APEM, the widest range of toggle switches
- Miniature and industrial switches, for high or low current ratings
- For panel or PCB
- Numerous maintained or momentary electrical functions
- Large variety of threaded or plain bushing, from 6 to 11.9 mm diameter
- Numerous lever types: cylindrical, flatted, locking, with fluorescent tip
- 12 terminal types: solder, screw, quick-connect, straight or right angle PC terminals
- Numerous options: frontal sealing, epoxy sealed terminals, matt black finish…
- Numerous accessories: caps, paddles, sealing boots
- Custom models
APEM, the broadest offering in the switch market: miniature switches, industrial switches, LED indicators, professional switch panels and professional joysticks.
|
|
* 10 different actuator and display components
* Two collar types
- round
- square
* Mounting hole diameter 22.3 mm
* Degree of protection: IP 65 in front of the switch panel
* Contact blocks with gold contacts, 1...42 V / 0.01 ... 100 mA
* Contact blocks with silver contacts, max. 400 V / 10 A
* Lamp socket BA9s
* Four connection types
- screw connection
- cage clamp
- quick-connect terminal
- RJ 12 connector
* AS-I contact blocks, also for EMERGENCY-STOP, safety at work
|
|
• Ratings up to 20A, 277V ac
• Metal & nylon lever versions
• Single and double pole
• Choice of circuits include 3 position and momentary
• Wide choice of terminals
• Range of accessories available include boots and lever guard
• RoHS compliant
|
|
Honeywell MICRO SWITCH™ Toggle Switch
Full-Scale Offering. Clean Slate Engineering. Optimal operator interface for controlling machine function to construction and agriculture equipment OEMs, in addition to aerospace, air transport, armored fighting vehicles. Our toggle switches withstand wet, dust, dirty environments and are designed for use in harsh environments. With many configurations available, our Honeywell can help you with quick customization.
-IP rating for commercial use
-Hermetic bonded sealing
-In-house machining and stamping capabilities
-Configurable components
|
|
|
|
|
|
Industrial Purpose Toggle Switches - AC/DC Rated
The Industrial Toggle Switch Line employs a Quick-make/Quick-break wiping action contact mechanism. Large, well separated terminals reduce the possibility of electrical creepage and insure separation of loose wire strands from adjacent leads. These switches are designed for heavy duty applications, such as industrial power tools and floor cleaning/polishing equipment.
Circuits: 1PST, 2PST, 2PDT. Maintained contact action.
Contact Mechanism: Quick-make/Quick-break wiping action.
Contact Material:
Movable - Copper silver plated.
Stationary - Bronze silver plated.
Terminal Types:
Screw Terminals - 7320 & 7321 Series: Brass designed to accept #5-40 x 1/4² (Cat. No. 811-14) binding head screws.
Furnished unassembled.
7360 & 7361 Series: Brass designed to accept #6-32 x 1/4² (Cat. No. 811-161) binding head screws.
Furnished unassembled.
8690 Series: Brass designed to accept #6-32 x 1/4² (Cat No. 811-7248) binding head screws.
Furnished unassembled.
|
|
Features/Benefits:
- Multi-pole and multi-position
- Wide variety of actuator and termination options
- Epoxy terminal-seal compatible with bottom wash cleaning
- RoHS complaint models available
|
|
A (submini)
Washable Subminiature Toggle Switches
B (sub-mini)
Process Sealed Washable Subminiature Toggle Switches
G (ultra-mini)
Washable Through-Hole Mount Toggle Switches
G3T (ultra-mini)
Washable Surface Mount Toggle Switches
M (miniature)
Miniature Toggle Switches
M2100 (miniature)
Toggle, Rocker and Paddle Switches
M2T (miniature)
Washable Toggle Switches
P (standard)
Internationally Approved Toggle Switches
S AC/DC (std/hi cap)
High Capacity Toggles S High Cap (standard)
High Capacity Toggles
S Low Cap (standard)
Low Capacity Toggles S Med Cap (standard)
Medium Capacity Toggles
S Med/Hi (standard)
Med/Hi Capacity Toggles
WT (standard)
WT Toggle Switches
|
|
|
|
|
|
Features:
* Withstands direct water spray.
* Submersible. Designed to meet IP68.
* Fits industry standard panel openings for drop-in replacement of panel sealed and unsealed switches.
* Snap-in feature accommodates a wide range of panel cutouts.
* Switches up to 16 Amps.
* UV and Solvent resistant.
* Withstands extreme shock & vibration.
* Legends and illuminated function indicators available.
* 2- & 3-position, momentary, maintained action and center-off.
The K4 series snap-in toggle switches are rugged, high performance sealed switches designed for use under severe conditions found in marine, appliance, heavy equipment and industrial control applications. They are totally sealed so the switch can withstand direct water spray and submersion, even during operation. They are designed to meet the international submersion specification level IP68. An optional panel seal is also available.
The K4 series is offered in single and double pole configurations. Toggle action includes 2 and 3 position, momentary and maintained operation in a combination of 13 variations.
Mounting is simple and quick; snaps into panel from the front. The OTTO snap-in design supports a variety of panel thicknesses with just one cut-out size specified.
Existing unsealed applications are easily upgraded to sealed functionality because the K series drops into existing panel cut-outs.
A choice of models are offered to handle current from 16 amperes to low level electronic switching levels.
|
|
AJ4
The AJ4 Toggle Switch Series provides a safety design with a contact gap greater than 3mm and high contact efficiency for a high inrush resistance.
|
|
General description :
Base of heat resistant resin meets UL94V-0 flammability rating.
Maximized voltage capability of 48V allows use in medium source applications and increases operating life.
Award-winning STC contact mechanism with benefits unavailable in conventional mechanisms: smoother positive detent actuation, increased contact stability, and unparalleled reliability. (Additional STC details under Terms and Acronyms in Supplement section.)
Round 0.8mm diameter PC terminals for easy PCB assembly.
Terminal spacing conforms to standard 2.54mm PC board grid spacing.
Molded-in terminals prevent entry of flux, solvents, and other contaminants.
|
|
