DIRECT DRIVE PUMP
ALSO AVAILABLE IN 40 HP
Powered by a 30 hp
electricity motor with
variable speed drive,
the P3055V operates
at a pressure of 0 to
55,000 psi (3,800 bar)
and flow rates from
.3 to .43 gpm.
Its low vibration and
quiet operation result in
dramatic reductions in
wear and tear on the
pump and surrounding
connections.
This rugged pump's
simple design makes
it economical, reliable
and easy to maintain. |
|
Standard characteristics :
- Maximum pressure : 4140 bar (60,000 psi).
- Working presure : from 500 up to 3500 bar (7,200 to 50,000 psi).
- Max. flow rate : 10 l/min at 3500 bar (50,000 psi).
- 1 SUGINO intensifier (redundancy in option), 1 UHP accumulator.
- Soundproofed casing.
- Complete hydraulic unit, with 10 µ filtration, and water cooling.
- Protection valve for automatic bleed-down of the UHP circuit.
- PLC controller : support for the maintenance and the follow-up of the functioning.
Advantages :
- Pumps perfectly adapted to all industry sectors : automotive, mechanics, aeronautics, food industry, and designed for a use in 3 shifts, 7 days a week.
- Turnkey equipments.
- Pumps with the UHP components reaching the best life times of the market.
- Decrease of the running costs. |
|
Among the most efficient, with the smallest footprint in the industry, the Waukesha Cherry-Burrell Homogenizer delivers more output for its plant space than any other. Advanced, fluid-dynamically engineered homogenizing cocks achieve the desired degree of dispersion/emulsion with lower pressures, requiring less energy and extending the life of moving parts.
- Precise, non-adjustable plunger seal; double professional seals standard, single seals optional.
- Injection cooled and flushed seals resulting in increased seal life.
- Headblocks with hardened replaceable valve seats.
- Sanitary overpressure relief device.
- Modular valve assemblies; single or double stage, manual or hydraulic.
- Multiple plunger sizes available for each model.
- Easy to maintain with front loaded seals and separate drive components.
- Also available without homogenizer valves for service as High Pressure Plunger pump
|
|
The Jet Edge iP55-75 is a 75-horsepower intensifier pump rated at 60,000 psi (4,100 bar). It is capable of producing output pressures from 1,000 to 55,000 psi (3,800 bar) with flow rates of 0 to 1.5 gallons (5.7 liters) per minute to a variety of cutting, surface-preparation or cleaning tools.
Features
- High efficiency TEFC motor
- 1,500 or 1,800 nominal motor speed (rpm)
- Electronically shifted intensifiers
- Wye-Delta soft start with disconnect
- 0.5 gallon (1.9 liter) high pressure attenuator with 1.45 micron filtration
- Safety shutdown systems
- Automatic safety pressure bleed-down cock
- Thermostatically controlled professional cooling system
- Programmable Logic Controller (PLC SUPPLIERS) for operation and safety monitoring
- Axial piston, variable displacement, pressure-compensated manufacturers of hydraulic pump
- Liquid-filled pressure gauges supplier
- UHP safety shielded tubing |
|
The Resato Powerjet PJE waterjet cutting pump is an example of our continuing commitment to research and development.
The latest generation of our skillfully designed waterjet cutting pumps offers monitor control and simple time-saving servicing possibilities. Proven reliability reduces down-time to a minimum and the operation costs will be reduced accordingly. As a result of further developments and tests in our cutting laboratory, the life cycle of high pressure professional seals and other parts subject to wear has been extended considerably.
To complement our extensive range of waterjet cutting pumps we offer all waterjet cutting accessories vital to the realization of a turn-key cutting system. |
|
Ideal for use in remote and/or mobile locations where electricity is scarce, the iP55-280DS is powered by a 280hp Cummins turbo professional diesel engine that meets Tier 3 emissions standards. It is capable of producing a flow rate of up to 4.1 gallons (15.5 liters) per minute of 55,000 psi (3,000 bar) ultra-high pressure water for waterjet cutting, surface preparation and cleaning applications.
The iP55-280DS utilizes a pressure-compensated hydraulic system to drive dual plunger-style intensifiers. The use of hydraulic fluid power provides smooth flowing UHP water resulting in long system life. Reliable and precise control of the electronically shifted intensifiers ensures superior performance standards with reduced operating costs. The pump is built on a skid-mounted frame with lifting eyes and forklift professional guides provided for increased mobility.
A 36,000psi model is also available.
Find out more at www.jetedge.com. |
|
The direct drive pump operates in the same manner as a low-pressure "pressure washer" that you may have used to pressure wash a house or deck prior to repainting. It is a triplex pump that gets the movement of the three plungers directly from the electric motor. These pumps are gaining acceptance in the waterjet industry due to their simplicity. At the time of this writing, direct drive pumps can deliver a maximum continuous operating pressure 10 to 25% lower than intensifier pumps units (20k to 50k for direct drive, 40k to 60k for intensifiers).
