HEAVY DUTY BASE MACHINE FOR FOUNDATION WORK
Max. Lifting Capacity: 80 tons x 3.6 m
Max. Boom Length: 54.9 m
Heavy-duty reliability from wet-type disc brakes. Powerful and large capacity drums to handle any job with power to spare. Drawing on long experience in crane manufacture, KOBELCO researched the bottom line in boosting operating efficiency in civil engineering and foundations work, and has unveiled a new generation of base machines.The BME800HD features power and precision in operations, simple controls and comprehensive safety features. Economic to run, easy to transport, kind to operator and environment alike. In every respect the BME800HD delivers a performance that sets new standards for heavy-duty foundation work. |
|
CRANE BOOM
Max. Lifting Capacity: 60 tons @ 3.0 m
Max. Boom Length: 51.8 m
FIXED JIB
Max. Lifting Capacity: 6.6 tons @ 16.0 m
Max. Fixed Jib Combinations: 42.7 m x 12.2 m
39.6 m x 18.3 m
The CKE600 crawler crane from KOBELCO takes advantage of new technologies to raise performance to new heights. Winches with extremely powerful line-pull handle the toughest jobs, while the innovative "wettype" multi-disc braking system provides safe and sure control with minimal maintenance. A large winch capacity promotes ultra-smooth operation and enhanced component service life. An optional full-sized third winch enables the use of an impressive selection of attachments. Add these new features to the renowned power and reliability of KOBELCO cranes, and you have the ideal combination of lifting performance, economical operation and durability. |
|
CRANE BOOM
Max. Lifting Capacity: 135 tons @ 4.5 m
LUFFING BOOM
Max. Lifting Capacity: 80 tons @ 8.0 m
LONG BOOM
Max. Lifting Capacity: 44.3 tons @ 10.6 m
FIXED JIB
Max. Lifting Capacity: 26.8 tons @ 16.0 m
LUFFING JIB
Max. Lifting Capacity: 36 tons @ 12.0 m
Whether positioning bridge girders or constructing tall buildings, smooth and speedy operation is the most important performance. KOBELCO CKE1350 crawler crane is designed with latest job trends in construction environment. With its excellent operability, sensitive controls, and most important, its safety features, the CKE1350 achieves the best balance in its
overall performance. In regular crane or luffing jib operations for building construction, as well as general foundation work, there's more than enough capacity. The difference is in its basic performance. |
|
SL 6000
Max. Lifting Capacity: 550 ton
STANDARD
Max. Boom Length: 108 m
Max. Luffing Jib Combination: 60 + 72 m
HEAVY LIFT
Max. Boom Length: 108 m
Max. Luffing Jib Combination: 66 72 m
SUPER HEAVY LIFT
Max. Boom Length: 126 m
Max. Luffing Jib Combination: 84 84 m
The KOBELCO SL6000 crawler crane, with a lifting capacity of up to 550 tons, targets large-scale energy-related projects and large infrastructure installations. In addition to its superb lifting capacity, the SL6000's innovative unit assembly system' is designed to comply with transport regulations worldwide and to minimize labor required for assembly/disassembly. The SL6000's wide range of attractive features includes advanced safety devices, a wide, comfortable cab giving excellent visibility and other enhancements. KOBELCO is proud to premiere this much-awaited new model, which will further enhance our global reputation for tough, reliable, and outstanding performance. |
|
Raw power and durability alone are no longer enough in today's fs construction environment, as operators and owners increasingly demand greater comfort and operability. KOBELCO has evolved accordingly with advanced hydraulic technology and onboard electronics that help you get the job done more quickly and reliably than ever before. But the real focus of our machine design is safety, both for the operator and for all the workers on the site. With their ideal combination of power, speed, comfort, operability, and advanced safety features, KOBELCO cranes are being used with confidence throughout the world. And now, we are proud to present them to the European market as the CKE Series.
