Lanner hybrid digital video recorders are standalone IP based video surveillance platforms that allow simultaneous recording and remote access of live video streams from digital or analog video sources. Lanner hybrid DVR products deliver up to 32-channels of network video with integrated RAID storage and flexible copper or fiber networking options.
http://www.lannerinc.com
|
|
|
|
|
|
16-channel H.264 Full D1 Network Video Recorder with Core 2 Quad CPU and 4 internal storage drives
Features
* H.264/AVC codec
* 16 BNC inputs for video
* 16 G.711 audio inputs
* Supports Intel Core 2 Duo and Core 2 Quad CPUs, LGA775 x 1
* 4 x 3.5" internal HDD bays, 1 slim CD drive bay
* Intel Q35 + ICH9DO chipset
* Intel Rapid Recovery RAID
* Max 4GB DDR2
* 2 RJ45 GbE Network Ports
* 1 PCI-E expansion slot for discrete graphics or 4/16 channel capture card
Form Factor
2U Rackmount
H.264 Video
Compression: H.264/AVC BP codec
Video Input: 16 x BNC inputs CVBS 1.0Vp-p, with 75 ohm loading for video input
Resolution: 16-channel full D1 resolution at 30/25 FPS for NTSC/PAL
NTSC: 30FPS per channel / PAL: 25FPS per channel
Audio Input
16 RCA audio ports
G.711 audio compression
Platform
Supports Intel Core 2 Duo and Core 2 Quad CPUs, LGA775 x 1
Chipset: Intel Q35 + ICH9DO
Storage
HDD Bays 3.5” x 4 internal bays
Slim CD drive bay x 1
HDD Interface SATA II x 6
RAID
Intel Rapid Recovery
System Memory
Dual-channel DDR2 DIMM 800/667 MHz
Max Capacity: 4GB
Socket: 240P DIMM x 2
OS Supported
Microsoft Windows XP
Microsoft Windows 2003
Ubuntu Linux 7.10
CentOS Linux 5
Linux 2.6.18 ~ 2.6.22
Networking
Ethernet Ports RJ45 x 2 GbE (Intel 82573L)
Alarm /PTZ
PTZ Control 1 RS-485 for PTZ
Alarm Interface 8 DI and 8 DO terminal block
Expansion: 1 x PCI-E (x8) for independent graphic card or 4/16-channel video capture card
Power
Type / Watts: 350Watts
Input AC: 90~264V at 47~63Hz
Compliance
CE Emission, FCC Class A, RoHS
http://www.lannerinc.com
|
|
|
|
|
|
16-channel hardware H.264 full D1 NVR with Core 2 Duo/Quad CPU and 4 internal storage drives
Features
* 16-channel analog video input
* H.264 AVC codec
* Socket LGA775 supports Core 2 Duo, Core 2 Quad CPUs
* 4 internal 3.5" SATA II HDD bays
* Slim DVD-RW drive
* 16-channel BNC looping
* Full D1 resolution
* 30FPS NTSC / 25FPS PAL per channel
Form Factor
2U Rackmount
H.264 Video Compression
H.264/AVC codec
Horizonatal Resolution: 720 pixels NTSC / 704 pixels PAL
Vertical Resolution: 480 lines NTSC / 576 lines PAL
NTSC: 30FPS per channel / PAL: 25FPS per channel
Audio
16 channel G.711 audio inputs via RCA connector (optional)
1Vp-p, 10Kohms input, 1 Vrms output
Platform
Supports Intel Core 2 Duo and Core 2 Quad CPUs, LGA775 socket
Intel Q35 + ICH9DO chipset
Storage
Four internal 3.5” SATA II HDD bays
Slim CD drive bay
HDD Interface SATA II x 6
RAID
Intel Rapid Recovery
System Memory
Dual-channel DDR2 DIMM 800/667 MHz
Max Capacity: 4GB
Socket: 240P DIMM x 2
OS Supported
Microsoft Windows XP
Ubuntu Linux 7.10
Fedora 7
Linux 2.6.18 ~ 2.6.25
Networking
Ethernet Ports RJ45 x 2 GbE (Intel 82573L)
Alarm/PTZ
PTZ Control 1 RS-485 for PTZ
Alarm Interface 8 DI and 8 DO terminal block
Compliance
CE Emission, FCC Class A, RoHS
Software
Evaluation Kit: EyeShot 2000 DVR Control Panel (Windows XP)
SDK: Linux and Windows SDK available
http://www.lannerinc.com
|
|
Digital Video Recorders
Honeywell’s DVRs are high-quality and high performing with features designed for easy installation and operation, superior image quality, and maximum storage.
