Configurable controllers with remote setpoint, isolated analog outputs, control algorithms for motor-driven valves, ...
|
|
SIPART DR 19 - in 96x96mm format for industrial applications such as mechanical and systems engineering
directer sensor connection
integrated control program
continious or step controller (K/S) (0/4 until 20mA / relays)
SIPART DR 21 - in 72x144mm format are ideal solutions for all standard tasks
excellent trend display with analog bar for process value and setpoint
continious or step controller (K/S) (0/4 until 20mA / relays)
SIPART DR 22 - in 72x144mm format is intended for complex closed-loop control systems
2 independant control-loops
input area is freely configurable, extensive function library
up to 11 analog inputs or 9 analog outputs
SIPART DR 24 - is a multitanlented unit for all processspecific tasks in 72x144mm format
up to 4 independant control-loops
library with basic and complex functions
up to 11 analog inputs or 9 analog output
|
|
A new type of multi-function controller
Compact Controller M is a multi-loop controller of a new era where functions of 4 controllers are compactly built in a single unit.
Adopting 16 colours liquid crystal display, it indicates abundant information in an easily visible way from multi-loop bar graph display screen to trend screen and menu screen.
Oriented to user friendly operation, the multi-loop controller with innovative operability and functionality allows to build economical and flexible system equivalent to high cost alternative ones.
|
|
|
|
|
|
Smart PID Controller MS-5300
Universal control output
and RS-485 Modbus communications
1/8 DIN (48 x 96 mm)
The MS-5300 Series is a high range process controller, fully configurable, provided with a response time of 500 ms suitable for fast process control, and universal control algorithms Step-by-Step, Heat-Cool, Analog and Time proportional control or digital control through DCS system. Designed for controlling fast response processes in industrial applications requiring high performance devices.
Fully configurable by keypad or from PC using LOOP WIN software programming tool
Universal analóg input 8 TC, RTD, mV or mA
High accuracy 0,1%
Bimodal PID control, Autotuning and Fuzzy-Logic
500 ms response time
Time proportional relay control output
Step-by-Step, Heat-Cool and Bimodal control
Analog control output 0...4-20 mA (optional)
3 relay outputs and 6 alarm modes
Direct Auto-Manu station from keypad
Transmitter power supply 24 Vdc standard
RS-485 modbus communication standard
Compatible with DCS-8000 system
|
|
|
DIN-rail mount process controllers one to four channels with RTD, 0/4-20mA or 0-1/10V inputs.
|
|
|
Configurable controllers with remote setpoint, isolated analog outputs, control algorithms for motor-driven valves, ...
|
|
DIN 48 x 24 or 96 x 48 mm
5 digits
Very bright LED display, up to 14,2 mm high
Inputs: 0..20 mA, 4..20 mA,
0..10 V, 2..10 V, thermo couples,
thermo resistance (e.g. Pt 100 or Pt 1000)
Freely programmable operating curve
With or without limit values
- Easy programming
- Big keys for use with gloves
- Programmable characteristic curve end points (up to 24 control points)
- MIN/MAX value detection,
- Display-Hold
- Auxiliary power output for measuring transducer/sensor
- Optocoupler or relay outputs
- Totalizer and Programmable limit values
- Optional: with serial interface
|
|
Series 1/16 DIN Universal Process Controller
• Thermocouple, RTD, Voltageor Current Input
• User-Selectable Ramp to Setpoint
• Bumpless Auto/Manual Transfer
• NEMA 4X (IP65) Dust and
Splash-Proof Front Panel
• On/Off through Full PID Operation (P,PI,PD,PID)
|
|
These models accepts single analog input from the sensor, transducer or transmitter and provides 2 to 6 outputs in the form of logic pulses or relay contacts. The process value is accurately displayed and up to 6 set points are provided and using front panel keyboard each is user programmable and configurable for High Alarm, Low Alarm, Deviation Alarm. They find application in heater bank selection, star delta change over, water level control, pressure control etc..
