SALICRU's EQUINOX LV series photovoltaic inverters are low voltage Pulse Pass technology unique within
market, giving several advantages which hi-Voltage apparatus cannot forward.
Having low Voltage power supply, fine surface modules connection may be parallel massive one, without
series connections, furnishing lots of advantages set-up plus energy production wise, decreasing at the same time
pay-back. Furthermore, DC low Voltage run diminishes electric shock risk plus more human security, such as
fitters, maintenance personnel, and so on.
Moreover, set-up design sight-simplified, lowering weight on possible shadow zones, nor being
needful modules specific bearing nor leaning. This great pliancy allows better efficiency within final generation
result.
APPLIANCES: Fine surface module suitable
Series connected panel series damage fine surface total useful life period. But, parallel massive connection
ensures optimum running all set-up life estimate.
Anticipating photovoltaic market evolution towards fine surface panels, SALICRU has developed an inverter range
which adapts to fine surface panel new needs.
Maximum worry in photovoltaic solar set-up design is to accomplish maximum solar radiation profit.
Due to fine surface panel technology we can worry-less about most unfavourable requirements in ref. to
tradicional systems, such as: due South bearing, localization link bending, shadowless zones or
series module failure.
|
|
|
|
|
|
SALICRU's EQUINOX series being solar inverters without transformer feature being light, dimension reduced and with high
reliability. Due to its novel technology, backep by SALICRU's wide experience within power electronics world,
they offer low power set-up high performance, as well as a wide range communication capacity.
Moreover, set-up and use maximum ease for a greater working out comfort.
Full range covers 2,8, 4,6 and 10 kW power, connected to single-phase or 3-phase net either for indoor or outdoor set-up. All
have LCD/graph screen to ease set-up data look on, as well as local or remote communication feasability.
APPPLIANCES:
SALICRU's EQUINOX series inverters indoor and outdoor fitting-wise, ranging from little
power to great ones via parallel inverters, achieving configurations which target a greater level of
realiability due to modular outlook.
Moreover, maximum flexibility offered being single-phase of 3-phase connect inverters.
Plus multistring topology set-up connect suitable, allowing photovoltaic field Design & Planning maximum fitting.
|
|
Inverters
Today's inverters are very efficient and reliable.
Some PV systems are designed to run DC loads exclusively and so not need an inverter, however an inverter is necessary in any PV system in which you want to run AC applications and tools, or if you are intending to interface your PV system with the Utility.
Most grid-tie inverters are simple machines that are dedicated to converting the DC current from a solar array into AC current and feeding it into the utility grid.
|
|
Power Supply System
"LINE BACK Ω" Utility-Connected Photovoltaic Inverter
"REQSTAR Series" AC Uninterruptible Power Supply
"BM3000-5FNJ/REIN" AC Uninterruptible Power Supply
"Acrostar RHA1250" AC Uninterruptible Power Supply
"TRUSTAR Series" DC Power Supply
|
|
Three-phase FSI inverters
FSI-25/FSI-100
GENERAL CHARACTERISTICS:
It will have the following parameters:
* A three-phase inverter module (400V AC, 3F).
* Connection system and protections from the inverter to the photovoltaic field.
* A system for connection/disconnection to/from grid.
* A monitoring, control and protection system.
* A galvanic isolation transformer connected to the inverter output.
* Maximum power point tracking (MPPT).
* Energy efficiency of up to 96%.
* Anti-islanding watch with automatic disconnection from grid.
* Harmonic distortion less than 3%.
* Necessary protections according to RD, temperature, voltage, current, etc.
* Easy parameter setting, installation and operation.
* CE seal. EMC and low voltage standards.
* RS485 communication.
|
|
|
|
|
|
An effective and environmentally friendly way to generate electrical energy is to use a unique inexhaustible source like the sun: a shining example of efficient power generation without harming the environment.
Thanks to modern technology, we can optimise the output taken from this energy. Mastervolt supply a broad range of solar inverters as a vital part of solar power systems, equally at home or for autonomous applications.
Sunmaster IP44 series
The new Sunmaster IP44 series: the new generation of compact, easy to install, high performance grid connected inverters for installation in most protected outdoor areas.
Sunmaster QS1200 / QS2000 / QS3200 & QS3200 Max-I / QS6400 & QS6400 Max-I
The Sunmaster QS is the dynamic heart of any grid-connected photovoltaic (PV) system, taking care of an accurate power conversion from solar panel to local grid. This effective conversion process takes place with minimal power loss and maximum reliability.
Sunmaster XL
The most recent development from Mastervolt is a new high power solar inverter with a power rating of 10 and 15 kW AC. The new Sunmaster XL models are delivered in a waterproof IP55 enclosure which can be installed in either a grid connected solar tracker system or a stationary PV system.
