Piston compressor SPINN 5.5X FM CEairelectricstationary
Add to favorites
Compare this product
Characteristics
- Technology
- piston
- Type
- air
- Power source
- electric
- Portability
- stationary
- Lubrication
- oil-free
- Applications
- air conditioning
- Voltage
- 400 V
- Other characteristics
- compact, tank-mounted
- Tank volume
270 l, 500 l
(71.3 gal, 132.1 gal)- Pressure
8 bar, 10 bar, 13 bar
(116.03 psi, 145.04 psi, 188.55 psi)- Flow
Min.: 696 m³/h
(24,579.01 ft³/h)Max.: 1,860 m³/h
(65,685.28 ft³/h)- Power
Min.: 5.5 kW
(7.48 hp)Max.: 15 kW
(20.39 hp)- Length
850 mm, 1,543 mm, 1,945 mm
(33.46 in, 60.75 in, 76.57 in)- Width
720 mm
(28.35 in)- Height
980 mm, 1,337 mm, 1,468 mm
(38.58 in, 52.64 in, 57.8 in)- Weight
Min.: 160 kg
(352.7 lb)Max.: 300 kg
(661.4 lb)- Noise level
65 dB, 69 dB, 71 dB
Description
Spinn screw compressors 5.5X-15kW are a great option for anyone who needs reliable, efficient, and user-friendly compressed air equipment. Their advanced technologies include a rotor design and an oil household that enhance their performance and durability.
easy installation
compact design
Very compact and easy to install, Spinn 5.5X-15 kW offers excellent savings on installation and piping costs, especially on the compact model with dryer.
safe investment
efficient
Spinn 5.5x-15 kW is 30% more efficient than piston compressors and has a longer lifetime due to less vibration and fewer moving parts.
quiter workplace
silent
This range provides small screw compressors with an extremely low noise level, comparable to your air conditioning system. It produces only 61 to 71 dB(A).
infographic controller
TAKE CONTROL
The controller allows easy monitoring and control of the compressor's functions, such as pressure, temperature, maintenance, and alarms.