APPLICATIONS
For controlling multiple heaters or other actuators at different set points by monitoring single input, for control and alarm of temperature, level, pressure, flow etc...
|
|
|
Built around a powerful 32-bit microprocessor, the PX100 Multi-Parameter Touch - Screen Controller provides all the features required of a multi-channel, multi - configuration instrument such as graphic display of measurements, datalogging over several weeks, menu-driven calibration functions and RS232 / RS485 communication. A touch-screen human interface considerably simplifies parameter setting and instrument calibrating or testing, in any of the available languages.
|
|
Major Features of these Process Controllers:
Universal input (mA, mV, V, RTD or Thermocouple)
Isolated analog outputs for process controllers (4-20mA or 0-20mA)
Alarm trip outputs (control, high/low, deviation and rate of change)
PowerTune delivers pretuning, adaptive tuning and powerback anti-overshoot
Quick setup of process controllers with plain-English menu prompts and large back-lit keys
NEMA 4X front panel with extra-bright 2-line, 5-digit PV display
RS-485 digital communications
|
|
The real-time process database is entirely distributed to the controllers. These are functionally complete and able to perform logic control, regulatory control and advanced calculations. This ensures that all processing and control can be performed on the spot, that is, data does not have to be sent elsewhere for processing and return of the result.
Consequently, the control system can be structured according to the process requirements without restrictions imposed by limitations in the control system. The result is a "clean" structure with a high degree of integrity.
|
|
|
|
|
|
Eaton's Fusion Integrated Machine Controller has advanced features, including a five-preset high speed counter with prewarn, a totalizer with preset, a batch counter with preset and a ratemeter (tachometer) with high and low setpoints. Unique to the count control world, the Fusion has five output relays, along with two transistors and two analog setpoint or follower outputs. Its ten available parameter sets of pre-loaded values are useful as recipes, for job-stacking or for a variety of application-specific purposes.
The Fusion has a multi-line alphanumeric display which can be programmed to show text messages, logic-generated prompts, alarms and machine status. Up to eight screens can be shown or optionally locked out.
With its ladder logic, the Fusion is actually a 26 I/O controller, making it a complete control for many machines and processes, integrating the functions of external timers, pushbuttons, power supplies, indicating lights, control relays and other components in a single box.
|
|
DRC 1210
The control generation DRC 1210
With the new DRC 1210 DESMA is providing an exceptionally effective control system which safely controls very complex machines and processes, but which remains simple to use. From closed-loop control of the clamping unit movements and of the complete injection process, passing on to comprehensive intermediate stop functions of core lifter movements, a modem for telediagnosis and data storage on hard disk or disk drive are equally standard!
Performance features
* Efficient PC-control with 6,5" colour display
* Exceptional equipment in this control category
* Clear and easy to understand user prompt
* Dynamic auto-optimization of temperature controllers
* Real-time operating system, multitasking, telediagnosis via modem
* optionally cure time optimization (DESCURE), DESMA-SPC, networking with TIG system
|
|
|
The Honeywell HC900 Hybrid Controller is an advanced loop and logic controller offering a modular design to satisfy the control and data acquisition needs of a wide range of process equipment. When combined with the optional, performance rich 1042 Operator Interface that fully integrates the controller database, configuration and set - up time is minimized. This powerful combination together with Honeywell's performance proven control technology provides users an ideal solution for process control. Open Ethernet connectivity also allows network access using a variety of HMI/SCADA software.
|
|
The HC900 controller provides a cost-effective platform for combining loop and logic control. The HC900 is ideal for unit process applications that require a combination of analog process control functions and discrete control actions. When networked with the Experion system for supervisory control, the HC900 controller provides an ideal unit controller for standalone processes, skid-mounted systems and other periphery operations in a process facility.
The HC900 controller offers a blend of analog process, logic and sequencing control algorithms. There are no preset limits on the number of times a function block type may be instantiated in a controller (limit based on memory availability and required scan rate). Features include:
- 1,920 I/O points
- Compact 4, 8 or 12 I/O slot rack sizes
- Open Ethernet network connectivity
- Peer-to-peer data exchange
- Automated loop tuning
- Setpoint programmers
- Setpoint schedulers with multiple ramp/soak outputs andultiple 64-step sequencers
|
|
