Planetary gear reducer SLFS series
right anglehollow-shaft1 - 5 Nm

Planetary gear reducer - SLFS series - A2V Mécatronique - right angle / hollow-shaft / 1 - 5 Nm
Planetary gear reducer - SLFS series - A2V Mécatronique - right angle / hollow-shaft / 1 - 5 Nm
Add to favorites
Compare this product
Go to the A2V Mécatronique website for more information

Characteristics

Type
planetary
Shaft orientation
right angle
Shaft configuration
hollow-shaft
Torque
20 - 50 Nm, 100 - 200 Nm, 200 - 500 Nm, 50 - 100 Nm, 500 - 1000 Nm, 10 - 20 Nm, 1 - 5 Nm, 5 - 10 Nm
Performance
precision
Applications
industrial
Rotational speed

Max.: 3,000 rpm
(18,849.5559 rad.min-1)

Min.: 2,000 rpm
(12,566.3706 rad.min-1)

Gear ratio

Max.: 512 unit

Min.: 3 unit

Description

The SLFS range of straight planetary gearboxes is designed to deliver high performance in various industrial applications. These gearboxes are available in several models to meet different torque and speed requirements. Here are the main variants available: - SLFS060 - Nominal torque: 16 - 41 Nm - Nominal speed: 3000 rpm - Ratio: 3 - 350 - SLFS090 - Nominal torque: 60 - 132 Nm - Nominal speed: 3000 rpm - Ratio: 3 - 350 - SLFS120 - Nominal torque: 93 - 329 Nm - Nominal speed: 2000 rpm - Ratio: 3 - 350 - SLFS160 - Nominal torque: 270 - 900 Nm - Nominal speed: 2000 rpm - Ratio: 3 - 512 These gearboxes are suitable for applications requiring robustness, precision, and reliability. - Features / Technical Specifications: - Type: Straight planetary gearbox - Available models: SLFS060, SLFS090, SLFS120, SLFS160 - Nominal torque: from 16 to 900 Nm depending on the model - Nominal speed: 2000 to 3000 rpm depending on the model - Reduction ratio: from 3 to 512 depending on the model
