Tapping units

The electronic thread tapping unit, specially designed for punching and forming processes, stands out thanks to its excellent process integration. Regardless of whether the electronic ...

Specifications: Cycle range: 500 - 7000 1/min. Production speed: max. 260 1/min. Thread diameter: M2 - M20 Stroke: max. 32 mm

Specifications: Thread diameter: M2 - M20 Production speed: max. 260 1/min. Cycle range: 300 - 9000 1/min. Stroke: max. 32 mm

Specifications: Speed range: 500 - 4500 1/min. Max. torque (Nm): 27 Thread diameter: M3 - M14

... the creation of the thread must be closely related. Inside the WTmax, there is a mechanical device, that slides according to the rotation direction that has been set by giving the tool the axial feeding necessary to ...

Tapping unit with pneumatic quick stroke for short cycle times Total stroke [mm] 50 Speed range at 50Hz [min-1] 500 ...

Autonomous and programmable tapping unit without a leadscrew Total stroke [mm] 60 Speed range at 50Hz [min-1] 200 - 5000 Max. Permissible speed [min-1] ...

Tapping unit with integrated leadscrew for heavy machining Total stroke [mm] 100 Speed range at 50Hz [min-1] 420 - 1500 Max. Permissible speed [min-1] ...

ST0N tapping spindle unit is designed with lead screw transmission and supported automatic thread cutting and float tap chuck. The maximum tapping capacity is M6 (S45C). ...

ST1N tapping spindle unit is designed with lead screw transmission and supported automatic thread cutting and float tap chuck. The maximum tapping capacity is M12 (S45C). ...

ST2N tapping spindle unit is designed with lead screw transmission and supported automatic thread cutting and float tap chuck. The maximum tapping capacity is M30 (S45C). ...

The LS 22 is a tapping unit developed by E2 Systems. It is consisting of a vane motor which is powered by compressed air, a planetary gearbox, lead screw, nut and a follower with cams for activation of ...

... electro-pneumatic units with modular layout. Their electric motor drives the spindle when the feed is pneumatic. The adjustment of the feed rate to be parallel to the pitch and the rpm, is made possible by the hydraulic ...

... series of units. The electric motor runs the spindle, while the feed is hydraulically powered and controlled. Hydraulic feed control makes it possible to use rapid advance and to adjust the feed rate in proportion to ...

Cenchro Tapping Collets For use in standard ER collet chucks for Tapping operations and to expensive Synchronous Tap Holders to correct variations of feed rate in relation to RPM. Designed to improve ...

Cutting Heads For the quick, convenient and very precise production of threads of different forms, pitches, diameters and lengths on various materials

MTE special norm, HSS high speed steel, BSP 55˚, right cutting direction. Application Used for threading pipe and pipe connection parts with adjustable special heads , in unalloyed structural steels, gray cast, brass etc. materials. ( 1 set = 4 pcs.)