Soladin 600
The Soladin 600 models are world's smallest mini string inverters and are usable for every type of solar panel. Contact Mastervolt for use in other than mentioned countries.
|
|
Inverter to modified sinusoidal wave
Inverters for systems to island with built-in regolator of charge
Inverter GRID CONNECTED (for logon to the net)
Accessories for assembly given from inverter SUNNYBOY
|
|
|
|
|
|
General description
The PVI-CENTRAL-50 is a complete turnkey solution for connection to low-voltage public utilities. Using integrated light sensors, it offers nighttime disconnection of the transformer to eliminate undesired losses. A string combiner box is optionally available to parallel, protect and monitor all of the photovoltaic strings and to enhance the monitoring and diagnostic capabilities of the system.
Maximize power harvest
- High conversion efficiency (CEC efficiency 95%) for maximum power harvest
- Wide operating voltage range of 300-600 Vdc increases energy collected
- Self-tuning MPPT power curve optimizes energy harvest
Low installation and maintenance costs
- Module design offers unobstructed front access to modules and power boards for quick inverter installs and simplified maintenance
- Residential area installation without the need for noise reduction: <54dB acoustic noise, non-audible 18 kHz switching frequency
Flexible configuration
- String combiner box option assures array protection and monitoring
- Optional module grounding of (+) leg for application flexibility
Extended performance
- A broad range of communications options: dial up, ISDN, Ethernet, DSL, GSM, and the optional FlyBy Easy Communication System hardware/software, for instant access to system status
- Digital Signal Processor (DSP) based controls for self diagnostics and LCD real-time display of operating status
- Five-year warranty extendable to 20 years
|
|
|
|
|
|
General description
Aurora has been designed with large de-rating criteria on all critical components, achieving an extremely robust and reliable inverter designed to last for 25 years and to deliver true maximum output
power on a continuous basis. With this design concept we achieve peak efficiencies of over 97% .
Benefits
- Dual input section to process two strings with independent MPPT (6000W max models)
- IP65 (NEMA 4) ruggedized, completely sealed unit to stand the harshest environmental conditions
- High speed MPPT for real time power tracking and improved energy harvesting
- Compact size and high power density: 6000W (6000W max) of output power in a box just 981,5mm x 325mm x 195mm
- Front heatsink keeps the unit cleaner and more efficient over time
- Transformerless operation for highest efficiency: up to 97% (96,5% C.E.C)
- DC disconnect switch (2 x 25A/600Vdc) meet
- NEC Standard, Article 690 "Solar Photovoltaic System"
- Reverse polarity protection minimizes chance of damage due to mis-wiring
- High overload capability: works up to 6000W under most ambient conditions
- True Sine Wave Output
- Anti-islanding Protection
- Certified grid connected operation according to UL1741 & CSA-C22.2 N.107.1-01
- LCD Display on the front to monitor the main parameters
- Integrated RS-485 serial communication
|
|
|
|
|
|
General description
These commercial-grade inverters feature scalability in a common-enclosure package that is delivered pre-configured and pre-tested. In addition to reducing on-site installation wiring and testing, this industry-leading technology provides cost-effective solutions with smaller footprints and increased reliability.
Applications flexibility is further enhanced by the availability of models with and without isolation transformers that are self contained within the inverter rack.
The development of the PVI-200/200-TL was in response to the rapidly growing global demand for environmentally friendly power sources. Magnetek's inverters deliver a unique combination of efficiency, flexibility and redundancy to the renewable energy market, demonstrating our ongoing commitment to world-class energy solutions.
Maximize power harvest
- High conversion efficiency (CEC efficiency 96%) for maximum power harvest
- Wide operating voltage range of 330-600 Vdc increases energy collected
- Self-tuning MPPT power curve optimizes energy harvest
- Multiple input MPPT through modular design for array efficiency
Flexible configuration
- Independent modules are configurable in multi-master mode or master-slave mode, providing power redundancy
- Optional module grounding of (+) leg for application flexibility
Low installation and maintenance costs
- Module design offers unobstructed front access to modules and power boards for quick inverter installs and simplified maintenance
- Reduced wiring for ease of installation
- Hot-swappable module replacement simplifies maintenance
|
|
| ... products without technical information |
| |
Solar inverter in network REFUSOL
The most powerful inverter of the world! The excellent yield to partial load and the injection in three phases facilitate the planning of each solar installation.
This German product of quality is the result of more than 40 years of experience in the electronics of power. Double winner of the test of product in the magazine "Photon".
Fast algorithm MPP and precis reach a degree of effectiveness of 99.9%. Also excel output at the time of bad weather, thanks to a licensed topology. That allows a saving in several hundred francs per year.
It is possible for the first time to produce an inverter higher than 10kW having a cooling system only based on the convection. The impermeable and solid case (IP65) even makes it possible to install the REFUSOL outside.
Thanks to its low fuel consumption in resources (gray energy), the inverter spares the environment and is assembled easily.
|
|
PV inverter choke
Application :
PV inverter from 2kW up to 30kW
Gamme :
Current range from 5A up to 50A
|
|
|
|
