Dial comparators

... Mitutoyos Dial Test Indicator is designed to carry out alignment and measurement of difficult-to-reach surfaces. Built with a proprietary design, it offers easy handling and ease of operation. It has a wide dial with ...

Measuring range: 0 mm - 12.5 mm

... Metric / imperial conversion Protection rating IP 51 Additional Features LCD display 12 mm Fastening bush (diameter 8 mm) Interchangeable plunger tip (M2.5) Display pivots through 270° Floating zero Change of origin for any tip position Measurement ...

Measuring range: 12.5 mm - 100 mm
Resolution: 0.5 µm - 10 µm

... accuracy characterize our digital dial gages. The range includes measuring instruments for all applications. Various interfaces for data transfer and a high protection rating up to IP 54 leave no demands unfulfilled. Digital dial ...

Measuring range: 12.7 mm

... This indicator is the MAX/MIN/RANGE value holding function model It offers the following benefits: • The MAX/MIN/RANGE (run-out value) can be measured. • A fast measurement frequency mode(detection cycle 20 ms or 50 times/s) is selectable to ...

Measuring range: 12.5 mm

... Digital dial indicator with very large (12 mm), high-contrast LCD display. Immediately ready for use when switched on due to Reference-System. Function: Display can be zeroed in any position, reversible direction of measurement, buttons ...

Measuring range: 12.5 mm
Resolution: 0.01 mm

... Product overview

• Digital dial indicator DIGI-MET IP52 by HELIOS-PREISSER for precise linear measurement tasks.

• Model: DIGI-MET IP52
• Measuring range:

Test indicators translate small linear distances into rotational movement to measure dimensions to 0.060", accurate up to 0.0001". They are typically fixed to a magnetic base or other Starrett fixture.

Measuring range: 12.5, 25, 50 mm
Resolution: 0.01 mm

... Works standard Large LCD display Aluminium housing Ø 58mm Clamping shaft Ø 8mm h6 Interchangeable measuring insert M2.5 Delivered in a case Functions: On/Off mm/inch commutation Zero setting at any position Tolerance pre-selection ABS / Relative mode ...

Measuring range: 1 mm - 100 mm
Resolution: 0.01 mm

... quality dial indicators with contrast black display. MICROTECH dial indicators can be with ranges 10, 30, 50, 100mm with 0.01mm resolution and precision indicator 0-1x0.001mm. Available modification shockproof, waterproof ...

Measuring range: 5 mm
Resolution: 0.001 mm

... Overview
Dial indicator designed for high-resolution dimensional measurements in industrial environments. Mechanical dial instrument for precise reading of small clearances or thickness variations with 0.001 ...

Measuring range: 1 mm
Resolution: 0.001 mm

... This precision dial indicator by HK is designed to measure linear dimensions and dimensional differences with 0.001 mm resolution. It is suitable for concentricity checks, flatness verification and position measurements in industrial ...

... travel), depending on model ■ Some analogue indicators are also available with Inch scale ■ Scale graduation for Micro comparators is 0.001 mm ■ Different measuring forces between 0.5N and 2.5N (Metric) and between 0.8N and 2N (Inch) ...

... These precise dial indicators maintain linearity and repeatability through millions of cycles. Group 4 indicators feature external zero adjustment knob, making possible to to adjust indicator hand to zero rather than rotating bezel to ...

Measuring range: 25.4 mm
Resolution: 0.001 mm

... English / Metric high accuracy gauge. The EG-225 ( lug back ) and EG-225F ( flat back ) have exactly the same specs. The EG-225 is our most popular gage and always Quick ! Delivery. Preset capability Zero / ABS function Rechargeable battery / 120V ...

Measuring range: 12.5 mm

... Display: LCD with high visibility - giant numbers ABS function Resolution: 0.01mm/0.0005” Precision: 0.02 mm/0.001” Range: 12.5 mm Buttons: on/off, zero, ABS, mm/inch, TOL Data output: jack std 4-way 2,5 mm ABS case Data output compatible with ...

Measuring range: 0.8 mm

... Many models available : horizontal, vertical and longitudinal large and small diameter dial carbide contact point 12 mm or 36 mm length metric reading 0,01 mm or 0,002 mm or 0,001 mm *inch reading .0005” or .0001” ...

Measuring range: 25, 12.5, 50 mm
Resolution: 1 µm

... to easily switch between preset recall or value transmission, streamlining your workflow. • Versatility and Convenience: S_ Dial WORK offer a range of standard functions, including mm/inch conversion, preset capabilities, and direction ...

... travel), depending on model • Some analogue indicators are also available with Inch scale • Scale graduation for Micro comparators is 0.001 mm • Different measuring forces between 0.5N and 2.5N (Metric) and between 0.8N and 2N (Inch) ...

Measuring range: 2 in - 6 in
Resolution: 0.0005 in

... • Dial indicator range: 0-0.25"; Resolution: 0.0005"; Accuracy: +/-0.0007"; Stem diameter: 9.5mm • Bore gauge measuring range: 2-6"; Ideal for hole diameter measuring, geometry Abnormality deteciton; Measuring depth: 9.5" • Comes with ...

Measuring range: 5 mm

Total Range 3 or 5mm, accuracy according to UNI 4180, deutsh made mechanism, Cylindrical mounting diameter ø 8 mm.

Measuring range: 5, 30, 10 mm
Resolution: 0.01 mm

... Bocchi's Dial Indicators have been manufactured out of shockproof and waterproof materials. These apparatus showcase extensive insulation levels against dust and water levels, even in extreme conditions. They feature rubber casings that ...

... 180x450 mm Weight: 10 kg approx. Length comparator with digital gauge 12.7 mm travel by 0.001 mm divisions mod. S382-01, complete with battery and RS232 connection to PC. Length comparator with analogic dial ...

Measuring range: 0 mm - 10 mm

... Dial Diameter 58 mm. Stem diameter 8 mm. Measuring Range 10 mm. Graduations 0.01mm. ...
