Return-line filters

Operating pressure: 0 bar - 10 bar
Filtration size: 10 µm - 30 µm
Flow: 0 l/min - 170 l/min

In-line mounting Connection up to G1¼ / -20 SAE Application In the return line circuits of hydraulic systems. Performance features Protection against wear: By means of ...

Operating pressure: 3 bar
Flow: 700 l/min
Fluid temperature: -25 °C - 110 °C

Hydraulic Return Line Filters are used on the return-side of the hydraulic circuit, where the oil re-enters the tank-reservoir. Return Filters ...

Operating pressure: 10 bar
Flow: 300 l/min

SRK tank-mounted suction and return assemblies/filters are popular choices for hydrostatic transmissions. The patented design uses an integrated main flow and by-pass flow filter, capable ...

Operating pressure: 8 bar
Flow: 0 l/min - 750 l/min

MYclean design (patent pending) to ensure machine reliability, performance, efficiency and ROI by guarantee of original filter elements over the life of the machine. Featuring patented technology, private branding, multiple ...

Operating pressure: 8 bar
Filtration size: 3 µm - 250 µm
Flow: 600 l/min - 1,000 l/min

Tank top filters to protect the circuit return line flows. Ikron HF502 return filters are mounted in the return line ...

Operating pressure: 10 bar
Flow: 40 l/min
Fluid temperature: -10 °C - 80 °C

... flanged connections Our return-line filters of the Pi 5000 series are characterized by a compact and space-saving design. Due to their streamlined design, the pressure drop is minimal. ...

Operating pressure: 0 bar - 34 bar
Filtration size: 5, 20, 10 µm
Flow: 0 l/min - 400 l/min

The ETF series is a light weight and economic tank top mounted return line filter. The Parker Filtration ETF Series is an economic tank top mounted return line ...

Operating pressure: 1.6 MPa
Filtration size: 5 µm - 20 µm
Flow: 150 l/min - 400 l/min

・Vertical return filters are designed for mounting directly on top of oil tanks used in hydraulic systems. They prevent the dust generated within the circuit from entering the tank and help keep the oil ...

Operating pressure: 0 bar - 25 bar
Fluid temperature: -10 °C - 100 °C

... to switch from the dirty filter-side to the clean filter-side without interrupting operation. The filters can be installed as suction filter, pressure filter ...

Operating pressure: 363 bar
Fluid temperature: 14 °F - 212 °F

... pressure filters and return-line filters. Core features High intrinsic stability Excellent filtration capability High dirt-retaining capacity ...

Operating pressure: 8 bar
Flow: 600 l/min

Tank-top mounting filters with threaded ports for return line. High efficiency microfibre or cellulose filtering elements, with by-pass. Electrical or visual clogging indicators.

Operating pressure: 0 Pa - 2,000,000 Pa
Filtration size: 10 µm - 250 µm
Flow: 8 l/min - 1,200 l/min

... , to be installed on return and suction lines. Operating at a maximum pressure of 2.000.000 Pa (20 bar), they can be used also on low pressure delivery lines. Materials and advanced technology ...

Operating pressure: 10 bar
Flow: 180 l/min
Fluid temperature: -20 °C - 100 °C

The 10-FRE series Filters are used for tank top mounting in the return line of the system and provide protection for tank and operating pumps as a result of filtering ...

Flow: 400 l/min

• with 3 or 4 tank mounting holes • with supplementary inlet ports • flow rate up to 400 l/min • with quick service cover FIND YOUR BEST CONFIGURATION Available accessories: • Diffuser • Extension tube • Connection tube

Operating pressure: 12 bar
Filtration size: 3 µm - 90 µm
Flow: 0 l/min - 270 l/min

A wide range of filters and cartridges applicable to the suction, return and intake lines of hydraulic systems. Filtration up to 3 absolute microns. Flow rates up to 600 L/min.

Operating pressure: 0 Pa - 1,000,000 Pa

The TRF is installed on the return line of the reservoir tank just before the reservoir tank to prevent contaminants from entering the tank. Features Installed directly on the tank surface and able ...

Operating pressure: 0 bar - 8 bar
Flow: 0 l/min - 600 l/min
Fluid temperature: -25 °C - 100 °C

The FR1 series of hydarulic oil filters operate in a maximum working pressure of up to 8 bar. These oil filters can operate in ambient temperatures of -25°C to +100°C. All parts are made out of aluminum ...

Operating pressure: 16 bar
Flow: 25 l/min - 1,000 l/min

This kind of filter can be used in hydraulic system for oil return fine filtration, and can keep the oil back to tank clean. This filter can be installed on the cover of the tank and ...

Operating pressure: 3,000 psi
Filtration size: 25, 10 µm
Flow: 24 m³/s - 100 m³/s

Muncie return line filters provide an effective and economical means of protecting and prolonging the life of any hydraulic system. Muncie return line ...

Operating pressure: 145, 200 psi
Flow: 180, 264.9, 568, 1,363 l/min

Hydraulic Filters Salient features • High dirt holding capacity • Lower pressure drop • Water removal elements • Several Mountings and porting options • Indicator shows when no element installed • Easy to service • ...

Operating pressure: 6, 10 bar
Filtration size: 40 µm - 60 µm
Flow: 0 l/min - 50 l/min

... use your machines more efficiently? For detailed information, you can contact us. Return Filters Return-Suction Filters Pressure Filters High ...
