Butterfly valves

DN: 2 in - 12 in
Pressure: 300 psi
Temperature: 120 °C

... 1.Maximum Working Pressure: 300PSI (Max. Test Pressure: 600PSI) 2.Maximum Working Temperature: 250ºF (120ºC) 3.Application: Indoor and Outdoor Use 4.Double-Seal Disc: Resilient EPDM Coated 5.Factory Installed Supervisory Tamper Switch Assembly ...

... required by butterfly valves. Gearboxes are designed to enable butterfly valves to be opened by one person manually by turning the handwheel under rated pressure acting from one side. ...

... that has clumped together in storage, dust formation, ensuring exact/calibrated quantities etc. Product range ■Flat slide valves ■Chutes ■2-way switches Properties/variants Applications For flowing or pourable bulk materials Configurations ...

DN: 100 mm - 400 mm
Temperature: -25 °C - 150 °C

... Butterfly valves suitable for intercepting powdered products - Size DN100 - 150 - 200 - 250 - 300 - 350 - 400 - 2 half-bodies in cast aluminum with double flange: identical upper and lower flange - Possibility of ...

... The “singold” Flap Shutter is used for all kinds of bulk material and solid-liquid mixtures, when the container is to be completely emptied. Examples: Container scales, container, primary and secondary vessels in mixing plants, wagons, reservoirs ...

DN: 100 mm - 3,000 mm
Pressure: 10, 16, 25, 40 bar

... eccentric valves used for their strength and resistance even at high pressure. Made in high quality ductile cast iron with stainless steel shafts and a welded-on seat ring. STANDARDS OF MANUFACTURE EN 593 METALLIC BUTTERFLY ...

DN: 50 mm - 600 mm

... Ductile Iron Full Lug Butterfly Valves Size: 2 to 24 in. (50 to 600mm) Description: These soft-seated butterfly valves are designed for a variety of general applications in the control ...

DN: 1 in - 6 in
Pressure: 0 bar - 10 bar
Temperature: -10 °C - 95 °C

... /BS4825-1/AS1528-1 End connections butt weld(std) for inch tubing(O.D.tubes) STAINLESS STEEL HYGIENIC BUTTERFLY VALVE ...

DN: 3,600 mm
Pressure: 10 bar

... Type: Ductile Iron Butterfly Valve. Body Material: Ductile Iron. Seat Material: EPDM. Operator: Gear. ...

DN: 15 mm - 100 mm
Pressure: 16 bar
Temperature: -10 °C - 130 °C

... Brass butterfly valve full bore, F/F threaded with throttling. ...

... performance butterfly valves are widely used in many industries including heating, ventilating and air conditioning, power generation, hydrocarbon processing, water and waste water treatment, marine and commercial shipbuilding. Valves ...

DN: 2 in - 12 in
Pressure: 150 psi

... SIZE: 2＂～12＂ JOINT END: FLANGE (ANSI /DIN / JIS/ CNS) WORKING PRESSURE: 150PSI Key words: CPVC pneumatic butterfly valve ...

DN: 25 mm - 300 mm
Pressure: 16, 10, 6 bar
Temperature: -10 °C - 120 °C

... General purpose valve with an EPDM liner, offering a long life with low maintenance. Self-lubricating bearings ensure perfect guiding and turning of the shaft without seizure or premature wear. These valves are supplied ...

DN: 1.25 in - 24 in
Temperature: -10 °C - 110 °C

... Ductile Iron Wafer butterfly valveDiameters from DN032 - 1¼" to DN600 - 24"For EN1092 PN16 flanges (also PN10 for DN≤150)Lengths according to EN558-1 series 20 (ex DIN3202 K1)Design according to EN593Testing according to EN12266-1Epoxy ...

DN: 450 mm
Pressure: 20 bar
Temperature: -29 °C - 120 °C

... We Provide ASTM B148 C95800 Butterfly Valves, ASTM B148 C95800 Pneumatic Butterfly Valves, API 609, 18 Inch, DN450, Class 150 LB, PN20. Design Standard: API 609. Body Material: ASTM ...

DN: 2 in - 60 in
Pressure: 16 bar - 160 bar

... waterway pipelines and is used as regulation and interception equipment. Compared with the centre butterfly valve, the double eccentric butterfly valve is more resistant to high pressure, ...

DN: 25 mm - 800 mm
Pressure: 500,000 Pa - 700,000 Pa
Temperature: -40 °C - 450 °C

... Structure: Centre Sealing Seal Form: Auto Sealed/Force Sealed Material of Seal Surface: Soft Sealed Valve Body: Injection Trademark: Baodi Transport Package: Carton/Plywood Box ...

DN: 4 mm - 32 mm
Temperature: -50 °C - 200 °C

... Pneumatic control valve VALVE STYLE Butterfly valve USAGE Throttling service Low-pressure service On/off service Hygienic service VERSION ANSI SUPPLY Pneumatic VALVE ...

DN: 50 mm - 500 mm
Pressure: 10, 6 bar
Temperature: 180 °C

... One-piece body, tight-closing, centric disc With blow-out proof shaft Design for mounting between flanges according to DIN EN 1092-1 Face-to-face length according to DIN EN 558-1-R20 Leakage rate A according to DIN EN 12266-1 For all flammable gases ...

DN: 50 mm - 500 mm
Pressure: 6 bar - 10 bar
Temperature: 200, 70 °C

... Intermediate flange butterfly valve for shutting off dusty and powdery bulk materials. MATERIAL HOUSING :Aluminum cast MATERIAL SEALING DISC :Structural steel, stainless steelMATERIAL SEALING RING :PUR, VMQTIGHTNESS ...

DN: 50 mm - 2,000 mm
Pressure: 1, 1.6, 4 MPa

... is sea The disc of the hard-sealed butterfly valve is installed in the diameter direction of the pipeline. In the cylindrical passage of the butterfly valve body, the disc-shaped butterfly ...

DN: 25 mm - 100 mm
Pressure: 0.2 bar - 10 bar
Temperature: -10 °C - 140 °C

... extraction of the valve by means of 4 screws while the flanges welded to the installation remain fixed. Sanitary butterfly valvescan be operated automatically through an actuator (sanitary pneumatic butterfly ...

DN: 150 mm
Pressure: 10 bar - 16 bar
Temperature: -20 °C - 90 °C

... Butterfly valve DN 150 PN10-PN16 Lug type GGG40 with notch lever with grey sleeve EPDM DVGW drinking water, WRAS, ACS, W270 sleeves: - EPDM DVGW drinking water, WRAS, ACS, W270 body material: - SG iron EN-JS1030 ...

DN: 50 mm - 300 mm
Pressure: 6 bar - 16 bar
Temperature: -20 °C - 180 °C

... • wafer type butterfly valve designed according EN 593 • flange connections according EN 1092-2 - PN6/10/16, ASME/ANSI B16.5 class 150, ASME/ANSI B16.47 class 150 series A • face to face dimension according EN 558-1 ...

Temperature: 0 °C - 600 °C

... The Vatac High Performance valves are available in Soft Seat (Up to 200°C depending on size and pressure), and Metal Seat (Up to 600°C) variants (fire safe on application). Vatac Flange High Performance Butterfly ...
