Cylindrical displacement sensors

Measuring range: 1, 2, 3, 6 mm
Ambient temperature: -30 °C - 180 °C

... system for fast, high precision displacement measurements. The system comprises a compact controller, a sensor and an integrated cable and is factory-calibrated for ferromagnetic or nonferromagnetic materials. ...

Measuring range: 4, 6, 2, 8 mm
Ambient temperature: 0 °C - 70 °C

The new eddyNCDT 3001 is a cost-effective eddy current sensor with housing that has to date only been reserved for inductive sensors and proximity sensors. This compact sensor ...

Measuring range: 1, 3, 5, 10 mm
Linearity: 0.3 %
Supply voltage: 14 V - 30 V

The compact DTD inductive sensor system consists of a gauge with a plunger guided by a plain bearing and a controller, which are connected to each other with a 3 m long cable. The controller has a diameter of just 18 ...

Measuring range: 0 mm - 12 mm
Ambient temperature: 0 °C - 50 °C

... foundations, of servo regulators, valve and robot controllers -Measurement of growth, and so on The incremental displacement sensors are based on a magnetic principle: consisting of a magnetic scale ...

Measuring range: 0 mm - 100 mm
Power consumption: 1 W
Ambient temperature: 0 °C - 50 °C

... foundations, of servo regulators, valve and robot controllers -Measurement of growth, and so on The incremental displacement sensors are based on a magnetic principle: consisting of a magnetic scale ...

Measuring range: 25 mm - 500 mm

The LVDT series LVPH by WayCon is developed for use in hydraulic cylinders. The inductive sensors measure reliably at a pressure of up to 350 bar. Measurement range - 25 mm, 50 mm, 100 mm, 150 mm, 200 mm, 500 mm Linearity ...

Measuring range: 0.8 mm - 4 mm
Measuring rate: 5 kHz - 50 kHz

... electrically conductive material can be detected contactless and wear-free by an eddy current sensor. A high-frequency alternating current feeds a coil in the sensor head. The resulting electromagnetic ...

Measuring range: 0.05 in - 0.08 in
Supply voltage: 2 V - 20 V

HPC-75 Series Cylindrical Probes for Precision Dimensional Measurement Capacitec’s HPC non-contact probes are our most popular line of capacitive sensors. The ensor and guard elements are provided in ...

Measuring range: 0.1 in - 0.15 in
Supply voltage: 2 V - 20 V

Capacitec’s HPC cylindrical probes are the most popular of its non-contact line of capacitive sensors due to the ease of installation to measure an earth grounded target. The sensor and ...

Measuring range: 0.23 in - 0.38 in
Supply voltage: 2 V - 20 V

Capacitec’s HPC cylindrical probes are the most popular of its non-contact line of capacitive sensors due to the ease of installation to measure an earth grounded target. The sensor and ...

Measuring range: 25 mm - 250 mm

The RC13 series of compact displacement sensors are used in harsh environment applications requiring a robust linear transducer with long life, high accuracy and a guided push rod with measurement lengths ...

Measuring range: 10 mm - 300 mm

RC20 series displacement sensors are used in harsh environment applications requiring a robust linear transducer with long life, high accuracy and a guided push rod with measuring lengths from 10 to 300 ...

Measuring range: 50 mm - 1,000 mm

... The construction prevents ingress of dirt or dust to the sensor element. On that way IP67 protection is reached for rough environmental conditions. For mechanical coupling the displacement sensors ...

Measuring range: 13 mm - 650 mm

Compact sensor head for general purpose featuring many convenience features. The C01 is the standard sensor head type for the PICOSCALE Interferometer. Due to its collimated output beam, the compact ...

Measuring range: 13 mm - 5,000 mm

Sensor head with collimated beam optimized for long distances and retro-reflector targets. The C03 is a sensor head type optimized for long working distances and using retro-reflectors as target. The ...

Measuring range: 10 mm

Sensor head with focused beam with high alignment tolerance. The F01 is a sensor head type with focused probe beam. This allows to measure displacements of small targets. Furthermore, ...

Measuring range: 50 mm
Linearity: 0.1 %
Supply voltage: 40 V

... stand. Available with different measurement ranges. The electronic crack meter consists of a potentiometric-type displacement sensor that detects changes in position between two points straddling a ...