CKE2500
Max. Lifting Capacity : 250t @ 4.6m
Max. Crane Boom Length: 91.4m
Max. Fixed Jib Combination: 76.2m + 30.5m
Max. Luffing Jib Combination: 61m 61m |
|
| Designed specifically for applications requiring particular manoeuvrability and compactness. LTC stands for "Liebherr-Telescopic-Compact", indicating the special compactness of the new crane design. A hydrostatic travel drive, the tightest of turning radii, active rear axle steering and shunting mode and the 7-section, 36 m compact boom distinguish the 55 tonner as the ideal lifting gear for crane assembly within restricted industrial buildings. |
|
Equipped with REXROTH and Kawasaki hydraulics components imported from Germany and Japan;
Excellent micro-mobility performance;
Independent main and auxiliary winches, convenient for operation;
Multi-disk clutch and brakes are self-compensated, free of adjustment, automatic compensation;
Travel with heavy load feature, and free-fall hook increase operation's efficiency and working coverage;
Built-in features as torque limiter, electronic controller and over-winding prevention device enhance operation safety;
Larger chassis is used for better stability;
Light weight and small specific ground pressure;
Adjustable track width for transportation convenience;
High-strength steel pipe boom for high load capacity. |
|
| With the LR series, Liebherr offers a well-balanced programme of lattice boom crawler cranes. In the class below-300 metric tons, low transport weights, rapid self-assembly, optimum load capacity values across the entire working range and comprehensive operating information are among these cranes' main functional features. |
|
| Liebherr builds a wide range of mobile cranes with telescoping or lattice booms on wheeled or crawler-tracked undercarriages, to operate in the most diverse areas. These cranes are powerful, compact and manoeuvrable, and feature ultra-modern "made in Germany" mobile-crane technology that satisfies combined road and off-road operating requirements on construction sites of all kinds, worldwide. |
|
| Liebherr builds a wide range of mobile cranes with telescoping or lattice booms on wheeled or crawler-tracked undercarriages, to operate in the most diverse areas. These cranes are powerful, compact and manoeuvrable, and feature ultra-modern "made in Germany" mobile-crane technology that satisfies combined road and off-road operating requirements on construction sites of all kinds, worldwide. |
|
The Favelle Favco crawler crane range is jointly developed with Caterpillar Industrial Products Inc and are a combination of Favelle Favco lifting technology and Caterpillar technology. The model lineup is divided into lattice boom and telescopic boom. The crane sizes range from 30 ton to 60 ton with a telescopic boom and 60 ton with a lattice boom. The innovative telescopic crawlers are ideal for remote jobs which require quick mobilization as they are able to get to work immediately off a truck without the aid of another crane. Their versatility is even more pronounced as it is able to "pick and carry"on rough terrain.
Applications:
- General Construction Worksites
- Pipe Laying Work
From:
MAX LOAD 27.5t
MIN BOOM LENGTH MAX 8.5m
BOOM LENGTH 27.9m
TIP LOAD 0.3t at 27.9m
To:
MAX LOAD 55t
MIN BOOM LENGTH MAX 10m
BOOM LENGTH 32.3m
TIP LOAD 1.8t at 29m |
|
The Favelle Favco crawler crane range is jointly developed with Caterpillar Industrial Products Inc and are a combination of Favelle Favco lifting technology and Caterpillar technology. The model lineup is divided into lattice boom and telescopic boom. The crane sizes range from 30 ton to 60 ton with a telescopic boom and 60 ton with a lattice boom. The innovative telescopic crawlers are ideal for remote jobs which require quick mobilization as they are able to get to work immediately off a truck without the aid of another crane. Their versatility is even more pronounced as it is able to "pick and carry"on rough terrain.
Applications:
- General Construction Worksites
- Pipe Laying Work
50PL
MAX LOAD 49t
MIN BOOM LENGTH MAX 15m
BOOM LENGTH 42m
TIP LOAD 0.8t at 42.7m
60L
MAX LOAD 55.1t
MIN BOOM LENGTH MAX 15m
BOOM LENGTH 54m
TIP LOAD 0.6t at 53.4m |
|