PC-Based
PC-based platforms that integrate seamlessly with Honeywell’s Access Control Systems, Integrated Data Manager and industry-leading alarm central station video verification applications
Embedded
Embedded DVRs are feature-rich, providing increased storage capacity, paramount picture quality and enhanced search capabilities.
|
|
|
|
|
|
Honeywell’s Enterprise NVR (Network Video Recorder) video management system is an industry-leading enterprise class digital video surveillance solution. The Enterprise NVR is built on best-in-class components that provide the flexibility and scalability needed to design a video system suited to a variety of end user applications. Honeywell is a total solution provider offering all the components of a reliable video system such as cameras, encoders, management software, servers, workstations, and video storage units.
The Enterprise NVR Series servers are the backbone of the Enterprise class digital network video recording system. The servers run the Enterprise NVR software and manage digital video—including receiving, storing and retransmitting video when it is requested by an NVR client workstation. Enterprise NVR servers leverage industryleading IT components and are tested to sustain the rigorous demands of a video system.
Features:
* Capable of simultaneous record, playback, live view, archive, or transmission of digital video
* Receives and records a minimum of 32 channels of 4CIF
* Save user-selected video clips as a watermarked and tamper resistant Safe Data Container (SDC)
* Supports multiple layers of imported facility maps with associated cameras
* Utilizes Intel Xeon Dual Core processor technology
* 1 GB of DDR2 400 RAM
* RAID1 mirrored internal 160 GB SATAII hard disks for redundancy
* Dual channel U320 SCSI for external storage connectivity
* Dual Gigabit Ethernet ports for load balancing and maximum data throughput
* Windows® XP Professional Operating System
* Single or redundant power supply option.
|
|
● Feature-Rich
- Simultaneous recording, playback and
back-up
- Built-in motion detection with
search function
- Dynamic IP (TCP/IP, DHCP, FTP,
PPPoE) support
- ATM/POS transaction data recording
and search
- Spot Monitor for single channel
monitoring and playback
- One channel audio recording and
playback
- Easy remote control (IR)
|
|
|
The NSR-1050H is a high capacity hard disk recorder that has a capacity of 500 GB. This network surveillance server is an ideal solution for multi-camera monitoring, recording, and playback.
|
|
Model PVS-2422
Stylish Industrial Grade Desktop DSS Platform
Stylish and compact design
Fantastic cooling design for CPU and add-on card
Remote control support
Dual Gigabit Ethernet ports
Model PVS-1125
Compact Size DSS Platform with Dual-Display function suitable for POS Application
Stylish and compact design to fit mission critical application
VGA, DVI, dual independent display support, enable E-Map and monitor function at the same time
Support SD flash board to enhance system security
Remote control support
|
|
|
Throw the mouse and keyboard, Topvision show you a whole new way to use the DVR with simple, intuition and security. The integrated LCD/DVR combo with TOUCH function lets user has a comfortable experience of using DVR system and release from the many and diverse operations of keyboard and mouse. The reliable housing brings trust and high-end feeling to your desktop and the all-in-one design makes the installation more easily and saving space. Dual and quattuor LCD/DVR combo with touch is also available.
|
|
This powerful, intelligent, all-in-one network surveillance recorder is extremely easy to use for multi-camera monitoring, recording, search and playback. It offers 1000 GB storage capacity, 480 frames per second recording and support for up to 64 audio channels.
Incorporating intelligent video analytics including Video Motion Filter Alarms and Video Motion Filter Searches it provides high levels of operational efficiency and security.
It can be deployed as a stand-alone system or in a small- to large-scale client/server configuration, and uses the reliable Linux operating system.
