Resistance: 10 kOhm - 6,000 kOhm
Power rating: 1.5 W
ASTRO2 precision resistors were developed for critical and demanding applications, which require a high precision and stable resistance value. Multi chamber (bifilar) windings secure a low inductance. During the production ...
Resistance: 10 kOhm - 1,000 kOhm
Power rating: 0.5 W
ASTRO5 precision resistors were developed for critical and demanding applications, which require a high precision and stable resistance value. Multi chamber (bifilar) windings secure a low inductance. During the production ...
Resistance: 0.005 Ohm - 0.1 Ohm
Power rating: 5 W
MST current sense resistors are accurate components for current sensing circuit applications. They have low inductance (<10nH), power rating of up to ...
Resistance: 10 Ohm - 1,000,000 Ohm
Power rating: 0.1, 0.125, 0.25, 0.063 W
SCOPE This specification describes AT0402 to AT1206 high precision-high stability chip resistors with lead-free terminations made by thin film process. APPLICATIONS Automotive electronics Industrial and medical equipment ...
Resistance: 0.01 Ohm - 1,000,000 Ohm
Power rating: 0.05 W - 2 W
... Thick fi lm technology ■ Power rating of 2 watts at 70 °C ■ Low resistance value available ■ RoHS compliant* Applications ■ Current sensing ■ Power supplies ■ Stepper motor drives ■ ...
Resistance: 10 Ohm
... Welding ones and combining with the original thin film and thick film technology, Delta has developed a series of current sensing resistor which characterized with miniaturization, high precision, and ...
High power to size ratio Low inductance, less than 5 nH Ceramic cases are available with circuit board stand-offs (designated with a -3 model ending) Superior surge capability Extremely low resistance values Complete welded construction ...
Resistance: 0.0005 Ohm - 200,000 Ohm
Power rating: 2 W - 20 W
... environmental protection. Series LVF resistors are well-suited for current sensing applications including test instrumentation, power supplies, and power amplifiers. Specify ...
Resistance: 0.002 Ohm - 0.05 Ohm
Power rating: 0.25, 0.5, 1 W
Surface Mount Metal Plate Current Sense The 60S series current sense resistor series design has low termination stress (“J” terminals), and flexible ...
Resistance: 0.001 Ohm - 0.1 Ohm
Power rating: 3, 0.33 W
High power metal alloy current sense resistor comes in value ranges from 0.001 to 0.1 ohm in 0603 and 2512 size at 75 and 100ppm. Tolerances of 1% and 5%. Power rating ...
Resistance: 0.1 Ohm - 10 Ohm
Power rating: 0.166 W - 0.66 W
Applications Car electronics, Power supply, Industrial robots Features Excellent anti-sulfuration characteristic due to using high sulfuration-proof inner top electrode material. Current detecting resistors ...
Resistance: 0.051 Ohm - 1 Ohm
Power rating: 0.125 W - 2 W
3 Watts power rating in 1 Watt size,1225 package Low TCR of ±100PPM/℃ Resistance values from 1m to 1 ohm High purity alumina substrate for high power dissipation Long side terminations with higher power rating
Power rating: 5 W - 100 W
... the current-viewing-resistors ISM behave like pure dc resistors with frequencyindependent resistance value. Because of their double coaxial design current-viewing-resistors ...
Resistance: 0.0005 Ohm - 1.8 Ohm
Features: SURFACE MOUNTABLE, MOLDED FLAT PACK ULTRA LOW VALUES (3m? ~ 1?) EXTEND TEMPERATURE RANGE (+180°C) Pb-FREE REFLOW COMPATIBLE
Resistance: 0 kOhm - 100 kOhm
Up to 30 Watts at +25°C Case Temperature, derated to zero at +150°C. Exposed Ceramic Heat Dissipating Mounting Surface. Resistance Range of 0.010 ohm to 100 K. Non-Inductive Design.