Only Flow manufactures both HyPlexTM and intensifier pumps. As a result, we can offer you the pump solution that is best suited for your application. Whether you run 24 hour, 7 days a week production or prototype jobs only a few hours a day, we have the right pump for you. Best of all, no matter which style of pump you choose, you'll receive a Flow pump that is reliable, simple, efficient, and easy to maintain. The focus of all our designs is performance, reliability and longevity so that your productivity is increased.
Flow Pumps Operate At Higher Pressures
Flow intensifier pumps are rated at 60,000 psi and our systems actually run at that pressure. No backing off, no hedging. It's another big reason why Flow equipment out-produces all others. Flow manufacturers the most complete range of ultrahigh-pressure waterjet pumps in the industry. From 205 hp, 6.5 gpm diesel powered Husky pumps for surface preparation to 100,000 psi pumps used for ultrahigh-pressure food processing to intensifier and direct drive pumps for waterjet cutting, Flow has a pump to meet your needs. Flow is the only waterjet company to offer its customers a choice of intensifier or HyPlex(direct drive) waterjet cutting pump technology. The wide range of waterjet pumps Flow builds is your assurance that you and your application will be paired with a pump that is specifically tailored to meet your needs.
Our waterjet cutting pumps set the industry standard for performance and reliability that is proven in 24 hour, 365 day a year operations around the world. All Flow pumps are capable of smooth, continuous operation, year after year, at the pressure they are rated. This ensures you receive the maximum possible benefit of pump's capacity and the performance you have paid for. It's an important distinction to make, because a pump's performance is limited by the lowest pressure it reaches in a cycle. By operating smoothly with a minimum of pressure fluctuations at the highest rated pressure a Flow pump can outperform other pumps which are rated for high pressures, but don't necessarily operate there smoothly or continually.
|
|
Tecnocut established a new concept of ultra high pressure intensifiers by giving its uniqueness and exclusivity, enhancing its technology making it the real answer to the prayers of the most demanding users.
The original technical design was for the system to be fitted with several electronically synchronized, parallel, independent pressure multipliers.
This allows increasingly constant pressure, avoiding typical drops of the traditional intensifier with single opposite professional cylinder. |
|
Maximum Productivity, Lower Cost of Operation
Maximum productivity and low operational costs are the keys to keeping your business competitive. Flow's 55,000 psi HUSKY pump sets a new industry standard for both productivity and reliability, giving you a portable ultrahigh-pressure waterjet pump that contributes to your bottom line by allowing you to work more efficiently and take on more jobs. The HUSKY is the world's first 55,000 psi direct drive triplex pump with full pressure compensation giving you the power you need to reduce your operating costs and increase productivity on a square foot basis. Now you get Flow's proven HUSKY UHP pump with a world class Caterpillar C-9 engine that meets Tier II emission requirements, on board diagnostics and lower fuel consumption.
The 55,000 psi HUSKY is compatible with all other Flow machines, meaning no additional investment in technology is necessary to upgrade.
Benefits
Maximum productivity from 55,000 psi - the highest pressure available in the industry
Lower cost of operation gives contractors a competitive advantage when bidding on jobs
Compatible with all existing Flow industrial cleaning products
Latest technology makes 55,000 psi pump the easiest-to-use, most reliable pump in the industry
Standard Features
290 hp Caterpillar C-9 Engine, producing 210 nhp - the highest available nozzle manufacturers horsepower
Automated settings for multiple tool operation
Diagnostic sensors to assist with troubleshooting and preventative maintenance
Engine meets worldwide Tier 2 emission standards
On-board water industrial booster and filtration system
Full pressure compensation allows for multiple tool use
Triple high-pressure outlet ports
82 gallon fuel tank
Multilingual remote operator box
Small 58.5" x 102" footprint
Specifications
Operating Pressure: 55,000 psi (3,790 bar)
Maximum Flow Rate: 6.5 gpm (24.5 lpm)
Approximate Weight: 5575 lbs (2534 kg) dry
Fuel Capacity: 82 gal (310 l)
Engine: 290 hp (216 kW) Caterpillar C-9
Nozzle Horsepower: 210 nhp (157 kW) continuous duty
Speed: 2,100 rpm continuous duty
Water Filtration: 10 micron absolute
Mounting Type: Skid or optional professional trailer mount
|
|
Standard characteristics :
- Maximum pressure : 4140 bar (60,000 psi).
- Working presure : from 500 up to 3500 bar (7,200 to 50,000 psi).
- Max. flow rate : 10 l/min at 3500 bar (50,000 psi).
- 1 SUGINO intensifier (redundancy in option), 1 UHP accumulator.
- Soundproofed casing.
- Complete hydraulic unit, with 10 µ filtration, and water cooling.
- Protection valve for automatic bleed-down of the UHP circuit.
- MANUFACTURERS OF PLC controller : support for the maintenance and the follow-up of the functioning.
Advantages :
- Pumps perfectly adapted to all industry sectors : automotive, mechanics, aeronautics, food industry, and designed for a use in 3 shifts, 7 days a week.
- Turnkey equipments.
- Pumps with the UHP components reaching the best life times of the market.
- Decrease of the running costs. |
|