|
|
Model PVR-4450
4U Industrial Grade Rackmount DSS Platform
Adopts Intel® Matrix Storage Technology to support RAID 0/1/5/10
Support up to six PCI slots and one PCI-E x 16 slot
Support up to five HDD
Dual Gigabit Ethernet ports
Model PVR-2423
2U Industrial Grade Rackmount DSS Platform
Fantastic cooling design for CPU and add-on card
Remote control support
Dual Gigabit Ethernet ports
Model PVR-1140
1U Industrial Grade Rackmount DSS Platform with Dual Core Performance
Support Core Duo/Core Solo processor
Support PCI-E x 16 slot for Graphic card, PCI-E x 4 slot for RAID card and PCI slot for capture card
Adopts Intel® Matrix Storage Technology to support RAID 0/1(RAID 0/1/5/10)
Dual Gigabit Ethernet ports
|
|
| ... products without technical information |
| |
|
|
|
|
16-channel H.264 Full D1 Network Video Recorder with Core 2 Quad CPU and 4 internal storage drives
Features
* H.264/AVC codec
* 16 BNC inputs for video
* 16 G.711 audio inputs
* Supports Intel Core 2 Duo and Core 2 Quad CPUs, LGA775 x 1
* 4 x 3.5" internal HDD bays, 1 slim CD drive bay
* Intel Q35 + ICH9DO chipset
* Intel Rapid Recovery RAID
* Max 4GB DDR2
* 2 RJ45 GbE Network Ports
* 1 PCI-E expansion slot for discrete graphics or 4/16 channel capture card
Form Factor
2U Rackmount
H.264 Video
Compression: H.264/AVC BP codec
Video Input: 16 x BNC inputs CVBS 1.0Vp-p, with 75 ohm loading for video input
Resolution: 16-channel full D1 resolution at 30/25 FPS for NTSC/PAL
NTSC: 30FPS per channel / PAL: 25FPS per channel
Audio Input
16 RCA audio ports
G.711 audio compression
Platform
Supports Intel Core 2 Duo and Core 2 Quad CPUs, LGA775 x 1
Chipset: Intel Q35 + ICH9DO
Storage
HDD Bays 3.5” x 4 internal bays
Slim CD drive bay x 1
HDD Interface SATA II x 6
RAID
Intel Rapid Recovery
System Memory
Dual-channel DDR2 DIMM 800/667 MHz
Max Capacity: 4GB
Socket: 240P DIMM x 2
OS Supported
Microsoft Windows XP
Microsoft Windows 2003
Ubuntu Linux 7.10
CentOS Linux 5
Linux 2.6.18 ~ 2.6.22
Networking
Ethernet Ports RJ45 x 2 GbE (Intel 82573L)
Alarm /PTZ
PTZ Control 1 RS-485 for PTZ
Alarm Interface 8 DI and 8 DO terminal block
Expansion: 1 x PCI-E (x8) for independent graphic card or 4/16-channel video capture card
Power
Type / Watts: 350Watts
Input AC: 90~264V at 47~63Hz
Compliance
CE Emission, FCC Class A, RoHS
http://www.lannerinc.com
|
|
|
|
|
|
Honeywell’s Enterprise NVR (Network Video Recorder) video management system is an industry-leading enterprise class digital video surveillance solution. The Enterprise NVR is built on best-in-class components that provide the flexibility and scalability needed to design a video system suited to a variety of end user applications. Honeywell is a total solution provider offering all the components of a reliable video system such as cameras, encoders, management software, servers, workstations, and video storage units.
The Enterprise NVR Series servers are the backbone of the Enterprise class digital network video recording system. The servers run the Enterprise NVR software and manage digital video—including receiving, storing and retransmitting video when it is requested by an NVR client workstation. Enterprise NVR servers leverage industryleading IT components and are tested to sustain the rigorous demands of a video system.
Features:
* Capable of simultaneous record, playback, live view, archive, or transmission of digital video
* Receives and records a minimum of 32 channels of 4CIF
* Save user-selected video clips as a watermarked and tamper resistant Safe Data Container (SDC)
* Supports multiple layers of imported facility maps with associated cameras
* Utilizes Intel Xeon Dual Core processor technology
* 1 GB of DDR2 400 RAM
* RAID1 mirrored internal 160 GB SATAII hard disks for redundancy
* Dual channel U320 SCSI for external storage connectivity
* Dual Gigabit Ethernet ports for load balancing and maximum data throughput
* Windows® XP Professional Operating System
* Single or redundant power supply option.
|
|
This powerful, intelligent, all-in-one network surveillance recorder is extremely easy to use for multi-camera monitoring, recording, search and playback. It offers 1000 GB storage capacity, 480 frames per second recording and support for up to 64 audio channels.
Incorporating intelligent video analytics including Video Motion Filter Alarms and Video Motion Filter Searches it provides high levels of operational efficiency and security.
It can be deployed as a stand-alone system or in a small- to large-scale client/server configuration, and uses the reliable Linux operating system.
|
|
|
|
