Spindles

Rotational speed: 80,000 rpm
Diameter: 16 mm

... Operation of the spindle Cooling Air Rotation CW / CCW Function position horizontal/vertical ...

Rotational speed: 45,000 rpm
Diameter: 61.9 mm

... Length:234mm Weight:3.8kg Power:DC 2.5kw / AC 1.2kw Voltage:220v Current:3A Poles:2p Tool Chang Method:Pneumatic Direct Tool Change Clamping :3.175、4、6mm Clamping Force:300N Run Out:<10um Balance Grade:G1 Cooling:Water ...

Rotational speed: 6,600 rpm - 34,000 rpm

... B035 feature a labyrinth spindle seal design and standard one year warranty. Click Here To Show AirShield VideoThe B040, B050, B070, and B090 represent the larger Sentry spindles. These spindles feature ...

Rotational speed: 6,000 rpm - 6,200 rpm
Diameter: 45 mm - 380 mm

... MILLING ELECTROSPINDLES Electrospindles with automatic tool change for CNC. They are equipped with: Sensors to check the tool change operations. Hybrid ceramic bearings greased with permanent grease with no maintenance ...

Rotational speed: 3,000 rpm - 9,000 rpm

... friction stir welding powerhouse. Experience unparalleled precision, efficiency, and quality with our FSW spindle for robots. The Stirweld FSW spindle for robots operates without hydraulic power, making it more cost-effective ...

Rotational speed: 8,000 rpm

... drilling capacity max. 42 mm / 600 N/mm² transferable torque 350 Nm spindle variant ISO 40 DIN 2079 (SK 40) rotation accuracy 0,01 mm max. speed 8000 U/min ...

Rotational speed: 10,000 rpm - 175,000 rpm

... changer (up to 20 tools) • Automatic tool changer electric spindle: 10,000 to 60,000 rpm • Air spindles: 9,000 to 175,000 rpm (five spindles) • Electric spindles: 15,000 to 80,000 ...

Rotational speed: 50,000 rpm
Diameter: 100 mm

... precision spindles for internal and external cylindrical grinding. Low vibration amplitudes of HSTec spindles during the grinding process ensure excellent surface quality of the machined workpiece. Additionally, we ...

Rotational speed: 85,000 rpm
Diameter: 3 mm

... 100 can be used for the economical deburring of small and complex parts of metallic as well as nonmetallic material. The spindle is freely compliable in all directions. The pressure against the part edge can be set from the robot program. • ...

Rotational speed: 0 rpm - 3,600 rpm
Diameter: 0.3 mm - 12 mm

... and allows a maximum speed of 3,600 rpm. The spindle is driven by a powerful water-cooled asynchronous motor with 3 Nm torque. With radial and axial load capacities of 425 N and 700 N, respectively, the spindle is ideal ...

Rotational speed: 0 rpm - 15,000 rpm

... integral tool changer to give you the muscle, speed control, and holding torque to perform many operations. The STC1503-BT30 spindle is configured to accept standard BT30 tapered toolholders. Standard or custom CNC tooling make it ...

Rotational speed: 15,000, 18,000, 25,000, 26,000 rpm
Diameter: 230, 270, 170, 202 mm

... line is all about - Vertical machining - Suitable for tilting operation - Milling spindle for processing of different materials - Milling spindle for processing of workpieces with varying geometries - ...

... Applications of Collet Chuck Spindles Collet chuck spindles can be used for a number of workholding applications. They are commonly used for longer shafts and tubes that need to be clamped and supported on the tail ...

Rotational speed: 15,000 rpm
Diameter: 100 mm

... machining center belt drive spindle manufacturer built up by a group of expert engineers and management of products. The belt drive spindle is an important component of machinery. It uses a belt drive system to turn ...

Rotational speed: 250,000 rpm
Diameter: 80 mm - 400 mm

... in offering a range of precision industrial spindles that are essential for high-performance machining applications. GMN spindles are known for their reliability, precision, and ability to handle high speeds, making ...

Rotational speed: 8,000, 9,000, 7,000, 10,000 rpm
Diameter: 12, 16, 20 mm

... Belt Driven Spindles are one of the simple components in the machine tools. The robust and efficient structure of the Belt Driven Spindles have eased many complex applications throughout the industry. Applications ...

Rotational speed: 16,000 rpm

... custom wishes when it comes to spindles. This is particularly the case with the belt spindles and spindle units. With over 400 different models, new models are added every year for our customers. Starting ...

Rotational speed: 600 rpm

... • High speed and high accuracy bearings • Coolant throught drawbar • Rotating adapter union • Hydraulic quick change tool clamping system with or without central cooling lubrication supply ...

Rotational speed: 8,000 rpm - 12,000 rpm

... range: 146, 156,166,196 The oil-bath elastic support structure can be better adapted to the spindle’s high-speed and vibration damping performance Spindle speed ranges from 8000 to 12000r/min The surface is applied ...

Rotational speed: 0 rpm - 23,000 rpm
Diameter: 80 mm - 170 mm

... machines with belt driven spindles, TDM has developed a big variety of spindles. For high performance and for long life each spindle is balanced dynamically and equipped with special grease for reaching ...

Rotational speed: 2,500 rpm - 5,000 rpm

... range of multi- spindle heads, and specifications of feasible head and unit combinations for drilling and tapping. Other combinations are possible for special applications like countersinking, reaming, etc, as well as heads with fixed ...

Rotational speed: 6,000 rpm - 8,000 rpm
Diameter: 170 mm

... WBS-L170 Lathe Spindle Housing：ø170 mm Motor：6HP /4.47kW Shaft-end：A 2-5 Taper：MT6 Speed：6000~8000 r.p.m. Internal hole：ø56 mm Run-out：<1.0μm Temp. Variation：±2.0°C (with oil cooling system) ...

Rotational speed: 20,000 rpm - 30,000 rpm
Diameter: 6 mm - 8 mm

... deflection function of the spindle up to 15 mm maximum constant deflection force even with larger spindle deflection uniform, regular machining, independent from dimensional differences on the workpieces Lateral deflection ...
