Planetary gear reducer SLE series
right anglehollow-shaft1 - 5 Nm

Planetary gear reducer - SLE series - A2V Mécatronique - right angle / hollow-shaft / 1 - 5 Nm
Planetary gear reducer - SLE series - A2V Mécatronique - right angle / hollow-shaft / 1 - 5 Nm
Add to favorites
Compare this product
Go to the A2V Mécatronique website for more information

Characteristics

Type
planetary
Shaft orientation
right angle
Shaft configuration
hollow-shaft
Torque
20 - 50 Nm, 100 - 200 Nm, 200 - 500 Nm, 50 - 100 Nm, 500 - 1000 Nm, 10 - 20 Nm, 1 - 5 Nm, 5 - 10 Nm
Performance
high-performance
Rotational speed

Max.: 3,000 rpm
(18,849.5559 rad.min-1)

Min.: 2,000 rpm
(12,566.3706 rad.min-1)

Gear ratio

Max.: 512 unit

Min.: 3 unit

Description

Discover our range of SLE straight planetary gearboxes, designed for high performance and reliability in various industrial applications. The SLE series offers several models with different torque, speed, and ratio specifications to meet your needs. - SLE060 - Nominal torque: 16 - 41 Nm - Nominal speed: 3000 rpm - Ratio: 3 - 350 - SLE080 - Nominal torque: 60 - 132 Nm - Nominal speed: 3000 rpm - Ratio: 3 - 350 - SLE090 - Nominal torque: 60 - 132 Nm - Nominal speed: 3000 rpm - Ratio: 3 - 350 - SLE120 - Nominal torque: 93 - 329 Nm - Nominal speed: 2000 rpm - Ratio: 3 - 350 - SLE160 - Nominal torque: 270 - 900 Nm - Nominal speed: 2000 rpm - Ratio: 3 - 512 Technical Specifications / Features: - Type: Straight planetary gearboxes - Models: SLE060, SLE080, SLE090, SLE120, SLE160 - Nominal torque range: 16 - 900 Nm (depending on model) - Nominal speed: 2000 - 3000 rpm (depending on model) - Ratio range: 3 - 512 (depending on model)
