Simple to use
Unlike Mechanical Gauges:
- Dropping can’t affect accuracy
- Overpressure doesn’t affect accuracy
- Repeatable readings
- No hysteresis
- No temperature or gravity effect.
Unlike Anything Else:
- 0.1% of reading! Like a deadweight tester!
- Calibration report with data at five temperature
- Replace three or more 0.25% standard gauges
- Pressure recording by DataLoggerXP to record pressure and ConFigXP to enable or disable features
- Customize your XP2i for panel mounted configurations or portable applications
- any XP2i can be cleaned for oxygen service
- CE certified and manufactured under a ISO 9001 registered quality system
- Runs on 3 AA alkaline batteries providing up to 1,500 hours of service
Pressure is Our Business!
|
|
The WT is a Wally box replacement!
The WT version of the XP2i is designed to replicate the dimensions and pressure connections of the most common test gauges mounted in portable cases. It is a drop in replacement for the Wally box.
0.1% of reading accuracy
Batteries and digital communications are accessible from the front
Rugged "Wally Box" gauge can stand dropping
Optional Pressure datalogging capability
Fast delivery
Comes in 6" and 8.5" options
|
|
Applications:
- Increased safety requirements
- With liquid-filled case for applications with high dynamic pressure pulsations or vibrations
- For gaseous and liquid aggressive media that are not highly viscous or crystallising, also in aggressive
- ambience
- Process industries: chemical/petrochemical, power stations, mining, on- and offshore, environmental technology, machine building and plant construction
Special Features:
- Safety pressure gauge with solid baffle wall designed in compliance with operational safety requirements of EN 837-1, BS 1780 and ASME B 40.1
- Excellent load-cycle stability and shock resistance
- All stainless steel construction
- Scale ranges up to 0 ... 1600 bar
- with Alarm Contacts
|
|
|
|
|
|
Badotherm’s range of pressure instruments includes both mechanical and electronic measuring instruments. Our electronic pressure sensors cover ranges from 20 mbar up to 2200 bar and our mechanical pressure gauges cover ranges from 2.5 mbar at the lowest pressure to 4000 bar at the maximum. Case diameters are available from 40 mm to 250 mm. Accuracies between 2.5% and 0.1% can be provided. These all meet stringent EN standards. The internals of our pressure instrument range are available in brass or stainless steel. Badotherm pressure instruments offer one of the most comprehensive product ranges available in our industry.
Badotherm “Safety baffle wall” pressure gauges represent the safest gauge in our industry and can be found at the higher end of our product range. These gauges are manufactured completely in stainless steel or in stainless steel with a plastic compound casing. In addition, this product is available in both dry, glycerine fillable or filled executions as standard. This filling option is available for our complete range. Most of our instruments are compatible with mechanical or electrical accessories, like drag pointers and contact devices, and can be combined with a variety of chemical seals.
|
|
|
The Series S9000 Differential Pressure BoxGauge™ is designed for easy surface mounting. The BoxGauge™ will mount to any wall or vertical flat surface without any additional kits, special mounting brackets, or optional hardware. The box shape also allows the gauge to sit on any flat horizontal surface making it an ideal choice for portable differential pressure measurement. The large 3” gauge face is easy to read and gives an overall accuracy of 5%. Pressure connections can be made either on the top or back of the gauge with 3/16” flexible tubing.
|
|
Ranges : 0...1/0...600 bar and vacuum
Industrial service, Liquid filled
For Process Industry
For oil industry, NACE std.
For Food and Sanitary Industries
Laboratory and Test
With Electric contact and micro-switches
|
|
Pressure Gauges
2" and 2.5" diameter
Brass or Stainless Steel construction
Pressure ranges from subatmospheric to 10,000 PSIG
1/4" NPT connections
|
|
with single diaphragm, DS150, static pressure max 100 bar
with bellow, DS100-150, max static pressure 25 bar
with double diaphragm, DS100-150, max static pressure 200 bar
with double diaphragm, DS100-150, max static pressure 100 bar
with double diaphragm, DS100-150, max static pressure 400 bar
with double Bourdon tube, DS100
|
|
|
With more than one million BARTON DPU-based instruments in service around the world today, Cameron's Measurement Systems division is a premier supplier of reliable and accurate chart recorders, indicators, switches and pneumatic controllers. Originally developed in the early 1920s, our differential pressure technology features a welded bellows assembly that increases accuracy while dramatically reducing the effects of wear. To facilitate quick and easy repairs all DPU based instruments are supported with pre-calibrated exchange or repaired sub-module bellows assemblies.
|
|
|
|
